CCD Images - Session 597 (2016-02-18)

Objects Session Notes
Bullet NGC 3041 - Spiral Galaxy
Bullet NGC 3162 - Spiral Galaxy
Bullet NGC 3190 - Spiral Galaxy (Part of Hickson 44)
Bullet Abell 24 - Planetary Nebula (PLN 217+14.1)
Bullet C/2013 US10 (Catalina) - Comet
Bullet NGC 3041 - Spiral Galaxy
Bullet NGC 2835 - Spiral Galaxy (UGCA 157)
Bullet Abell 33 - Planetary Nebula (PLN 238+34.1)
Bullet IC 2207 - Spiral Galaxy
Bullet NGC 4361 - Planetary Nebula
Bullet C/2014 W2 (PANSTARRS) - Comet
Bullet 9P/Tempel - Comet
Bullet NGC 5374 - Spiral Galaxy with SN 2016P
Bullet NGC 3209 -  Elliptical Galaxy
Bullet Hickson 61 - Galaxy Cluster (NGC 4169 et al, "The Box")

Bullet Photometric Monitoring - Variables
  RX And, U And, Z And, SS Cyg, U Gem, BL Lac, SZ Lyn, CN Ori, CZ Ori, FO Ori, FU Ori, NV Ori, DY Per, GK Per, ER UMa

Bullet Astrometric Monitoring - Nearby Stars
  None
- Late Evening/Night session (6.2 hrs duration).
Clear skies. Wind 0-5 mph.  Moon 87% phase
- Session operated under semi-automated control, with remote monitoring from indoors computer.
- Ambient Temperature:  -3.0degC (minimum)
- CCD operation -30 degC (at 63% average cooling).
- Planned objectives of the session were to monitor selected variable and nearby stars. As conditions where good images were also taken of C/2013 US10 (Catalina), two other fainter comets and a number of deep sky objects in Leo, Hydra, Virgo and Coma Berenices


NGC 3041 - Spiral Galaxy

NGC 3041 (Leo)
CCD Image (cropped)
3 x 90s exposure (average combine), 3x3 binning, C Filter
2016-02-18 23:32h UT (#597058-60)
12" LX200R  (at f/10.4) + ST-10XME

NGC 3041 - detail
CCD Image (cropped)
Image details as above

Negative CCD Image (cropped)
Image details as above

Back to Top


NGC 3162 - Spiral Galaxy

NGC 3162 (Leo)
CCD Image (50% size)
3 x 90s exposure (average combine), 3x3 binning, C Filter
2016-02-18 23:42h UT (#597065-57)
12" LX200R  (at f/10.4) + ST-10XME

NGC 3162 - detail
CCD Image (cropped)
Image details as above

NGC 3162 - Earlier Image (2016-02-11)
CCD Image (cropped)
2 x 90s exposure (average combine), 3x3 binning, C Filter
2016-02-11 22:07h UT (#596190-93)
12" LX200R  (at f/10.4) + ST-10XME

Back to Top


NGC 3190 - Spiral Galaxy (Part of Hickson 44)

NGC 3190 (Leo)
CCD Image (cropped)
3 x 90s exposure (average combine), 3x3 binning, C Filter
2016-02-19 00:05h UT (#597073-77)
12" LX200R  (at f/10.4) + ST-10XME

NGC 3190 - Wider View / Hickson 44
Showing Hickson 44 Members:
Spiral Galaxy NGC 3190 (catalog mag +11.9),
Elliptical Galaxy NGC 3193 (catalog mag +12.0),
Spiral Galaxy NGC 3187 / ARP 316 (catalog mag +13.2)
Annotated CCD Image (50% size)
Image details as above

Hickson 44 - Earlier Image (2008-02-16)
Annotated CCD Image
5 x 3 min exposure (average combine),
2x2 binning, C Filter
2008-02-16 04:32 h UT (#264476-80)

Back to Top


Abell 24 - Planetary Nebula (PLN 217+14.1)

Abell 24 / PLN 217+14.1 (Canis Minor)
Location of Abell 24 planetary nebula is shown by white circle.
It's unfortunately not readily visible due to its faintness and
bright background sky due to 87% phase moon.
Annotated CCD Image (50% size)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2016-02-19 00:22h UT (#597084-94)
12" LX200R  (at f/10.4) + ST-10XME

Abell 24 - detail
CCD Image (cropped)
Image details as above

Abell 24 - Earlier Image (2016-02-11)
CCD Image
5 x 120s exposure (average combine), 2x2 binning, C filter,
2007-02-17 21:51h UT (#176124-28)
8" LX200 Classic + ST-7E

Back to Top


C/2013 US10 (Catalina) - Comet

C/2013 US10 (Catalina)
(passing through starfield in Camelopardalis)
Sun distance 1.83 AU
CCD Image Montage (Linear Scale, 50% size)
5 x 15s exposure (average combine), 3x3 binning, C Filter
2016-02-19 00:46h UT (#597114-19)
12" LX200R  (at f/10.4) + ST-10XME

C/2013 US10 (Catalina)  - detail
False Colour CCD Image (Log Scale, 50% size)
Inverse Spectrum
Image details as above

CCD Image (Square Root Scale, 50% scale)
Image details as above

C/2013 US10 (Catalina)  - Attempted Colour Image
Colour CCD Image  (Linear Scale, 50% size)
Blue : 6 x 30s, 3x3 binning, B Filter
Green : 3 x 20s, 3x3 binning, V Filter
Red : 3 x 20s, 3x3 binning, R Filter
Frames aligned on comet,
2016-02-19 01:12h UT (#597166-77)
12" LX200R  (at f/10.4) + ST-10XME

C/2013 US10 (Catalina)  - Frames showing Motion over 21 minute period
2016-02-19 00:44 to 01:05h UT
Animation
CCD Image Sequence (Linear Scale, 50% size)
Frames 15s exposures, aligned on comet,
3x3 binning, C Filter
2016-02-19 00:44 to 01:05h UT (#597114-63)
12" LX200R  (at f/10.4) + ST-10XME

CCD Image (Linear Scale, 50% size)
48 x 15s exposure (average combine, aligned on comet),
3x3 binning, C Filter
2016-02-19 00:55h UT (#597114-63)
12" LX200R  (at f/10.4) + ST-10XME

False Colour CCD Image (Log Scale, 50% size)
Inverse Spectrum
Image details as above

C/2013 US10 (Catalina)  - Rotational Gradient Processing
Analysis of rotational gradient processed images show no
evidence of any jets emanating from the comet at time of image
(processing using IRIS [http://www.astrosurf.com/buil/us/iris/iris.htm]
Rotational Gradient Processed CCD Image
(10 deg rotation, Linear Scale, 67% size)
48 x 15s exposure (average combine, aligned on comet),
3x3 binning, C Filter
2016-02-19 00:55h UT (#597114-63)
12" LX200R  (at f/10.4) + ST-10XME

C/2013 US10 (Catalina)  - detail
Rotational Gradient Processed CCD Image
(15 deg rotation, Linear Scale, 77% size)
Image details as above

Back to Top


NGC 2835 - Spiral Galaxy(UGCA 157)

NGC 2835 (Hydra)
Image taken at altitude of only 6.5 deg, galaxy is only just visible due to
high airmass (8.2) and bright moonlight (87% phase)
(At Declination -22d 21m, the highest altitude reached by the galaxy at my site is 10.25 deg)
Alias : UGCA 157
Annotated CCD Image (55% scale)
9 x 30s exposure (average combine), 3x3 binning, C Filter
2016-02-19 01:34h UT (#597188-98)
12" LX200R  (at f/10.4) + ST-10XME

NGC 2835 - detail
CCD Image (100% scale, cropped)
Image details as above

Back to Top


Abell 33 - Planetary Nebula (PLN 238+34.1), attempted imaging

Abell 33 /  PLN 238+34.1  (Hydra)
 Planetary Nebula is unfortunately not visible in the image due to the object's very low
surface brightness and prevailing bright moonlight (87% phase).
The catalogue position and extent of the Pl.Neb is shown by the white circle.
The bright star directly south of the nebula is the mag +7.2 star HIP 47369.
Annotated CCD Image (50% scale)
5 x 30s exposure (average combine), 3x3 binning, C Filter
2016-02-19 01:47h UT (#597206-13)
12" LX200R  (at f/10.4) + ST-10XME

Back to Top


IC 2207 - Spiral Galaxy

IC 2207 (Gemini)
CCD Image (50% scale)
4 x 60s exposure (average combine), 3x3 binning, C Filter
2016-02-19 02:21h UT (#597247-52)
12" LX200R  (at f/10.4) + ST-10XME

IC 2207 - detail
CCD Image (100% scale, cropped)
Image details as above

Back to Top


NGC 4361 - Planetary Nebula

NGC 4361 (Corvus)
Hidden Treasures catalog object 61
[ Hidden Treasures ]
CCD Image (50% size)
5 x 60 sec exposure (average combine), 3x3 binning, C Filter
2016-02-19 02:49hUT (#597263-72)
12" LX200R  (at f/10.4) + ST-10XME

NGC 4361 - detail
CCD Image (100% size, cropped)
Image details as above

NGC 4361 - Earlier Image (2015-04-09)
CCD Image (100% size, cropped)
5 x 60 sec exposure (average combine), 3x3 binning, C Filter
2015-04-09 22:27hUT (#583036-41)
12" LX200R  (at f/10.4) + ST-10XME

Back to Top


C/2014 W2 (PANSTARRS) - Comet

C/2014 W2 (PANSTARRS)
(passing through Cepheus, near boundary with Draco)
Sun Distance 2.68 AU
CCD Image (50% size)
3 x 45 sec exposure (average combine), 3x3 binning, C Filter
2016-02-19 03:26hUT (#597304-07)
12" LX200R  (at f/10.4) + ST-10XME

C/2014 W2 (PANSTARRS)  - wider view
(comet is marked by white cross-lines)
CCD Image (100% size, cropped)
Image details as above

C/2014 W2 (PANSTARRS) - Showing motion over 53 minute period
(motion: 10 arc secs/hour)
Animation
CCD Image Animation (100% scale, cropped)
2 frames, each 3 x 45 sec exposure (average combine), 3x3 binning, C Filter
Frame 1: 2015-04-09 03:26hUT (#597304-07)
Frame 2: 2015-04-09 04:19hUT (#597369-72)
12" LX200R  (at f/10.4) + ST-10XME

Back to Top


9P/Tempel - Comet

9P/Tempel
(passing through starfield in Coma Berenices)
Sun Distance 2.17 AU
Comet is marked by white cross-lines
Measured magnitude +16.3  (vs. forecast mag +14.4)
CCD Image (50% size)
5 x 45 sec exposure (average combine), 3x3 binning, C Filter
2016-02-19 04:10hUT (#597359-65)
12" LX200R  (at f/10.4) + ST-10XME

9P/Tempel  - detail
CCD Image (100% size, cropped)
Image details as above

9P/Tempel - Earlier Image (2005-05-13)
(during an earlier orbit around the sun)
Sun Distance 1.56 AU
CCD Image
3 x 60s (median combine), clear filter
2005-05-13 22:41 h UT (#86123-25)
8" LX200 + ST-7E

Back to Top


NGC 5374 - Spiral Galaxy with SN 2016P

NGC 5374 (Virgo)
CCD Image (50% scale)
2 x 90s exposure (average combine), 3x3 binning, C Filter
2016-02-19 04:27h UT (#597376-77)
12" LX200R  (at f/10.4) + ST-10XME

NGC 5374 - detail, showing SN 2016P

SN 2016P (Type Ic-BL) was discovered 2016/01/19.192 by Grzegorz Duszanowicz and Michal Zolnowski
(Rochester Supernova site | Discovery Image )
The Image below was taken 31 days after discovery.
Supernova 2016P is marked by the white indicator lines
Annotated CCD Image (100% scale, cropped)
Image details as above

Back to Top


NGC 3209 -  Elliptical Galaxy

NGC 3209 (Leo)
NB. Stars are trailed due to mount's uncorrected periodic error
Annotated CCD Image (50% scale)
2 x 90s exposure (average combine), 3x3 binning, C Filter
2016-02-19 04:36h UT (#597382-83)
12" LX200R  (at f/10.4) + ST-10XME

Back to Top


Hickson 61 - Galaxy Cluster (NGC 4169 et al, "The Box")

Hickson 61 (Coma Berenices)
CCD Image (75% scale)
4 x 90s exposure (average combine), 3x3 binning, C Filter
2016-02-19 05:05h UT (#597399-403)
12" LX200R  (at f/10.4) + ST-10XME

Hickson 61 - Earlier Image (2005-03-21)
Annotated CCD Image
3 x 60s exposure (average combine), 2x2 binning, C filter
2004-03-21  23:30 to 23:34 h UT (#63127-29)
8" LX200 + ST-7E

Back to Top
