Objects Session Notes
- Post-midnight session 6.5 hours - Session start delayed due to cloud & snow shower - Session interrupted for 20 mins due to 'invalid' CloudSensor readings (rain and cloud/poor clarity) after accidently getting warm water onto the sensors whilst clearing snow cover from northern side of the AllSky Camera. - Session interrupted for 20 mins due to 'invalid' CloudSensor readings (rain and cloud/poor clarity) after accidently getting warm water onto the sensors whilst clearing snow cover from northern side of the AllSky Camera. Aurora activity observed from 2022-02-10 23:10 UT (time of first clear view of northern sky) and 2022-02-11 03:25 UT - 12" LX200 + ST-10XME for imaging - TS 80mm APO + ZWO ASI178MC for guiding & imaging - Ambient Temperature: -4°C (min) - CCD Temperature: -25°C - Notes from 2022-02-10 >> [ Local Files >> ] - Aurora Images/Video from 2022-02-10 >>
| 67P/Churyumov-Gerasimenko (passing through Cancer) Sun Distance 1.71 AU (receeding) Earth Distance 0.75 AU (112.5 million km) |
67P/Churyumov-Gerasimenko - 2022-02-11, Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -15.43 arcsec/hr, Dec -10.87 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 3 x 45s exposure (average combine), 3x3 binning, C Filter 2022-02-11 02:35 UT (#969100-02) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, log scale, cropped) 15 x 45s exposure (average combine), 3x3 binning, C Filter 2022-02-11 02:40 UT (#969100-14) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of 67P/Churyumov-Gerasimenko on Comets 2022 Page >> |
| 67P/Churyumov-Gerasimenko - False Colour Image(s) Inverse Spectrum |
| 67P/Churyumov-Gerasimenko - 2022-02-11 |
 |
| False Colour CCD Image (70% size, log scale) 15 x 45s exposure (average combine), 3x3 binning, C Filter 2022-02-11 02:40 UT (#969100-14) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
| 70P/Kojima (passing through Virgo) Sun Distance 2.16 AU Earth Distance 1.27 AU (190.5 million km) |
70P/Kojima - 2022-02-11, Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -8.16 arcsec/hr, Dec 17.07 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 7 x 60s exposure (average combine), 3x3 binning, C Filter 2022-02-11 00:07 UT (#969026-32) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (100% size, square root scale, cropped) Image details as left |
|
| Images of 70P/Kojima on Comets 2022 Page >> |
Back to Top
| C/2017 K2 (PANSTARRS) (passing through Ophiuchus) Sun Distance 4.02 AU (approaching) Earth Distance 4.54 AU (678.7 million km) |
C/2017 K2 (PANSTARRS) - 2022-02-11, Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 26.55 arcsec/hr, Dec -2.61 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 3 x 45s exposure (average combine), 3x3 binning, C Filter 2022-02-11 05:27 UT (#969195-97) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (100% size, square root scale, cropped) 9 x 45s exposure (average combine), 3x3 binning, C Filter 2022-02-08 06:01 UT (#966107-15) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of C2017 K2 (PANSTARRS) on Comets 2021 Page >> | ||
| Images of C2017 K2 (PANSTARRS) on Comets 2022 Page >> |
Back to Top
| C/2019 L3 (ATLAS) (passing through Gemini) Sun Distance 3.57 AU (turning) Earth Distance 2.78 AU (416.4 million km) |
C/2019 L3 (ATLAS) - 2022-02-11, Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -16.60 arcsec/hr, Dec -29.62 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 3 x 45s exposure (average combine), 3x3 binning, C Filter 2022-02-11 02:21 UT (#969089-91) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (100% size, log scale, cropped) 9 x 45s exposure (average combine), 3x3 binning, C Filter 2022-02-11 02:24 UT (#969089-97) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of C/2019 L3 (ATLAS) on Comets 2022 Page >> |
| C/2019 L3 (ATLAS) - False Colour Inverse Spectrum |
|
C/2019 L3 (ATLAS) - 2022-02-11 Affected by uneven moonlit sky background |
 |
| False Colour CCD Image (70% size, log scale) 9 x 45s exposure (average combine), 3x3 binning, C Filter 2022-02-11 02:24 UT (#969089-97) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
| Nova Cas 2021 (Cassiopeia) Nova in Cassiopeia discovered 2021-03-18.4236, by Yuji Nakamura (Japan) Magnitude at discovery +9.6 (unfiltered CCD) AT2021hkn (Type: Nova) reported by 2021/03/30.055 UT by Gaia Alias: Gaia21bpe, AT2021hkn, V1405 Cas |
| Nova Cas 2021 / AT2021hkn - 2022-02-11 (T+329.8d) Image below (2022-02-11.199) was taken 329.8 days after discovery of Nova Nova is shown by white cross hairs. Measured magnitude +9.60 (linked with Detection Threshold = 50 |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 5 x 30s exposure (average combine), 3x3 binning, C Filter 2022-02-11 04:48 UT (#969162-66) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Nova Cas 2021 (V1405 Cas) Spectra - 2022-02-11 (T+329.8d) |
 |
| Spectra produced in AstroMain using Image taken with Star Analyser
200 5 x 45s exposure (average combine), 2x2 binning, S Filter 2022-02-11 04:52 UT (#969167-71) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of Nova Cas 2021 on Novae Page >> |
Back to Top
| AT2022jw (Hercules) AT2022jw (Type: CV) discovered 2022-01-08.702 UT by Gaia Alias: Gaia22acy 5 mag outburst in candidate CV Alert triggered at mag 13.26 (vs historic magnituude 17.97) (Rochester Supernova site | TNS 2022jw | Gaia22acy ) |
| AT2022jw - 2022-02-11 (T+33.5d) Image below (2022-02-11.208) was taken 33.5 days after discovery of 2022jw Position of reported transient (faint) is shown by white cross-hairs Measured magnitude +18.3 Transient has faded back to historic levels |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, C Filter 2022-02-11 05:04 UT (#969174-78) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT2022jw on Transients 2022 Page |
Back to Top
| IC 635 with AT2022bqu (Leo) AT2022bqu (Type: AGN) discovered 2022-02-06.907 UT by XOSS Alias: XM101HT (Rochester Supernova site, TNS 2022bqu ) |
| IC 635 - Spiral Galaxy |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 02:59 UT (#969117-21) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| IC 635 with AT2022bqu - 2022-02-11 (T+4.2d) Image below (2022-02-11.117) was taken 4.2 days after discovery of 2022bqu Position of reported transient is shown by white cross-hairs. Measured magnitude +15.43 |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 02:59 UT (#969117-21) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT2022bqu (IC 635) on Transients 2022 Page |
Back to Top
| NGC 3628 with AT2022brm (Leo) AT2022brm (Type: unk) discovered 2022-02-08.962 UT by Dumitru Ciprian Alias: Barlad V2 Discovery magnitude +16.1 (Rochester Supernova site, TNS 2022brm ) |
|
NGC 3628 with AT2022brm (T+2.1d) Position of reported transient (not visible) is shown by white cross-hairs. |
 |
| Annotated CCD Image (70% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 01:10 UT (#969051-55) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 3628 with AT2022brm - 2022-02-11 (T+2.1d) Image below (2022-02-11.042) was taken 2.1 days after discovery of 2022brm Position of reported transient (not visible) is shown by white cross-hairs. |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 01:10 UT (#969051-55) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT2022brm (NGC 3628) on Transients 2022 Page >> |
| NGC 3628 - False Colour Image |
 |
| False Colour CCD Image (70% size, square root scale) Inverse Spectrum Image details above |
| NGC 3628 - Earlier Image (2022-02-09) |
 |
| CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-09 23:19 UT (#968144-48) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 3628 - Earlier Image (Jan 2019) |
 |
| CCD Image (50% size, square root scale) 4 x 180s exposure (average combine), 3x3 binning, C Filter 2019-01-03 03:58 UT (#647416-20) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
| NGC 4165 (Virgo) |
| NGC 4165 with adjacent galaxies |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 01:30 UT (#969058-62) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 4165 with SN2021gno (Virgo) SN 2021gno (Type: II) discovered 2021/03/20.235 UT by ZTF Alias: ZTF21aaqhhfu ( Rochester Supernova site | Claudio Balcon image | Giancarlo Cortini image ) |
| NGC 4165 with SN2021gno - 2022-02-11 (T+327.8d) Image below (2022-02-11.056) was taken 327.8 days after discovery of 2021gno Position of earlier SN (no longer visible) is shown by white cross hairs. |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 01:30 UT (#969058-62) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 4165 with SN2021gno - Earlier image, 2021-04-01 (T+12.7d) Image below (2021-04-01.940) was taken 12.7 days after discovery of 2021gno SN is shown by white cross hairs. |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2021-04-01 22:43 UT (#879054-58) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2021gno (NGC 4165) on Supernovae 2021 Page >> |
Back to Top
| NGC 4348 with SN2022fw (Virgo) SN 2022fw (Type: Ia) discovered 2022-01-09.490 UT by ASAS-SN Alias: ASASSN-22am (Rochester Supernova site | TNS 2022fw ) |
| NGC 4348 |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 04:07 UT (#969138-42) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 4348 with SN2022fw - 2022-02-11 (T+32.7d) Image below (2022-02-11.165) was taken 32.7 days after discovery of 2022fw Position of reported SN (bright) is shown by white cross-hairs Measured magnitude +14.12 |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 04:07 UT (#969138-42) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022fw (NGC 4348) on Supernovae 2022 Page >> |
Back to Top
| NGC 5117 with SN2022abq (Canes Venatici) SN 2022abq (Type: II) discovered 2022-01-21.050 UT by F. Cappiello, S. Massaro Alias: Ric7-2022abqGBObs, ATLAS22cks (Rochester Supernova site | TNS 2022abq ) |
| NGC 5117 with SN2022abq - 2022-02-11 (T+21.2d) Image below (2022-02-11.234) was taken 21.2 days after discovery of 2022abq Position of SN is shown by white cross-hairs Measured magnitude +15.80 |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 05:45 UT (#969206-09) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022abq (NGC 5117) on Supernovae 2022 Page |
Back to Top
| UGCA 258 with SN2022mm (Corvus) SN 2022mm (Type: II) discovered 2022-01-11.647 UT by ATLAS Alias: ATLAS22bjw (Rochester Supernova site | TNS 2022mm ) [ UGCA Galaxies ] [ Irregular Galaxies ] |
| UGCA 258 with SN2022mm - 2022-02-11 (T+30.5d) Image below (2022-02-11.149) was taken 30.5 days after discovery of 2022mm Position of SN (faint) is shown by white cross-hairs |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 03:43 UT (#969131-35) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022mm (UGCA 258) on Supernovae 2022 Page >> |
Back to Top
| UGC 522 with SN 2022bqt (Andromeda) SN 2022bqt (Type: Ic-BL) discovered 2022-02-08.235 UT by ATLAS Alias: ATLAS22ffi Discovery Magnitude +18.40 (Rochester Supernova site, TNS 2022bqt ) |
| UGC 522 |
 |
| Annotated CCD Image (50% size, square root scale) 4 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 00:25 UT (#969037-40) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 522 with SN 2022bqt - 2022-02-11 (T+2.8d) Image below (2022-02-11.012) was taken 2.8 days after discovery of 2022bqt Position of reported transient is shown by white cross-hairs. |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 00:25 UT (#969037-40) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022bqt (UGC 522) on Supernovae 2022 Page >> |
Back to Top
| UGC 4671 with SN 2021afsj (Ursa Major) SN 2021afsj (Type: Ia) discovered 2021-11-29.718 UT by Shuji Tokuoka Alias: Gaia21flf, ZTF21acqstfo ( Rochester Supernova site | Gaia21flf ) |
| UGC 4671 with SN 2021afsj - 2022-02-11 (T+73.4d) Image below (2022-02-11.080) was taken 73.4 days after discovery of 2021afsj Position of SN is shown by white cross-hairs Measured magnitude ?? (unable to resolve object in Sextractor)) |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 02:05 UT (#969082-86) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2021afsj (UGC 4671) on Supernovae 2021 Page >> |
Back to Top
| UGC 6014 with AT 2022bil (Leo) AT2022bil (Type: MP) discovered 2022-02-02.029 UT by MASTER Alias: MASTER OT J105342.41+094343.9, MP 1642 Hill (Rochester Supernova site, TNS 2022bil ) |
| UGC 6014 - Spiral Galaxy |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 03:23 UT (#969124-28) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 6014 with AT 2022bil - 2022-02-11 (T+9.1d) Image below (2022-02-11.134) was taken 9.1 days after discovery of 2022bil Position of reported transient is shown by white cross-hairs. |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 03:23 UT (#969124-28) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022bil (UGC 6014) on Transients 2022 Page >> |
Back to Top
| SN 2022bnf (Ursa Major) SN 2022bnf (Type: Ia) discovered 2022-02-05.837 UT by XOSS Alias: XM99HT Discovery magnitude +15.79. Potential host galaxy: WISEA J084058.13+484413.2 (Host redshift: 0.05736) (Rochester Supernova site, TNS 2022bnf ) |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 00:50 UT (#969044-48) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| SN 2022bnf - 2022-02-11 (T+5.2d) Image below (2022-02-11.028) was taken 5.2 days after discovery of 2022bnf Position of reported transient is shown by white cross-hairs. Measured magnitude +15.42 |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 00:50 UT (#969044-48) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| SN 2022bnf - Reference Image (DSS2 Color) The reported SN position is shown by purple cross hairs. Object corresponds to the position of the galaxy 2MASX J08405808+4844120 (r mag 15.628) (equivalent to WISEA J084058.13+484413.2) |
 |
| DSS2 Image, screen captured via Aladin |
| Images of SN 2022bnf (WISEA J084058.13+484413.2) on Supernovae 2022 Page >> |
Back to Top
| UGCA 258 with SN2022mm (Corvus) SN 2022mm (Type: II) discovered 2022-01-11.647 UT by ATLAS Alias: ATLAS22bjw (Rochester Supernova site | TNS 2022mm ) [ UGCA Galaxies ] [ Irregular Galaxies ] |
| UGCA 258 with SN2022mm - 2022-02-11 (T+30.5d) Image below (2022-02-11.149) was taken 30.5 days after discovery of 2022mm Position of SN (faint) is shown by white cross-hairs |
|
|
| CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-02-11 03:43 UT (#969131-35) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGCA 258 with SN2022mm - Earlier Image 2022-01-29 (T+17.4d) Image below (2022-01-29.090) was taken 17.4 days after discovery of 2022mm No sign of SN transient at reported position indicated by white cross-hairs SN has either faded & is no longer visible or more likely it is not distinguishable due to poor image quality (due to poor seeing) |
 |
| CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-01-29 02:19 UT (#961089-93) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
