Notes (S00037)

This imaging session was of nearly 8 hours duration and ran many under unattended script control.  With ambient temperatures of -5 deg C attended operation of the telescope would just not have been possible.    A number of check visits were made to the observatory  to check progress.   The first visit showed that the telescope's sky position  had become lost due to an inappropriate sync following a SBIG driver: A/D timeout. # 800407DD problem.  The script was restarted and then continued without requiring any form of intervention  for 6 hours 40 minutes, during which scripts took a total of 596 CCD Images as part of the following set of tasks :

• Images of 19 variables in constellations And, Peg & Lac

• Jog Testing (on And R and And RX)

• Images of 16 variable stars in constellations Cam, Per & Tau

• 8 x 9 Mosaic of open cluster M45  (Pleiades)

• Images of 10 variable stars in constellations Aur, Gem, Mon & Cnc

• 5 x 5 Mosaic of open cluster NGC 1807 / NGC 1817

• Second 8 x 9 Mosaic of open cluster M45  (Pleiades)

• 7 x 6 Mosaic of double cluster NGC 884 / NGC 869

• 5 x 6 Mosaic of open clusters M35 / NGC 2158

• 4 x 5 Mosaic of galaxy cluster / galaxy NGC 507

• 3 x 4 Mosaic of galaxy cluster / galaxy NGC 1275 (Perseus A)

• 7 x 10 Mosaic of cluster & nebulosity IC1848

• Image of galaxy UGC 4047

Back to Top

Variable Stars

Variables in Pegasus, Andromeda, Lacerta were imaged using Automated Scripting (see Scripting).  New set of variables in constellations Auriga, Gemini, Cancer, Camelopardalis, Perseus and Taurus were commenced.

Back to Top

NGC 1807 / NGC 1817 Open Cluster Pair

Mosaic of NGC (1807 lower right)/ NGC 1817 (upper left)

Mosaic 5x5 CCD frames,  20 sec exposures taken on 2003-01-04 22:08 to 22:21h UT (#37355-69) 49.7 x 31.1 arc mins Missing frame is due to Telescope Failing to Move in Dec problem

Back to Top

NGC 884 / NGC 869   (Double Cluster In Perseus)

Mosaic of NGC 884 (left) & NGC 869 (right)  (Perseus)

Mosaic 7x6 CCD frames,  20 sec exposures taken on 2003-01-04  23:03 to 23:32h UT (#37454-95) 69 x 34 arc mins

Back to Top

M45 Pleiades   (Open Cluster in Taurus)

Mosaic of M45  (Taurus)

Mosaic 8x9 CCD frames,  10 sec exposures taken on 2003-01-04  21:10 to 21:48h UT (#37250-321) 76 x 55 arc mins (1.25 x 0.92 arc deg) [ Full size image ]

Back to Top

M35 / NGC 2158 Open Clusters

Mosaic of M35 (right/centre) & NGC 2158 (lower right)  (Gemini)

Mosaic 5x6 CCD frames,  20 sec exposures taken on 2003-01-04  23:33 to 23:54h UT (#37250-321) 50 x 39 arc mins Missing frame is due to Telescope Failing to Move in Dec problem

Back to Top

NGC 1275 (Perseus A) Galaxy / Galaxy Cluster

NGC 1275 + surrounding galaxies (Perseus)

CCD Mosaic 3x4,  60s exposures 2003-01-05 00:25 to 00:40h UT (#37550-61) 30.4 x 23.6 arc mins

Detail of galaxies near NGC 1275

part of a CCD Mosaic 3x4,  60s exposures 2003-01-05 00:25 to 00:40h UT (#37550-61)

Back to Top

UGC 4047 Galaxy

UGC 4047 (Gemini) UGC 4047 (catalog mag +14.0), MCG5-19-16 (catalog mag +15.8)

CCD frames,  10 x 60s (median combine) 2003-01-05 01:44 to 01:58h UT (#37634-43) 11.0 x 7.1 arc mins

Back to Top

Stars in IC 1848

Hip 13296. Hip 13308 within area of IC 1848 (This is one frame from a 7x10 Mosaic over IC 1848, these didn't reveal the nebula, however this frame contains a interesting set of stars)

CCD image,  30s  2003-01-05 01:15h UT (#37601) 11.4 x 7.6 arc mins
