NGC 514 - Spiral Galaxy with Type Ia Supernova 2020uxz     Variable Stars (photometric monitoring) - RX And, U And, TT Ari, SS Cyg, DY Per       Nearby Stars (astrometric monitoring) - HH And, Teegardens Star

- Post-midnight night session (2.0 hours total) - Main aims of the session were the acquisition of a selection of deep sky targets, together with some variable star, nearby star and comet targets (if conditions allowed) - Session affected by problems with stalling of dome data (twice) and an issue due to CCDSoft not saving images from 23:57 onwards - 12" LX200 + ST-10XME for imaging - TS 80mm APO + ZWO ASI178MC for guiding & imaging - Ambient Temperature: 10°C (min), but warming later - CCD Temperature:  -15°C (-10°C later) - Notes from 2020-10-06 >>      -

NGC 514 - Spiral Galaxy with Type Ia Supernova 2020uxz

NGC 514 (Pisces) SN 2020uxz (Type 1a), discovered 2020/10/05.573 by Koichi Itagaki  (Rochester Supernova site | Discovery Image | )

NGC 514 with SN 2020uxz -2020-10-07 am (T+1.5d) Image below (2020-10-07.067) was taken 1.48 days after discovery of SN 2020uxz SN is shown by white cross hairs.  Magntitude +15.7

Annotated CCD Image  (100% size, square root scale, cropped) 4 x 120s exposure (average combine), 3x3 binning, C Filter 2020-10-07 01:14 UT (#816042-46) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 514 with SN 2020uxz - Detail

CCD Image  (100% size, square root scale, cropped) Image details as above

Negative CCD Image (100% size, square root scale, cropped) Image details as above

Images of SN 2020uxz (NGC 514) on Supernovae 2020 Page >>
