EV Lac - Nearby Star (GJ 873, 16.5 ly)     Hickson 80 - Galaxy Cluster (PGC 56588 et al) Hickson 88 - Galaxy Cluster (NGC 6977 et al) Hickson 94 - Galaxy Cluster (NGC 7578 et al, ARP 170)     Photometric Monitoring - Variables     - None    (TT ARI attempt failed due to cloud)     Astrometric Monitoring - Nearby Stars     - EV Lac

- Late Night Session (1.1 hrs duration). Initially clear , but clouds rolled in after 1 hour - Session conducted as a Fully Automated Run. (Session was monitored remotely in order to observe target centering which had been problematic in last session and look out for any further instances of Error 203 problem or blue screen crashes that had affected the last session badly). - Main aim of the session was to confirm that target centering was working and wasn't affected by the issue that had caused problems during the last session (S618). Secondary aims were to acquire images of a selection of deep sky, variable star & nearby star targets and perform a further test of fully automated observatory operations. - 12" LX200 + ST-10XME for imaging - TS 80mm APO + ZWO ASI178MC for guiding - Ambient Temperature:  9 degC (minimum) - CCD Temperature:  -15 degC (78% av. power) - Notes from 2018-08-19 >>

EV Lac  - Nearby Star (GJ 873, 16.5 ly)

EV Lac (Lacerta)

CCD Image (35% size) 5 x 60 sec exposure (average combine), 3x3 binning, C Filter 2018-08-19 23:16 UT (#619003-09) 12" LX200R  (at f/10.4) + ST-10XME

EV Lac - detail

Annotated CCD Image (54% size, cropped) Image details as above

EV Lac - earlier image (2008)

Annotated CCD Image (75% size, cropped) 7 x 45 sec exposure (average combine), 1x1 binning, C Filter 2008-08-26 00:52 UT (#297206-12) 8" LX200 + ST-7E

Back to Top

Hickson 80 - Galaxy Cluster (PGC 56588 et al)

Hickson 80 (Draco)

CCD Image (75% size, cropped) 4 x 180 sec exposure (average combine), 3x3 binning, C Filter 2018-08-19 23:29 UT (#619012-15) 12" LX200R  (at f/10.4) + ST-10XME

Hickson 80 & Adjacent Galaxies PGC 2675242 (catalog mag +17.3), PGC 2675868 (catalog mag +17.5)

CCD Image (Linear Scaled, 100% size, cropped) Image details as above

Hickson 80 - Detail a) PGC 56588 (catalog mag +15.6), b)  PGC 56590 (catalog mag +16.4), c) PGC 56572 (catalog mag +16.3), d)  PGC 56577 (catalog mag +17.4)

Annotated CCD Image (100% size, cropped) Image details as above

Negative CCD Image (100% size, cropped) Image details as above

Back to Top

Hickson 88 - Galaxy Cluster (NGC 6977 et al)

Hickson 88 (Aquarius)

CCD Image (75% size, cropped) 5 x 180 sec exposure (average combine), 3x3 binning, C Filter 2018-08-19 23:46 UT (#619017-21) 12" LX200R  (at f/10.4) + ST-10XME

Hickson 88 - Detail a) NGC 6978 (catalog mag +14.1), b)  NGC 6977 (catalog mag +13.3), c) NGC 6976 (catalog mag +14.0), d)  PGC 65612 (catalog mag +15.8)

Annotated CCD Image (75% size, cropped) Image details as above

Negative CCD Image (75% size, cropped) Image details as above (Full Size Image)

Back to Top

Hickson 94 - Galaxy Cluster (NGC 7578 et al)

Hickson 94 (Pegasus)

CCD Image (75% size, cropped) 4 x 180 sec exposure (average combine), 3x3 binning, C Filter 2018-08-20 00:07 UT (#619026-29) 12" LX200R  (at f/10.4) + ST-10XME

CCD Image (100% size, cropped) Image details as above

Hickson 94 - Detail a) NGC 7578A (catalog mag +13.3 or +14.7), b)  NGC 7578B (catalog mag +14.0), c) PGC 70943 (catalog mag +16.2), d)  PGC 70936 (catalog mag +16.3) e) PGC 70937 (catalog mag +17.7), f)  PGC 70939 (catalog mag +18.2) g)  PGC 70941 (catalog mag +18.4)

Annotated CCD Image (150% size, cropped) Image details as above

Negative CCD Image (150% size, cropped) Image details as above
