CCD Session S00005
	Moon Images
	Composite

Some of the images below can be viewed at larger size by clicking on them.

Moon - CCD Images
Copernicus and Mare Nubrium 2001-10-03, 22:24h UT  0.1 secs  exposure (#5012)	Lacus Somniorum (The Lake of the Dreamers) 2001-10-03,  23:11h UT 0.2 sec exposure (#5044)
Tycho 2001-10-03, 23:01h UT 0.2 sec  exposure (#5037)	Mare Crisium (The Sea of Crises) 2001-10-03,  23:08h UT 0.2 sec exposure (#5041)
CCD Images taken with ST-7E at 1x1 binning, though 8" LX200  stopped down to 2" diameter equivalent. CCD Temperature -10 deg C Image reduction made using a rough Flat Field (some dust spot effects remain) Images unsharp masked, then resized and sharpened in PaintShop Pro Image scale 2.27 arc sec/pixel (original 0.89 arc sec/pixel) Optics back-calculated to be 2xxxmm focal length (f/xx)
More images (click on image for larger view)
Mare Frigoris, Endymion 2001-10-03, 23:11h UT 0.2 sec exposure (#5045)	Plato, Anaxagoras 2001-10-03,  23:12h UT 0.2 sec exposure (#5046)
Mare Tranquillitatis 2001-10-03, 23:09h UT 0.2 sec  exposure (#5042)	Mare Crisium, Geminus 2001-10-03,  23:07h UT 0.2 sec exposure (#5040)
Mare Imbium 2001-10-03, 23:04h UT 0.2 sec  exposure (#5038)	Southern Highlands 2001-10-03,  23:00h UT 0.2 sec exposure (#5036)

Unplanned Composite of several CCD Images

2001-10-03, 23:04 to 23:12h UT,  Composite of several images each of 0.2 sec exposure (Uneven flat fielding is evident in these images) (click on image for larger view) Annotated Composite
