Objects Session Notes
C/2019 Y4 (ATLAS) - Comet IC 1222 - Spiral Galaxy (ARP 73) with SN 2020enm NGC 5157 - Spiral Galaxy with Type 1a SN 2020ees NGC 4636 - Elliptical Galaxy, with Type Ia Supernova 2020ue UGC 6334 - Spiral Galaxy (PGC 34656) UGC 7576 - Spiral Galaxy (PGC 40900) UGC 9796 - Spiral Galaxy (PGC 54461) Variable Stars (photometric monitoring) - AM CVn
- U Her attempt failed due to too few stars/link failureNearby Stars (astrometric monitoring) - None
- All night session (6.8 hours total).
- Main aims of the session was to acquire images of a selection of deep sky and comet objects - 12" LX200 + ST-10XME for imaging - TS 80mm APO + ZWO ASI178MC for guiding & imaging - Ambient Temperature: -1.5°C (min)
(Dew heaters on auto)- CCD Temperature: -25°C (69% av. power) - Notes from 2020-04-16 >>
| C/2019 Y4 (ATLAS) - 2020-04-16 (passing through Camelopardalis) Sun Distance 1.17 AU (approaching) Earth Distance 0.99 AU (148.3 million km) |
C/2019 Y4 (ATLAS) - 2020-04-16, Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -184.02 arcsec/hr, Dec -45.57 arcsec/hr) |
|
 |
 |
|
| CCD Image (50% size, square root scale) 3 x 45s exposure (average combine), 3x3 binning, C Filter 2020-04-16 21:20 UT (#768003-05) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (100% size, log scale, cropped) 25 x 45s exposure (average combine), 3x3 binning, C Filter 2020-04-16 21:29 UT (#768003-27) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of C/2019 Y4 (ATLAS) on Comets 2020 Page >> |
| C/2019 Y4 (ATLAS) - 2020-04-16 |
 |
| CCD Image (70% size, square root scale) 25 x 45s exposure (average combine), 3x3 binning, C Filter 2020-04-16 21:29 UT (#768003-27) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
 |
| False Color CCD Image (70% size, square root scale) Image details as above |
 |
| CCD Image (70% size, log scale) Image details as above |
| C/2019 Y4 (ATLAS) - 2020-04-16 Indications of comet fragmentation |
 |
| CCD Image (100% size, linear scale, cropped) Unsharp Masked (um4) Image details as above |
 |
| CCD Image (150% size, linear scale, cropped) Unsharp Masked (um4) Image details as above |
Back to Top
| IC 1222 with SN 2020enm (Hercules) IC 1222 (catalog mag +13.4), aliases ARP 73, PGC 58544 SN 2020enm (Type Ia-99a SN) discovered 2020/03/16.913 by Xingming Observatory Sky Survey (XOSS) (Rochester Supernova site | Discovery Image | mag +17.7 V at discovery) |
| IC 1222 with SN 2020enm - 2020-04-16 (T+31.0d) Image (2020-04-16.913) taken 31.0 days after SN discovery. SN shown by white cross hairs. Measured Magnitude +17.2 |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, C Filter 2020-04-16 21:54 UT (#768030-34) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2020enm (IC 1222) on Supernovae 2020 Page >> |
Back to Top
| NGC 5157 with SN 2020ees (Canes Venatici) SN 2020ees (Type 1a), discovered 2020/03/05.472 by ATLAS (Rochester Supernova site | Odd Trondal image ) Image below (2020-04-16.928) was taken 42.46 days after discovery of SN 2020ees SN is shown by white cross hairs. Estimated SN magnitude +16.9 |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, C Filter 2020-04-16 22:17 UT (#768037-41) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 5157 with SN 2020ees - Earlier Image (2020-03-27) Image below (2020-04-06.948) was taken 32.48 days after discovery of SN 2020ees SN is shown by white cross hairs. Estimated SN magnitude +16.7 Image taken under very poor sky conditions, thin cloud & moonlight |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2020-04-06 22:45 UT (#766021-25) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 5157 with SN 2020ees - Earlier Image (2020-03-27) Image below (2020-03-27.928) was taken 22.46 days after discovery of SN 2020ees SN is shown by white cross hairs. Estimated SN magnitude +16.4 |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2020-03-27 22:17 UT (#764081-85) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 5157 with SN 2020ees - Earlier Wide View (2020-03-27) SN 2020ees, Type 1a Supernova Other galaxies in view : PGC 47206 (catalog mag +15.5), PGC 1972782 (+17.8), PGC 1978267 (+17.9), PGC 1977070 (+18.0), PGC 1979392 (+18.1) |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2020-03-27 22:17 UT (#764081-85) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
| NGC 4636 with SN 2020ue (Virgo) SN 2020ue Type1a discovered 2020/01/12.722 by Koichi Itagaki (Rochester Supernova site | Discovey Image, K.Itagaki | SN 2020ue sub-page | |
| NGC 4636 with SN 2020ue - 2020-04-16 (T+95.2d) Image below (2020-04-16.946) was taken 95.2 days after discovery of SN 2020ue Estimated SN magnitude +15.6 (calibrated) |
 |
| Annotated CCD Image (100% size, log scale, cropped) 2 x 180s exposure (average combine), 3x3 binning, C Filter 2020-04-16 22:42 UT (#768046-48) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2020ue (NGC 4636) on Supernovae 2020 Page >> |
Back to Top
| UGC 6334 (Ursa Major) Ring Galaxy, J.Lowrey List Alias: PGC 34656 Note: image shows a satellite track crossing the field of view |
 |
| CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2020-04-16 23:13 UT (#768056-60) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 6334 - Detail |
 |
| CCD Image (100% size, square root scale, cropped) Image details as above |
 |
| Negative CCD Image (100% size, square root scale, cropped) Image details as above |
| UGC 6334 - Earlier Image (2020-04-13) Note: single frame only due to cloud, ring structure is not discernable |
 |
| CCD Image (100% size, square root scale, cropped) 180s exposure (single frame), 3x3 binning, C Filter 2020-04-13 22:14 UT (#767030) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
| UGC 7576 (Coma Berenices) Ring Galaxy, J.Lowrey List UGC 7576 / PGC 40900 (catalog mag +16.6) |
 |
| CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2020-04-16 23:35 UT (#768063-67) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
 |
| Negative CCD Image (125% size, square root scale, cropped) Image details as above |
| UGC 7576 - Earlier Image (2020-04-14) |
 |
| CCD Image (125% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, C Filter 2020-04-14 00:36 UT (#767077-81) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 7576 - Earlier Wider View (2020-04-14) UGC 7576 / PGC 40900 (catalog mag +16.6) with several adjacent galaxies : NGC 4448 / H I-91 (catalog mag +11.2), PGC 1843133 (catalog mag +16.1) PGC 40901 (catalog mag +16.9), PGC 1843743 (catalog mag +17.0) PGC 1841207 (catalog mag +17.9), PGC 1843788 (catalog mag +18.8) |
 |
| Annotated CCD Image (50% size, square root scale) 4 x 180s exposure (average combine), 3x3 binning, C Filter 2020-04-14 00:36 UT (#767077-81) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
| UGC 9796 (Bootes) Ring Galaxy, J.Lowrey List UGC 9796 / PGC 54461 (catalog mag +16.1) with several adjacent galaxies : PGC 54478 (catalog mag +16.3), PGC 2214734 (catalog mag +17.4) PGC 2214320 (catalog mag +17.7), PGC 2215545 (catalog mag +18.1)) |
 |
| Annotated CCD Image (50% size, square root scale) 3 x 180s exposure (average combine), 3x3 binning, C Filter 2020-04-17 00:57 UT (#768089-91) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 9796 - Detail |
 |
| CCD Image (125% size, square root scale, cropped) Image details as above |
 |
| Negative CCD Image (125% size, square root scale, cropped) Image details as above |
Back to Top
