Objects Session Notes
Bullet Star field adjacent to SAO 23825
Bullet AXP Monitoring (4U 0142+615 & 1E 2259+586)
Bullet NGC 3079 - Spiral Galaxy
Bullet Double Quasar Q0957+561 - Gravitationally Lensed Quasar
Bullet GCVS RT Aur - Cepheid Variable
Bullet Comet 29P/Schwassmann-Wachmann
Bullet NGC 2537 - Spiral Galaxy (Bear Paw Galaxy)
Bullet M97 - Planetary Nebula ("Owl Nebula")
Bullet NGC 1664 - Open Cluster
- 4.5 hour session, cold (1 deg C)
- operation mainly under automated script control
- Near full moon (95% phase) &  thin high cloud
(the combination caused significant problem in getting sufficiently flat backgrounds for showing up dimmer objects.
- main aim was to obtain magnitude estimates for Delta Cepheid & RT Aur and to attempt to image the double Quasar Q0957+561 (in UMa) and the Bear Paw Galaxy in Lynx. This objectives were successfully met.
- More Notes
-

Star field adjacent to SAO 23825

Star field adjacent to SAO 23825 (Perseus)
Mag +6.3 star with nearby chain of mag +11 to +13 stars

 CCD Image (75% size)
60 sec exposure, 1x1 binning, C Filter
2006-02-10 20:31h UT (#114088)

Back to Top


AXP Monitoring (4U 0142+615 & 1E 2259+586)

Two Anomalous X-ray pulsers (AXPs),  4U 0142+615 and  1E 2259+586 (both lying in Cassiopeia) were checked for brightening. No indication of activity was observed for either AXP.

Star field of 1E 2259+586 area
no sign of AXP (mag limit ~ +15.3)
CCD Image
2 min exposure,  C Filter
2006-02-10  20:26h UT (#114083)
Star field of 4U 0142+615 area
no sign of AXP (mag limit ~ +15.8)
CCD Image
2 min exposure,  C Filter
2006-02-10  20:19h UT (#114078)

Back to Top


NGC 3079 - Spiral Galaxy

NGC 3079 (Ursa Major)

 CCD Image
5 x 2 min exposure (average combine), 2x2 binning, C Filter
2006-02-10 20:40h UT (#114091-95)

 NGC 3079 - false colour
 CCD Image - false colour, log brightness scaling
(image details as above)

Back to Top


Double Quasar Q0957+561  (Gravitationally Lensed Quasar)

 Quasar Q0957+561 A/B (Ursa Major)
Gravitationally lensed quasar 8.5 billion light years distance

The pair of quasar images are around magnitude +17 and
have a separation of  about 6 arc secs.
[ Other Internet Info/pics on Q0957+561 : 1, 2 , 3 , 4, 5 ]
 CCD Image - 250% scaling, cropped & annotated
3 x 2 min exposure (average combine), 2x2 binning, C Filter
2006-02-10 20:49h UT (#114097-99)

Quasar Q0957+561

Image   Image

Location wrt NGC 3079

 CCD Image
3 x 2 min exposure (average combine), 2x2 binning, C Filter
2006-02-10 20:49h UT (#114097-99)

 Quasar Q0957+561 A/B
 CCD Image
5 x 2 min exposure (average combine), 1x1 binning, C Filter
2006-02-10 22:19h UT (#114148-52)

Back to Top


GCVS RT Aur - Cepheid Variable

Baseline images of RT Auriga and reference star were taken. Follow up images taken in Feb-May 2006 were subsequently taken and analysed.   [ Notes on RT Aur Analysis & Results, 2006-05-12 ].

RT Aur (Auriga)
RT Aug (mag ~ +5)  with  Struve 907 double star,+9.3 & +10.4, separation 12 arc secs

 CCD Image (50% size)
60 sec exposure, 1x1 binning, C Filter
2006-02-10 22:11h UT (#114120)
[ Full Size Image ]

SAO 78571 (Auriga)
Reference Star for RT Aug Measurements
 CCD Image
3 x 20 sec exposure (average combine), 2x2 binning, C Filter
2006-02-10 20:57h UT (#114103-05)

Back to Top


Comet 29P/Schwassmann-Wachmann

29P/Schwassmann-Wachmann (passing through Aries)

 CCD Image
3 x 2 min exposure (average combine), 2x2 binning, C Filter
2006-02-10 21:17h UT (#114122-24)

Back to Top


NGC 2537 - Spiral Galaxy (Bear Paw Galaxy)

NGC 2537 (Lynx)

 CCD Image
5 x 2 min exposure (average combine), 2x2 binning, C Filter
2006-02-10 21:26h UT (#114126-30)

NGC 2537 - Bear Paw Galaxy
(North down)
 CCD Image (200% size & rotated by 180 deg)
Image details as above

Back to Top


M97 - Planetary Nebula ("Owl Nebula")

M97 (Ursa Major)

 CCD Image
3 x 5 min exposure (average combine), 2x2 binning, C Filter
2006-02-10 22:02h UT (#114144-46)

Back to Top


NGC 1664 - Open Cluster

NGC 1664 (border of Auriga & Perseus)

 CCD Image Mosaic (2x3 frames, 50% size)
60 sec exposure, 2x2 binning, C Filter
2006-02-10 23:11h UT (#114223-46)
[ Full Size Mosaic ]

 NGC 1664 - detail, approximate colour
Approximate Colour CCD Image  - central portion of 2x3 mosaic
Red - 60sec (R Filter), Green - 60sec (V Filter),
Blue - 60s (B Filter), 2x2 binning
2006-02-10 23:11h UT (#114223-46)
[ Full Size Mosaic ]

Back to Top
