CCD Images - Session 607 (2017-12-13)

Objects Session Notes
Bullet NGC 936 & NGC 941 - Galaxy Pair (The Tie Fighter Galaxy)
Bullet NGC 1600 - Galaxy Group
Bullet Hickson 19 - Galaxy Cluster (PGC 10262 et al)
Bullet NGC 100 - Spiral Galaxy
Bullet PLN 189+7.1 - Planetary Nebula (Minkowski 1-7)
Bullet Omicron Eri / Beid - Multiple Star
Bullet C/2016 R2 (PANSTARRS) - Comet
Bullet NGC 988 - Spiral Galaxy
Bullet M33 - Spiral Galaxy ("Pinwheel Galaxy")
Bullet PGC 2141552 - Galaxy
Bullet NGC 1555 - Reflection Nebula
Bullet NGC 2237 - Nebula
Bullet C/2017 T1 (Heinze) - Comet
Bullet Hickson 34 - Galaxy Cluster (ARP 327, NGC 1875 et al)
Bullet Iridium Flash
Bullet Geminid Meteors

Bullet Photometric Monitoring - Variables
   - None

Bullet Astrometric Monitoring - Nearby Stars
    - None

Bullet SharpCap Files (S607)

- Evening Session (6 hrs duration).
Clear skies, low wind. Cloud developing towards end of session.
- Session operated under semi-automated control, with remote monitoring from indoors computer.
- Main aims of the session were to provide live testing of VS2017 version of CCDApp2 observatory control program (with cleaned up code), continue testing of dual scope/dual camera operations with autoguiding and acquire images of some selected deep sky objects.
- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  -6 degC (minimum)
- Notes from 2017-12-13 >>


NGC 936 & NGC 941 - Galaxy Pair (The Tie Fighter Galaxy)

Deep Sky Challenge object in Nov 2017 edition of Astronomy Now magazine

NGC 936 & NGC 941 (Cetus)
Galaxy pairing of NGC 936 (lenticular galaxy) and NGC 941 (open spiral galaxy).
CCD Image (50% size)
5 x 120s exposure (average combine), 3x3 binning, C Filter
2017-12-13 20:08h UT (#607006-11)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

NGC 936 & NGC 941- Detail
CCD Image (Log Scale, 100% size, cropped)
Image details as above

False Colour CCD Image (Log Scale, 100% size, cropped)
Image details as above

NGC 936 - Earlier Image
CCD Image (100% size, cropped)
7 x 20s exposure (average combine), 3x3 binning, C Filter
2017-11-02 22:20h UT (#603313-21)
12" LX200R  (at f/10.4) + ST-10XME

Back to Top


NGC 1600 - Galaxy Group

Deep Sky Challenge object in Dec 2017 edition of Astronomy Now magazine

NGC 1600 Galaxy Group (Eridanus)
CCD Image (50% size)
7 x 180s exposure (average combine), 3x3 binning, C Filter
2017-12-13 20:59h UT (#607025-31)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)
[ 100% size ]

NGC 1600 Galaxy Group - Detail
Negative CCD Image (50% size)
Image details as above

NGC 1600 Galaxy Group
( NGC 1600  Catalog Mag +12.0,  NGC 1601 Catalog Mag +15.0,
NGC 1603 Catalog Mag +15.0, NGC 1606 Catalog Mag +14.9,
PGC 177545 Catalog Mag +16.1 )
Annotated CCD Image (50% size)
Image details as above

NGC 1600, NGC 1601, NGC 1603  - Detail
CCD Image (100% size, cropped)
Image details as above

Back to Top


Hickson 19 - Galaxy Cluster

Hickson 19 (Cetus)
( PGC 10262 Catalog Mag +14.4,  PGC 10270 Catalog Mag +15.3,
PGC 10268 Catalog Mag +15.5, PGC 10269 Catalog Mag +17.1,
PGC 953682 Catalog Mag +16.9 )
CCD Image (50% size)
2 x 120s exposure (average combine), 3x3 binning, C Filter
2017-12-13 21:19h UT (#607035-36)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)
[ 100% size ]

Hickson 19 - Detail
Negative CCD Image (50% size)
Image details as above

Back to Top


NGC 100 - Spiral Galaxy

Deep Sky Challenge object in Oct 2017 edition of Astronomy Now magazine

NGC 100 (Pisces)
CCD Image (50% size)
7 x 180s exposure (average combine), 3x3 binning, C Filter
2017-12-13 21:40h UT (#607041-47)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

NGC 100 - detail
CCD Image (100% size, cropped)
Image details as above

NGC 100 - Earlier Image (2017-11-17)
(image affected by wind/poor seeing)
CCD Image (50% size)
5 x 120s exposure (average combine), 3x3 binning, C Filter
2017-11-17 01:27h UT (#605003-09)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

NGC 100 - Earlier Image (2017-11-02)
(low contrast against sky background
full moon just 20 deg away)
CCD Image (50% size)
7 x 30s exposure (average combine), 3x3 binning, C Filter
2017-11-02 20:09h UT (#603130-43)
12" LX200R  (at f/10.4) + ST-10XME

Back to Top


PLN 189+7.1 - Planetary Nebula (Minkowski 1-7)

Deep Sky Challenge object in Feb 2017 edition of Astronomy Now magazine

PLN 189+7.1 (Gemini)
CCD Image (50% size, Linear Scaling)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2017-12-13 22:04h UT (#607052-66)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

PLN 189+7.1 - detail
CCD Image (100% size, Square Root Scaling, cropped)
Image details as above

Back to Top


 Omicron Eri / Beid - Multiple Star

Omicron Eri / Beid (Eridanus)
CCD Image (50% size)
3 x 2s exposure (average combine), 3x3 binning, C Filter
2017-12-13 22:13h UT (#607063-66)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)


Back to Top


C/2016 R2 (PANSTARRS) - Comet

C/2016 R2 (PANSTARRS)
(passing through Gemini)
Sun distance 3.02 AU
(Bright object in upper-left corner of the image is the
+7.2 mag star HIP 22221)
CCD Image (50% size, Linear Scaling)
2 x 60s exposure (average combine), 3x3 binning, C Filter
2017-12-13 22:29h UT (#607079-80)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

C/2016 R2 (PANSTARRS) - detail
Image demonstrates motion of comet against background stars
CCD Image (100% size, Linear Scaling)
9 x 60s exposure (average combine), 3x3 binning, C Filter
Frames aligned on combine before stacking
2017-12-13 22:21 to 22:34h UT (#607073-83)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

C/2016 R2 (PANSTARRS) - detail
Image demonstrates size of comet's Coma
CCD Image (100% size, Linear Scaling)
3 x 180s exposure (average combine), 3x3 binning, C Filter
Frames aligned on stars before stacking
2017-12-13 22:40 hUT (#607084-86)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

Back to Top


NGC 988 - Spiral Galaxy

NGC 988 (Cetus)
(Bright foreground object is the +7.1 mag star HIP 12055)
CCD Image (50% size, Linear Scaling)
3 x 120s exposure (average combine), 3x3 binning, C Filter
2017-12-13 22:53h UT (#607089-92)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

NGC 988 - detail
CCD Image (100% size, Linear Scaling)
Image details as above

Back to Top


M33 - Spiral Galaxy ("Pinwheel Galaxy")

M33 (Triangulum)
CCD Image (75% size)
6 x 180s exposure (average combine), 3x3 binning, C Filter
2017-12-13 23:23h UT (#607096-101)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

M33 - Earlier Image (2016-11-18)
(image frames affected by wind/poor seeing, and demonstrate the limitation of
operating my 12" LX200 from roll-roof designe observatory )
CCD Image (75% size)
4 x 120s exposure (average combine), 3x3 binning, C Filter
2017-11-18 01:45hUT (#605014-19)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

M33 - Earlier Image (2006)
Image taken under much better sky conditons
CCD Image Mosaic (cropped)
3 min exposure , 2x2 binning, C Filter
2006-11-16 22:24 h UT (#152233-45)
8" LX200 Classic + ST-7E

Back to Top


PGC 2141552 - Galaxy

PGC 2141552 (Andromeda)
(Catalog Mag +17.1)
CCD Image (100% size, cropped)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2017-12-13 23:55h UT (#607109-11)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

Back to Top


NGC 1555 - Reflection Nebula

NGC 1555 (Taurus)
CCD Image (50% size)
6 x 90s exposure (average combine), 3x3 binning, C Filter
2017-12-14 00:13h UT (#607114-19)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)


Back to Top


NGC 2237 - Nebula

NGC 2237 (Monoceros)
Part of the Rosette Nebula
CCD Image (75% size)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2017-12-14 00:47h UT (#607138-42)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)
[ 100% size, 50% size ]

Back to Top


C/2017 T1 (Heinze) - Comet

C/2017 T1 (Heinze)
(passing through Hydra)
Sun distance 1.49 AU
CCD Image (50% size, Linear Scaling)
6 x 45s exposure (average combine), 3x3 binning, C Filter
2017-12-14 00:35h UT (#607129-35)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

C/2017 T1 (Heinze) - detail
CCD Image (100% size, Aligned on Comet, Cropped)
Image details as above


Back to Top


Hickson 34 - Galaxy Cluster (NGC 1875 et al, ARP 327)

Hickson 34 / ARP 327 (Orion)
NGC 1875 Catalog Mag +13.7,  PGC 17173 Catalog Mag +18.5,
PGC 17175 Catalog Mag +17.4, PGC 17176 Catalog Mag +17.3
Annotated CCD Image (100% size, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2017-12-14 01:13h UT (#607149-53)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

Hickson 34 / ARP 327 - detail
Negative CCD Image (150% size, cropped)
Image Details as above

Back to Top


Iridium Flash

Meteor or Iridium Flash - 2017-12-13 17:37hUT
The path/orientation of the event shows that it can't be a Geminid meteor
but could it be a sporadic meteor ?
Annotated All Sky Camera Image (50%)
See picture for details on time/exposure
(Image taken with Oculus All Sky Camera)

Meteor or Iridium Flash
Difference Images ('frame' - 'frame before') can be used to examine whether the object
is likely to be meteor rather than an Iridium satellite flash.
The sequence of Diff. Images below suggest that there is a trace of an object
leading out of the main event - After 1 contains a narrow white trace leading to the right
After 2 contains a corresponding black trace.
This implies the event is almost certainly an Iridium Flash.
All Sky Camera Image (100%, cropped)
Image Details as above

Back to Top


 Geminid Meteors

Geminid Meteor - 2017-12-14 05:46hUT
(geminid meteor radiant marked with white cross)
Annotated All Sky Camera Image (50%)
See picture for details on time/exposure
(Image taken with Oculus All Sky Camera)
[ Annotated Image ]

Panoramic View - Northern Sky
Image details as above

More Geminid Meteors - 2017-12-13 21:19 to 2017-12-14 07:06hUT
19 meteors in 12 hours
Image   Image

Image   Image

Image   Image

Image   Image

Image   Image

Image   Image

Image   Image

Image   Image

Image   Image
Annotated All Sky Camera Images (75% size, cropped)
(Images taken with Oculus All Sky Camera)

Back to Top


SharpCap Files (S607)

SharpCap Session - 2017-12-13 S00607

ObjectFolderCapture
Area
Colour
Space
BinExpGainGammaTemp.
(C)
Subtract
Dark
Output
Format
Num
Frames
Stacked
Frames
Total
Exp
Num
.fits
Raw
.fits
Num
.png
Proc
.png
Num
.ser
M4519_33_40Z3096x2080RAW16310s400505.0FITS110000
Pointing------------------
