David's Astronomy Pages
CCD Images - Session 1048 (2022-10-22)
Images
(S1047)
Images
Main
Home
Page
Images
(S1049)
David's Astronomy Pages
|
Images (S1047) |
Images Main |
Home Page |
Images (S1049) |
Objects Session Notes
Jupiter - Planet C/2020 V2 (ZTF) - Comet AT 2022qnv - Type YSO Transient AT 2022tqu - Type Nova Transient AT 2022vxe - Type YSO? Transient AT 2022whd - CV Type Transient AT 2022why - Type Nova? Transient NGC 3938 - Spiral Galaxy with Type Ia-02cx Supernova 2022xlp NGC 5894 - Spiral Galaxy with Type II Supernova 2022pgf NGC 7448 - Spiral Galaxy with Type II Supernova 2022wsp NGC 7495 - Spiral Galaxy with Type II Supernova 2022ubb UGC 3923 - Spiral Galaxy with Transient AT 2022rqc Variable Stars (photometric monitoring) - SY Cnc, SS Cyg, BL Lac, GK Per, V Sge Nearby Stars (astrometric monitoring) - None
- Attempted All Night session (6.7h). - 12" LX200 + ST-10XME for imaging - TS 80mm APO + ZWO ASI178MC for guiding & imaging - Ambient Temperature: 12°C (min) - CCD Temperature: -10°/ -15° C - Notes from 2022-10-22 >> [ Local Files >> ]
| Jupiter (passing through Pisces) Sun Distance 4.95 AU Earth Distance 4.06 AU (607.4 million km) |
| Jupiter - V Band (BVR Colour Image not feasible as R images (0.12s) were saturated) |
 |
| CCD Image (100% size, cropped, unsharp masked) Combined Image from 10 frames 10 x 0.12s exposure (average combine), 1x1 binning, V Filter 2022-10-22 23:18 UT (#1048029-38) 12" LX200R (at f/10.4) + ST-10XME |
| Jupiter Moons |
 |
| Annotated CCD Image (70% size, linear scale) 5 x 0.2s exposure (average combine), 3x3 binning, V Filter 2022-10-22 23:16 UT (#1048014-18) 12" LX200R (at f/10.4) + ST-10XME |
Back to Top
| C/2020 V2 (ZTF) - 2022-10-23 (passing through Ursa Major) Sun Distance 3.13 AU (approaching) Earth Distance 3.19 AU (477.9 million km) |
C/2020 V2 (ZTF) - 2022-10-23 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 24.73 arcsec/hr, Dec 35.31 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 3 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-10-23 01:17 UT (#1048074-76) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, log scale, cropped) 15 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-10-23 01:25 UT (#1048074-88) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of C/2020 V2 (ZTF) on Comets 2022 Page >> |
Back to Top
| AT 2022qnv (Orion) AT 2022qnv (Type: YSO) discovered 2022-07-28.651 UT by Gaia Alias: Gaia22ddt Alerting Magnitude 14.63 (vs Historic Magnitude 13.39) Known YSO BB Ori fades by 1 mag ( TNS 2022qnv , Gaia22ddt ) |
| AT 2022qnv - 2022-10-23 (T+86.5d) Position of reported transient (barely separable) is shown by white cross-hairs |
 |
| Annotated CCD Image (50% size, linear scale) 180s exposure (single frame), 3x3 binning, Clear Filter 2022-10-23 04:38 UT (#1048152) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| AT 2022qnv - 2022-10-23 (T+86.5d) Image below (2022-10-23.193) was taken 86.5 days after discovery of 2022qnv Position of reported transient (barely separable) is shown by white cross-hairs Measured magnitude +14.48 |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 180s exposure (single frame), 3x3 binning, Clear Filter 2022-10-23 04:38 UT (#1048152) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022qnv on Transients 2022 Page >> |
Back to Top
| AT 2022tqu (Auriga) AT 2022tqu (Type: Nova) discovered 2022-09-06.418 UT by Kumar Alias: GEOTS-2022-013 Discovery Magnitude +12.7 (Clear Filter) ( TNS 2022tqu ) |
| AT 2022tqu - 2022-10-23 (T+46.8d) Image below (2022-10-23.209) was taken 46.8 days after discovery of 2022tqu Position of earlier transient (faded & no longer visible) is shown by white cross-hairs |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-10-23 05:10 UT (#1048159-63) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022tqu on Transients 2022 Page >> |
Back to Top
| AT 2022vxe (Cygnus) AT 2022vxe (Type: YSO?) discovered 2022-09-24.523 UT by Gaia Alias: Gaia22dzx Brightening in candidate YSO Alerting Magnitude 12.34 ( vs historic mag 12.65) ( TNS 2022vxe, Gaia22dzx ) |
| AT 2022vxe - 2022-10-23 (T+28.6d) Image below (2022-10-23.169) was taken 28.6 days after discovery of 2022vxe Position of reported transient (bright) is shown by white cross-hairs Measured magnitude +11.77 |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-10-23 04:11 UT (#1048137-40) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022vxe on Transients 2022 Page >> |
Back to Top
| AT 2022whd (Cassiopeia) AT 2022whd (Type: CV) discovered 2022-09-28.034 UT by Gaia Alias: Gaia22eba ( TNS 2022whd , Gaia22eba ) |
| AT 2022whd - 2022-10-23 (T+25.2d) Image below (2022-10-23.184) was taken 25.2 days after discovery of 2022whd Position of reported transient (bright) is shown by white cross-hairs Measured magnitude +12.63 (aperture 8) |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-10-23 04:28 UT (#1048144-48) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022whd on Transients 2022 Page >> |
Back to Top
| AT 2022why (Cassiopeia) AT 2022why (Type: Nova?) discovered 2022-09-30.436 UT by Tadashi Kojima Alias: TCP J23580957+5502503, TCP J23580961+5502508, Gaia22eci ( TNS 2022why , Gaia22eci ) |
| AT 2022why - 2022-10-23 (T+22.7d) Image below (2022-10-23.094) was taken 22.7 days after discovery of 2022why Position of reported transient (distinct) is shown by white cross-hairs Measured magnitude +14.34 (aperture 8) |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-10-23 02:19 UT (#1048110-14) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022why on Transients 2022 Page >> |
Back to Top
| NGC 3938 with SN 2022xlp (Ursa Major) SN 2022xlp (Type: Ia-02cx) discovered 2022-10-13.808 UT by Koichi Itagaki Alias: ATLAS22bkeb Discovery Magnitude xx ( TNS 2022xlp ) |
| NGC 3938 with SN 2022xlp - 2022-10-23 (T+9.3d) Image below (2022-10-23.067) was taken 9.3 days after discovery of 2022xlp Position of SN (distinct) shown by white cross-hairs Measured magnitude +15.67 |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-10-23 01:46 UT (#1048091-95) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022xlp (NGC 3938) on Supernova 2022 Page >> |
Back to Top
| NGC 5894 with SN 2022pgf (Draco) SN 2022pgf (Type: II) discovered 2022-07-22.285 UT by ZTF Alias: ZTF22aauurbv, ATLAS22vul, PS22gvc ( Rochester Supernova site | TNS 2022pgf ) |
| NGC 5894 with SN 2022pgf - 2022-10-23 (T+92.9d) Image below (2022-10-23.142) was taken 92.9 days after discovery of 2022pgf Position of reported transient (distinct) is shown by white cross-hairs Measured Magnitude +15.37 (aperture 8) |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 13 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-10-23 03:30 UT (#1048124-26) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022pgf (NGC 5894) on SN 2022 Page >> |
Back to Top
| NGC 7448 with SN 2022wsp (Pegasus) SN 2022wsp (Type: II) discovered 2022-10-03.000 UT by DLT40 Alias: DLT22q, ATLAS22bhvs, PS22knl ( Rochester Supernova site | TNS 2022wsp ) |
| NGC 7448 with SN 2022wsp - 2022-10-22 (T+20.0d) Image below (2022-10-22.976) was taken 20.0 days after discovery of 2022wsp Position of SN (close to nucleus) is shown by white cross-hairs Measured magnitude +14.20 (nucleus + SN) |
 |
| Annotated CCD Image (150% size, log scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-10-22 23:35 UT (#1048052-56) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022wsp (NGC 7448) on SN 2022 Page >> |
Back to Top
| NGC 7495 with SN 2022ubb (Pegasus) SN 2022ubb (Type: II, z=0.01628) discovered 2022-09-13.498 UT by ATLAS Alias: ATLAS22bekt Discovery Magnitude +18.125 ABMag ( TNS 2022ubb ) |
| NGC 7495 with SN 2022ubb - 2022-10-22 (T+39.5d) Image below (2022-10-22.994) was taken 39.5 days after discovery of 2022ubb Position of SN (faint) shown by white cross-hairs Measured Magnitude ? (unable to separately isolate) |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-10-22 23:58 UT (#1048061-64) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022ubb (NGC 7495) on Supernova 2022 Page >> |
Back to Top
| UGC 3923 with SN 2022rqc (Lynx) SN 2022rqc (Type: Ia) discovered 2022-08-20.487 UT by ZTF Alias: ZTF22abbozja ( Rochester Supernova site | TNS 2022rqc ) |
| UGC 3923 - Spiral Galaxy |
| UGC 3923 with SN 2022rqc - 2022-10-23
(T+63.7d) Image below (2022-10-23.158) was taken 63.7 days after discovery of 2022rqc Position of reported supernova is shown by white cross-hairs Measured magnitude +15.38 (nucleus + transient) (aperture 8) |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-10-23 03:54 UT (#1048131-34) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022rqc (UGC 3923) on Supernova 2022 Page >> |
Back to Top
