Objects Session Notes
Mars - Planet 29P/Schwassmann-Wachmann - Comet 81/P Wild - Comet C/2019 U5 (PANSTARRS) - Comet C/2022 E3 (ZTF) - Comet NGC 2777 - Spiral Galaxy with Type II Supernova 2022aagp (Attempt) NGC 4088 - Spiral Galaxy (H I-206) with Type II Supernova 2022jzc NGC 4340 - Spiral Galaxy with Transient AT 2022zzz NGC 4545 - Spiral Galaxy with Type II Supernova 2022fuc UGC 3554 - Spiral Galaxy with Type Ib Supernova 2022rbo (Attempt) UGC 6608 - Spiral Galaxy with Type Ia Supernova 2022zvr UGC 8379 - Spiral Galaxy with Transient AT 2022qza (Attempt) Variable Stars (photometric monitoring) - None Nearby Stars (astrometric monitoring) - None
- Attempted All Night session (8.1h), but hampered by cloud - 12" LX200 + ST-10XME for imaging - TS 80mm APO + ZWO ASI178MC for guiding & imaging - Ambient Temperature: 6.5°C (min) - CCD Temperature: -15° C - Notes from 2022-11-24 >> [ Local Files >> ]
| Mars (passing through Taurus) Sun Distance 1.52 AU Earth Distance 0.55 AU (82.0 million km) (Motion Ra -58.74 arcsec/hr, Dec 4.22 arcsec/hr) |
 |
| Annotated CCD Image (50% size, linear scale) 4 x 0.11s exposure (average combine), 3x3 binning, V Filter 2022-11-24 23:57 UT (#1061047-50) 12" LX200R (at f/10.4) + ST-10XME |
 |
| Annotated CCD Image (150% size, linear scale, cropped, unsharp masked) Original images collected as 1/4 (one quater) frames 0.2s exposure (single frame), 1x1 binning, Ha Filter 2022-11-25 00:00 UT (#1061077) 12" LX200R (at f/10.4) + ST-10XME |
Back to Top
| 29P/Schwassmann-Wachmann - 2022-11-24 (passing through Gemini) Sun Distance 6.05 AU Earth Distance 5.26 AU (786.4 million km) |
29P/Schwassmann-Wachmann - 2022-11-24 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -12.44 arcsec/hr, Dec 1.41 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 2 x 30s exposure (average combine), 3x3 binning, Clear Filter 2022-11-24 22:54 UT (#1061012-14) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, log scale, cropped) 5 x 30s exposure (average combine), 3x3 binning, Clear Filter 2022-11-24 22:57 UT (#1061012-24) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| 29P/Schwassmann-Wachmann - 2022-11-24 (passing through Gemini) Shows significant brightening since image in Mar 2022 Shows 'Pac Man' shape. Coma diameter |
||
 |
Sun Distance 6.05 AU Earth Distance 5.26 AU (786.4 million km) (Motion : Ra -12.44 arcsec/hr, Dec 1.41 arcsec/hr) Detail (150% size) showing its 'Pac Man' shape Annotated CCD Image (150% size, log scale, cropped) 5 x 30s exposure (average combine), 3x3 binning, Clear Filter 2022-11-24 22:57 UT (#1061012-24) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| 29P/Schwassmann-Wachmann - Earlier Image (2022-03-01) (passing through Taurus) |
||
 |
Sun Distance 5.96 AU (receeding) Earth Distance 5.93 AU (886.6 million km) (Motion : Ra 13.25 arcsec/hr, Dec -2.20 arcsec/hr) Annotated CCD Image (150% size, log scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, C Filter 2022-03-01 23:36 UT (#980138-42) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of 29P/Schwassmann-Wachmann on Comets 2022 Page >> |
Back to Top
| 81P/Wild (passing through Virgo) Sun Distance 1.61 AU (approaching) Earth Distance 2.07 AU (309.4 million km) |
81P/Wild - 2022-11-25 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 103.56 arcsec/hr, Dec -39.32 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-25 05:29 UT (#1061121-24) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-25 05:29 UT (#1061121-24) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of 81/P Wild on Comets 2016 Page >> | ||
| Images of 81/P Wild on Comets 2022 Page >> |
Back to Top
| C/2019 U5 (PANSTARRS) (passing through Bootes) Sun Distance 3.79 AU (approaching) Earth Distance 4.45 AU (666.2 million km) Comet position is indicated by white cross-hairs |
C/2019 U5 (PANSTARRS) - 2022-11-25 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 8.79 arcsec/hr, Dec -18.90 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 2 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-25 05:57 UT (#1061144-45) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) 2 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-25 05:57 UT (#1061144-45) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of C/2019 U5 (PANSTARRS) on Comets 2022 Page >> |
Back to Top
| C/2022 E3 (ZTF) (passing through Serpens) Sun Distance 1.36 AU (approaching Earth Distance 1.86 AU (277.6 million km) |
C/2022 E3 (ZTF) - 2022-11-25 am Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 4.48 arcsec/hr, Dec 5.75 arcsec/hr) (poor quality image, single frame only due to cloud |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 90s exposure (single frame), 3x3 binning, Clear Filter 2022-11-25 06:10 UT (#1061155) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (100% size, log scale, cropped) 90s exposure (single frame), 3x3 binning, Clear Filter 2022-11-25 06:10 UT (#1061155) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of C/2022 E3 (ZTF) on Comets 2022 Page >> |
| C/2022 E3 (ZTF) - False Colour (Nov 2022) Inverse Spectrum Images |
| C/2022 E3 (ZTF) - 2022-11-25 am |
| False Colour CCD Image (70% size, square root scale) 7 x 90s exposure (average combine), 3x3 binning, Clear Filter 2022-11-24 06:19 UT (#1060177-83) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
| NGC 2777 with SN 2022aagp (Cancer) SN 2022aagp (Type: II) discovered 2022-11-14.393 UT by ZTF Alias: ZTF22abtspsw Discovery Mag 15.76 (r-ZTF filter) ( TNS 2022aagp ) |
| NGC 2777 - Spiral Galaxy |
 |
| Annotated CCD Image (50% size, square root scale) 2 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-25 00:25 UT (#1061091-93) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 2777 with SN 2022aagp - 2022-11-25 (T+10.6d) Image below (2022-11-25.014) was taken 10.6 days after discovery of 2022aagp Position of reported supernova (not separately distinguishable) is shown by white cross-hairs Measured magnitude +14.25 (nucleus + SN) |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 2 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-25 00:25 UT (#1061091-93) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022aagp (NGC 2777) on Supernova 2022 Page >> |
Back to Top
| NGC 4088 with SN 2022jzc (Ursa Major) SN 2022jzc (Type: II) discovered 2022-05-16.204 UT by ZTF Alias: ZTF22aakdbia Discovery Magnitude 17.8 [ Rochester Supernova site | TNS 2022jzc ] |
| NGC 4088 with SN 2022jzc - 2022-11-25 (T+193.0d) Image below (2022-11-25.199) was taken 193.0 days after discovery of 2022jzc Position of SN (faded / very faint) is indicated by white cross-hairs |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-25 04:58 UT (#1061109-11) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022jzc (NGC 4088) on Supernovae 2022 Page >> |
Back to Top
| NGC 4340 with SN 2022zzz (Coma Berenices) SN 2022zzz (Type: II) discovered 2022-11-12.824 UT by Koichi Itagaki Alias: ATLAS22blqo ( Rochester Supernova site | TNS 2022zzz ) Although SN 2022zzz has been ascribed to NGC 4340 it seems more likely that the supernova's host galaxy is the small diminutive galaxy LEDA 213984 |
| NGC 4340 with SN 2022zzz & LEDA 213984 - 2022-11-25
(T+12.4d) Image below (2022-11-25.213) was taken 12.4 days after discovery of 2022zzz Position of reported transient (faint, but distinct) is shown by white cross-hairs Measured magnitude +16.98 |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-25 05:14 UT (#1061114-18) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022zzz (NGC 4340) on Supernova 2022 Page >> |
Back to Top
| NGC 4545 with SN2022fuc (Draco) SN 2022fuc (Type: II) discovered 2022-04-02.878 UT by Giancarlo Cortini Alias: ATLAS22lhg, ZTF22aadpuwe Discovery Magnitude 17 ' Past image of the same field taken on 2022/03/03.98 showed nothing at that position (limit mag.+18.5) ' ( Rochester Supernova site | TNS 2022fuc ) |
| NGC 4545 with SN 2022fuc - 2022-11-24 (T+236.1d) Image below (2022-11-24.987) was taken 236.1 days after discovery of 2022fuc Position of earlier SN (very faint) is shown by white cross-hairs |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-24 23:48 UT (#1061040-43) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022fuc (NGC 4545) on Supernovae 2022 Page >> |
Back to Top
| UGC 3554 with SN 2022rbo (Auriga) SN 2022rbo (Type: Ib) discovered 2022-08-09.497 UT by ZTF Alias: ZTF22aazqoey Discovery Mag 17.95 (r-ZTF filter) ( TNS 2022rbo ) |
| UGC 3554 - Spiral Galaxy |
 |
| Annotated CCD Image (50% size, square root scale) 2 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-25 00:09 UT (#1061084-87) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 3554 - Detail Image possibly contains a ghost image from previous imaging of Mars which saturated the CCD in V & R filter bands. |
 |
| Annotated CCD Image (125% size, square root scale, cropped) Image details as above |
| UGC 3554 with SN 2022rbo - 2022-11-25 (T+107.5d) Image below (2022-11-25.002) was taken 107.5 days after discovery of 2022rbo Position of earlier supernova (not distinguishable) is shown by white cross-hairs |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 2 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-25 00:09 UT (#1061084-87) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022rbo (UGC 3554) on Supernova 2022 Page >> |
Back to Top
| UGC 6608 with SN 2022zvr (Virgo) SN 2022zvr (Type: Ia, z=0.020715) discovered 2022-11-10.530 UT by ZTF Alias: ZTF22abtdbnx Discovery Mag 17.68 (r-ZTF filter) ( TNS 2022zvr ) |
| UGC 6608 with SN 2022zvr - 2022-11-25 (T+14.7d) Image below (2022-11-25.184) was taken 14.7 days after discovery of 2022zvr Position of SN (bright) is shown by white cross-hairs Measured magnitude +16.11 |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-25 04:35 UT (#1061098-102) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022zvr (UGC 6608) on Supernova 2022 Page >> |
Back to Top
| UGC 8379 with AT 2022qza (Virgo) AT 2022qza (Type: unk) discovered 2022-08-07.569 UT by Gaia Alias: Gaia22dhh ( TNS 2022qza , Gaia22dhh) |
| UGC 8379 with AT 2022qza - 2022-11-25 (T+109.7d) Image below (2022-11-25.266) was taken 109.7 days after discovery of 2022qza Position of earlier reported transient (not distinguishable) is shown by white cross-hairs |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 2 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-25 06:26 UT (#1061161-62) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022qza (UGC 8379) on Transients 2022 Page >> |
Back to Top
