Comets - 2018

Comet Images (2018) This page summarises observations and images of comets in 2018
Bullet 21P/Giacobini-Zinner (May, Sep 2018)
Bullet 37P/Forbes (Aug-Sep 2018)

Bullet C/2016 R2 (PANSTARRS) (Dec 2017 to Aug 2018)

21P/Giacobini-Zinner - Comet

21P/Giacobini-Zinner (2018-09-15)
(Passing through starfield in Gemini)
Sun Distance 1.82 AU
Earth Distance ~ 0.39 AU
CCD Image (50% size, linear scale)
30 sec exposure (single frame), 3x3 binning, C Filter
2018-09-15 01:18 UT (#629521)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
[ Full Size Image ]


21P/Giacobini-Zinner - Detail  (2018-09-15)
CCD Image (50% size, log scale)
Image details as above
[ Full Size Image ]

False Colour CCD Image (50% size, log scale)
Inverse Spectrum
Image details as above

21P/Giacobini-Zinner - Animated Image (2018-09-15)
showing 3.28 arc min movement of comet over a 41 minute interval
(i.e. movement of 4.8 arc min/hour or 1.92 arc deg/day)
Animated CCD Image (100% size, linear scale, cropped)
40 x 30 sec frames, 3x3 binning, C Filter
2018-09-15 01:18 to 02:00 UT (#629521-80)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided on star using TS 80mm APO, ZWO ASI178MC & PHD2
  21P/Giacobini-Zinner - Other Images (2018-09-15)
Composite CCD Image (50% size, logscale)
14 x 15 sec exposure (aligned on comet, average combine)
3x3 binning, C Filter
2018-09-15 02:35 to 02:42 UT (#629621-35)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided on star using TS 80mm APO, ZWO ASI178MC & PHD2
[ Full Size Image ]

False Colour CCD Image (50% size, log scale)
Inverse Spectrum
Image details as above

Composite CCD Image (72% size, log scale)
40 x 30 sec exposure (aligned on comet, average combine)
3x3 binning, C Filter
2018-09-15 01:18 to 02:00 UT (#629521-80)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided on star using TS 80mm APO, ZWO ASI178MC & PHD2
[ Full Size Image ]

  21P/Giacobini-Zinner - Rotational Gradient (2018-09-15)
15 deg rotational shift
(Processing performed in IRIS 5.59)
Processed CCD Image (100% size, rotational gradient, cropped)
5 x 30 sec exposure (aligned on comet, average combine)
3x3 binning, C Filter
2018-09-15 01:20 UT (#629621-25)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided on star using TS 80mm APO, ZWO ASI178MC & PHD2

  21P/Giacobini-Zinner - Wider View through TS 80mm APO scope  (2018-09-15)
Colour CMOS Image (16% size)
12 x 10s (Live Stack Combine) 1x1 binning, Gain 400
Total Exposure 120s
2018-09-15 02:58 UT (#02_58_53Z)
TS 80mm f/6 APO + ASI178MC (OSC)
Mounted on 12" LX200R
[ Larger Image , 29% size ]

Colour CMOS Image (100% size, cropped)
Image details as above


21P/Giacobini-Zinner  (2018-05-18)
 (passing through Vulpecula)
Sun Distance 1.81 AU


CCD Image (50% size)
4 x 30s sec exposure (average combine), 3x3 binning, C Filter
2018-05-18  01:45 h UT (#611179-83)
12" LX200R  (at f/5.7) + ST-10XME


Annotated CCD Image (150% size, cropped)
Image details as above
21P/Giacobini-Zinner  (2018-05-17)
(passing through Vulpecula)
Sun Distance 1.82 AU


CCD Image (100% size, cropped)
3 x 60s sec exposure (average combine), 3x3 binning, C Filter
2018-05-17  01:26 h UT (#610073-75)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


37P/Forbes - Comet

37P/Forbes (passing through star-field in Pisces)
Sun Distance 2.05 AU
Comet is marked by white cross hairs. Two faint galaxies in the image are
PGC 85401 (catalog mag +16.8) & PGC 70646 (catalog mag +16.7)
Annotated CCD Image (50% size)
3 x 60 sec exposure (average combine), 3x3 binning, C Filter
2018-09-15 00:12 UT (#629498-500)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
[ Full Size Image ]

37P/Forbes  - 2018-09-18
Sun Distance 2.07 AU. Passing through star-field in Pisces
Annotated CCD Image (100% size, cropped)
5 x 60 sec exposure (average combine), 3x3 binning, C Filter
2018-09-18 21:49 UT (#630060-64)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

37P/Forbes - 2018-09-15
Sun Distance 2.05 AU. Passing through star-field in Pisces
Annotated CCD Image (100% size, cropped)
Image details as above

37P/Forbes - 2018-09-08
Sun Distance 2.02 AU
Annotated CCD Image (100% size, cropped)
5 x 60 sec exposure (average combine), 3x3 binning, C Filter
2018-09-08 22:33 UT (#627002-06)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

37P/Forbes - 2018-08-31
Sun Distance 1.98 AU
Annotated CCD Image (100% size, cropped)
5 x 60 sec exposure (average combine), 3x3 binning, C Filter
2018-08-31 23:09 UT (#623111-15)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Back to Top


C/2016 R2 (PANSTARRS) - Dec 2017 to Aug 2018

C/2016 R2 (PANSTARRS) - 2018-09-19
(passing through Ursa Major)
Sun distance 2.95 AU.
Faint Galaxy too right is  PGC 2324722, catalog mag +17.5)
Annotated CCD Image (100% size, Cropped)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2018-09-19 00:48 UT (#630180-84)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

C/2016 R2 (PANSTARRS) - 2018-08-24
(passing through Ursa Major)
Sun distance 2.84 AU, Est. Mag +15.8.
The tiny galaxy at below left is PGC 2393752, catalog mag +17.4)
Annotated CCD Image (100% size, Cropped)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2018-08-24 02:09 UT (#621132-36)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)
(Average Guide Error 0.9" rms, PHD2)

C/2016 R2 (PANSTARRS) -  2017-12-13
(passing through Gemini)
Sun distance 3.02 AU
(Bright object in upper-left corner of the image is the
+7.2 mag star HIP 22221)
CCD Image (50% size, Linear Scaling)
2 x 60s exposure (average combine), 3x3 binning, C Filter
2017-12-13 22:29h UT (#607079-80)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)
