Bullet Notes from CCD Session

Bullet Moon
Bullet Satellite
Bullet NGC 6709 - Open Cluster

Notes (S00070)

- Imaging session was with a focal reducer bringing 8" f/10 LX200 to f/7.
- Images were recorded with ST7 CCD camera. Filter Wheel with CBVRI filters
- Moon in ESE Sky 83% phase, Altitude 20 deg.
- Cloud rapidly build up and cut short the 1.5 hour session.

Back to Top


Moon

Moon (83.1% phase)
CCD Mosaic, 0.11s exposure, B filter
2004-09-02 23:04 to 23:16h UT (#70020-43)
Larger Size

Moon (negative image)
CCD Negative Image  (details as above)

Moon - comparison of mosaic image with equivalent mosaic from 2 days previous
2004-08-31 (95.4% phase) & 2004-09-02 (83.1% phase)

Back to Top


Satellite

Satellite (passing through starfield in Aquila)
CCD Image, 15s exposure, Clear Filter
2004-09-02  21:30:50 to 21:31:05 h UT (#70004)

Back to Top


NGC 6709 - Open Cluster

NGC 6709 (Aquila)
Hidden Treasures catalog object 94
 [ Open Star Clusters ]  [ Hidden Treasures ]
CCD  Colour Composite,
L 1x20s,  B 1x60 sec,  V 1x30s,  R 1x30s
2004-09-02  22:47 to 22:53h UT (#70013-18)

8" LX200 Classic + ST-7E

Back to Top
