Bullet Notes from CCD Session

Bullet C/2001 HT50 - Comet
Bullet M76 Planetary Nebula
Bullet M31 (Andromeda Galaxy)
Bullet HD 209458 (Osiris)

Notes (S00068)

- Imaging session was with a focal reducer bringing 8" f/10 LX200 to f/7.
- Images were recorded with ST7 CCD camera.  Filter Wheel with CBVRI filters
- Seeing was moderate, but cloud gradually built up through session.
- 2.5 hour session

Back to Top


C/2001 HT50 - Comet

C/2001 HT50
CCD  Image, 3 x 60 sec exposure, C filter
2004-08-22  22:08h UT (#68053-55)

Back to Top


M76 (Little Dumbbell)- Planetary Nebula

M76 (Perseus)
CCD  Image, 7 x 60 sec exposure (average combine)
Clear Filter
2004-08-22  23:15 h UT (#68129+)

M76 (False-Colour Display)
False Colour CCD  Image
(Logarithmic Scaling, Spectrum Colour Scale)
7 x 60 sec exposure (average combine)
Clear Filter
2004-08-22  23:15 h UT (#68129+)

M76 through CBVRI Filters
CCD  Animation,
C  (4x60s), B (2x120s), V (2x60s), R(2x60s), I (2x60s)
2004-08-22  23:02 to 23:23 h UT (#68125-43)

M76 Colour Image
CCD  Approximate Colour Image
Constructed by taking R (2x60s) as Red,
V(2x60) as Green,  B (2x120s) as Blue
2004-08-22  23:02 to 23:23 h UT (#68125-43)

M76 Colour Image
CCD  Colour Image
Constructed by taking R (2x60s) as Red, V(2x60) as Green,
B (2x120s) as Blue and C (4x60s) as Luminance
2004-08-22  23:02 to 23:23 h UT (#68125-43)

M76 False Colour Image
False Colour CCD  Image
Constructed by taking I (2x60s) as Red, V(2x60) as Green,
B (2x120s) as Blue and R(2x60s) as Luminance
2004-08-22  23:02 to 23:23 h UT (#68125-43)

Back to Top


M31 (Andromeda Galaxy)

Regions of M31 (Andromeda)
CCD  Image, 6x60 sec exposure (average combine)
Clear Filter
2004-08-22  23:48 h UT (#68154-62)

CCD  Image, 5x60 sec exposure (average combine)
Clear Filter
2004-08-22  23:38 h UT (#68145-52)

Index Image :Showing B/W CCD Images inserted
within a Colour Image of M31 (from TheSky6)

Back to Top


HD 209458 (Osiris) - star to extra-solar planet system

A sequence of images of HD209458 were taken through V and R filters. These will be processed in order to understand the magnitude measurement precision and indicate whether it would be likely to detect dimming in the star associated with transit of its planet.
