38P/Stephan-Oterma - Comet 64P/Swift-Gehrels - Comet     HIP 20995 - Star     NGC 1662 - Open Cluster     Photometric Monitoring - Variables    - None       Astrometric Monitoring - Nearby Stars   - None

- Night Session (2.9 hours total, 0.8 hours images) . - Main aim of the session was to test the operation and use of a Pegasus Motor Focus Unit that was newly installed onto the TS 80mm f6 APO secondary scope - Opportunity was taken to acquire images of an open cluster and a couple of comets     - 12" LX200 + ST-10XME for imaging - TS 80mm APO + ZWO ASI178MC for guiding & imaging - Ambient Temperature:  5.5°C (minimum)  - CCD Temperature:  -15°C (58% av. power) - Notes from 2018-11-07 >>

38P/Stephan-Oterma - Comet

38P/Stephan-Oterma (passing through Gemini) Sun distance 1.59 AU.

CCD Image (50% size) 26 x 30s exposure ( aligned on comet, average combine), 3x3 binning, C Filter  2018-11-08 03:32 UT (#636029-59) 12" LX200R  (at f/10.4) + ST-10XME (Autoguided on a guide star using TS 80mm APO + ZWO ASI178MC)

38P/Stephan-Oterma  - Earlier Image (2018-10-21) (passing through Gemini) Sun distance 1.61 AU.

CCD Image (50% size) 7 x 30s exposure (average combine), 3x3 binning, C Filter  2018-10-21 20:03 UT (#633206-12) 12" LX200R  (at f/10.4) + ST-10XME (Autoguided using TS 80mm APO + ZWO ASI178MC)

38P/Stephan-Oterma - Earlier detail  (2018-10-21)

Annotated CCD Image (100% size, Cropped) Image details as above

Back to Top

64P/Swift-Gehrels - Comet

64P/Swift-Gehrels (passing through Andromeda) Sun distance 1.39 AU. taken under deteriorating sky conditions

Annotated CCD Image (50% size) 2 x 45s exposure (average combine), 3x3 binning, C Filter  2018-11-08 03:50 UT (#636067-68) 12" LX200R  (at f/10.4) + ST-10XME (Autoguided using TS 80mm APO + ZWO ASI178MC)

Back to Top

HIP 20995 - Star

HIP 20995 / SAO 93970 (Taurus) Images taken at the end of testing the focusing of TS 80mm Secondary Scope using new Motor Focus Unit

Image from  80mm APO scope (at f/6) + ZWO ASI 178MC camera (box shows the corresponding FOV for  12" LX200 + ST-10XME) HIP 20995, mag +5.6 lies near centre of image Bright star to upper right is HIP 20894, mag +3.4 (Image Link with 30 UCA/USNO stars, plate scale 3.100"/px, N angle 354.5 deg camera needs to be rotated anti-clockwise by 5.5deg )

Annotated CMOS Image (48% size) 4 x 10s exposure (average combine), 3x3 binning 2018-11-08 02:58h UT (#636012-15) TS Photoline 80mm APO  (at f/6) + ZWO ASI 178MC (Images acquired using CCDSoft using 'ASCOM Camera / ASI Camera (1)'

Image from 12" LX200R scope  (at f/10.4) + ST-10XME camera

CCD Image (50% size) 3 x 5s exposure (average combine), 3x3 binning, C Filter 2018-11-08 03:05h UT (#636016-18) 12" LX200R  (at f/10.4) + ST-10XME

Back to Top

NGC 1662 - Open Cluster

NGC 1662 (Orion)

CCD Image (70% size) 7 x 20s exposure (average combine), 3x3 binning, C Filter 2018-11-08 03:10h UT (#636020-26) 12" LX200R  (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 1662 - Earlier Image (2017) Single Frame with ZWO Camera and 80mm Secondary Scope

Image: Exposure: Details: Image ID: Date/Time: Equipment: Software: CMOS Image (24% size , cropped) 10s (single frame) Binning 1x1, Gain 400, Raw16, ROI 3096x2080  #20_30_23Z 2017-01-23 20:30h UT TS 80mm f/6 APO + ASI178MC (OSC) Mounted on 12" LX200R Frame acquired using SharpCap
