Objects Session Notes
Bullet C/2006 M4 (Swan) - Comet
Bullet M31 - Spiral Galaxy (Mosaic)
Bullet M31 - Extragalactic Nova: M31 2006 14
Bullet Astrometric & Photometric Monitoring
- HD 5501/5513 (eclipsing variables)
- SS Cyg (dwarf novae)
- BL Lac (BL Lac blazer)
- 6.5 hr session, largely operated under automated control
- CCD operation of -25 degC (at 55% average cooling). .
- main objective was to acquire a large scale image mosaic of M31, together with follow-up images on C/2006 M4,  SS Cyg, BL Lac and M31 Nova (2006 14)
-
- More Notes
-

C/2006 M4 (Swan) - Comet

Comet C/2006 M4 (Swan)
(passing through starfield in Aquila)

CCD Image
5 x 60s exposure (average combine, aligned on comet),
2x2 binning, C filter,  Linear scale
2006-12-09 18:23h UT (#161018-22



False Colour CCD Image
Log brightness scaling (3000 ADU range)
(details as above)

Back to Top

M31 - Spiral Galaxy (Andromeda Galaxy), Mosaic

M31 (Andromeda)
5 x 10 mosaic acquired over 2.5 hour period, 3 min exposures

CCD Image Mosaic (5x10 frames, 33% size)
3 min exposure, 2x2 binning, C Filter
2006-12-09 20:03 to 22:41h UT (#161075-124)
Linear brightness scaling,   (larger image, 50% size)


M31 - details



False Colour CCD Image Mosaic
(5x10 frames, 20% size)
Log brightness scaling
Image details as above

False Colour CCD Image Mosaic
(5x10 frames, 20% size)
Log brightness scaling
Image details as above





CCD Image Mosaic
(5x10 frames, 20% size)
Linear brightness scaling, Negative
Image details as above

CCD Image Mosaic
(5x10 frames, 20% size)
Linear brightness scaling
Image details as above



Mosaic Frames
(with original background variation)

Mosaic Frames
(with correction of background light variation)



CCD Image Mosaic
(5x10 frames, 20% size)
Linear brightness scaling
Image details as above

CCD Image Mosaic
(5x10 frames, 20% size)
Linear brightness scaling
Image details as above

Back to Top

M31 - Extragalactic Nova : M31 2006 14

M31 part (Andromeda)
An extragalactic nova (M31 2006 14) was discovered in M31 on 2006/11/25.468
by Koichi Itagak, with an apparent magnitude of +17.5
(Extragalactic Novae page at Rochester Supernova site | Discovery Image | Reference: 2006-11a)

Image below (2006-12-10.00) shows that object (shown by white marker) is still visible,
despite the bright moonlit sky background
Estimated magnitude +16.1 . Limiting Mag +16.5

CCD Image
7 x 3 min exposure (average combine), 2x2 binning, C Filter
2006-12-10 00:02h UT (#161171-75)

Back to Top

Astrometric and Photometric Monitoring

Back to Top
