David's Astronomy Pages
CCD Images - Session 1124 (2023-07-30)
Images
(S1123)
Images
Main
Home
Page
Images
(S1125)
David's Astronomy Pages
|
Images (S1123) |
Images Main |
Home Page |
Images (S1125) |
Objects Session Notes
M33 - Spiral Galaxy with Transient AT 2023nou NGC 513 - Spiral Galaxy with Transient AT 2023jpp (Attempt) - M101 w/SN2023ixf , NGC 5297 w/AT2023mlt, UGC 9350 w/SN2023nny, AT2023cur & AT2023cvz attempts failed (due to bad focus) Variable Stars (photometric monitoring) - Z And, BL Lac, V Sge Nearby Stars (astrometric monitoring) - None - Barnards Star attempt failed (due to bad focus)
- All night session (3.5 hrs). Images from first 7 targets were out-of-focus and were rejected. This was due to a major change in focus / atmosphere from the previous session and a QC Check Rejection of the Best Focus Measurement for Near Zenith Focus Field at the start of the session - 12" LX200 + ST-10XME for imaging - TS 80mm APO + ZWO ASI178MC for guiding & imaging - Ambient Temperature: 7.5°C (min) - CCD Temperature: -10° / -15° C - Notes from 2023-07-30 >> -
|
M33 with AT 2023nou (Triangulum) |
|
M33 with AT 2023nou Cam2 Reference Image, Position of AT 2023nou is shown by blue circle Limits of M33 Spiral Galaxy is shown by white ellipse |
|
|
| Annotated CMOS Image (16% size) (10s exposure, 1x1 binning) 2023-07-31 01:50 UT (02:50 LT) TS 80mm APO, ZWO ASI178MC |
| M33 with AT 2023nou - 2023-07-31 (T+10.6d) Image below (2023-07-31.078) was taken 10.6 days after discovery of 2023nou Position of reported transient (faint) is shown by white circle |
|
|
|
Annotated CCD Image (50% size, square root scale) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-07-31 02:00 UT (#1124120-23) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
M33 with AT 2023nou - 2023-07-31 (T+10.6d) Image below (2023-07-31.078) was taken 10.6 days after discovery of 2023nou Position of reported transient (faint) is shown by white cross-hairs Measured Magnitude +16.98 |
|
|
| Annotated CCD Image (125% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-07-31 02:00 UT (#1124120-23) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
AT 2023nou - Reference Image Position of reported transient is shown by mauve cross-hairs Object appears to be a previously known star visible in DSS2 Colour image |
|
|
| DSS2 Image captured in Aladin |
| Images of AT 2023nou (in M33) on Transients 2023 Page >> |
Back to Top
|
NGC 513 with AT 2023jpp (Andromeda) |
|
NGC 513 with adjacent galaxies NGC 513 (alias PGC 5174, catalog mag +13.4), PGC 5134 (catalog mag +15.6), PGC 212749 (catalog mag +16.9), PGC 212747 (catalog mag ?) |
|
|
|
Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-07-31 01:41 UT (#1124113-17) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 513 - Detail |
|
|
| Annotated Negative CCD Image (150% size, log scale, cropped) Image details as above |
|
NGC 513 with AT 2023jpp - 2023-07-31 (T+63.6d) Image below (2023-07-31.064) was taken 63.6 days after discovery of 2023jpp Position of reported transient (not visible) is shown by white cross-hairs |
|
|
| Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-07-31 01:41 UT (#1124113-17) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of 2023jpp (in NGC 513) on Transients 2023 Page >> |
Back to Top
