Objects Session Notes ++
Bullet Moon
Bullet Comet 73/P Schwassmann-Wachmann 3-B (Fragment B)
Bullet Comet 73/P Schwassmann-Wachmann 3-C (Fragment C)
Bullet M57 - Planetary Nebula (Ring Nebula)
Bullet NGC 3953 - Spiral Galaxy & Supernova 2006bp
Bullet CGCG 108-13 - Spiral Galaxy with SN 2006bt
Bullet UGC 5434 - Spiral Galaxy (attempt to image Supernova 2006bx)
Bullet NGC 6041 - Elliptical Galaxy & surrounding galaxies (part of Abell 2151)
Bullet Hubble Deep Field (HDF) - North
Bullet M81 - Spiral Galaxy (Bode's Nebula)
Bullet IC 2574 - Spiral Galaxy (Coddington Nebula)
- 3.8 hour session
- main aim was to record follow up images of comet 73/P SW-3 and recent supernova - 2006bp, 2006bt. Opportunity was taken to acquire images of M81 & IC 2574, with telescope/camera operating at their extreme northern declination range.
- More Notes
-

Moon

Moon (37% phase)

CCD Image Mosaic (25% size)
0.11 sec exposure, 1x1 binning, R Filter
2006-05-03 22:17h UT (#121032-44)
[ 50% size ]



Moon (Detail)

Moon (detail)

Image Image

Back to Top


Comet 73/P Schwassmann-Wachmann 3-B  (Fragment B)

Comet 73/P Schwassmann-Wachmann 3-B
(Fragment B passing through Star Field in Hercules)

False Colour CCD Image
4 x 1 min exposure (stacked, aligned on comet)
2x2 binning, C Filter
Log Scale, False Colour (inverse spectrum)
2006-05-03 22:28h UT (#121046-49)

Back to Top


Comet 73/P Schwassmann-Wachmann 3-C  (Fragment C)

Comet 73/P Schwassmann-Wachmann 3-C
(Fragment C passing through Star Field in Hercules)

False Colour CCD Image
4 x 1 min exposure (stacked, aligned on comet)
2x2 binning, C Filter
2006-05-03 22:37h UT (#121052-55)

Back to Top


M57 - Planetary Nebula (Ring Nebula)

M57 (Lyra)

CCD Image
3 x 60 sec exposure (average combine), 2x2 binning, C Filter
2006-05-03 22:49h UT (#121063-65)

Back to Top




NGC 3953 - Spiral Galaxy & Supernova 2006bp

NGC 3953 (Ursa Major) with SN 2006bp
2006bp was discovered 2006/04/09.60 by Koichi Itagaki
(Rochester Supernova site | Discovery Image | Reference Image)

Image below (2006-05-03.96944) was taken 24 days after discovery.
Estimated magnitude of 2006bp  is  +14.5 (C filter).

Annotated CCD Image
4 x 60s exposure (average combine), 2x2 binning, C Filter
2006-05-03 23:16h UT (#121118-21)


Back to Top


CGCG 108-13 - Spiral Galaxy with Supernova 2006bt

CGCG 108-13  with SN 2006bt (Serpens Caput)
2006bt was discovered 2006/04/26.48 by Lick Observatory Supernova Search
(Rochester Supernova site | Discovery Image | Reference Image)

Image below (2006-05-03.976) was taken 7.5 days after discovery.
Estimated magnitude of 2006bt  is  +17.0 (C filter).
CCD Image
5 x 2 min exposure (average combine), 2x2 binning, C Filter
2006-05-03 23:25 h UT (#121125-29)

Back to Top


UGC 5434 - Spiral Galaxy  (attempt to image Supernova 2006bx)

UGC 5434   (Serpens Caput)
A mag +18 supernova (2006bx) has reportedly been discovered in UGC 5434 on
2006/05/01.26 by Lick Observatory Supernova Search
(Rochester Supernova site | Discovery Image | Reference Image)

Image below was taken 2.5 days after discovery.
No indication of an object at the reported position of the supernova.
This is probably due to the mag +18 supernova being too faint to be picked up
in the exposure - the limiting magnitude of the CCD image is approxmately +16.5 (C Filter)
CCD Image
5 x 2 min exposure (average combine), 2x2 binning, C Filter
2006-05-03 23:59 h UT (#121148-52)

Back to Top


NGC 6041 - Elliptical Galaxy & surrounding galaxies (part of Abell 2151)

NGC 6041   (Serpens Caput)
[ NGC 6039 catalog mag +13.9, NGC 6040 catalog mag +14.5
NGC 6041 catalog mag +13.4, NGC 6043 catalog mag +14.4 )
CCD Image
5 x 2 min exposure (average combine), 2x2 binning, C Filter
2006-05-04 00:19 h UT (#121158-62)

Back to Top


Hubble Deep Field (HDF) - North

Hubble Deep Field (Ursa Major)
In December 1995 the Hubble Space Telescope assembled an image of a small 2x2' region in Ursa Major
over the course of 10 consecutive days. Known as the Hubble Deep Field (HDF), it was was the deepest ever field
taken at that time and showed tens of thousands of galaxies out to a distance of 13 billion light years.

Repeating a previous ambitious attempt, I tried to image the same area, under slightly better conditions that last summer's attempt (2005-06-10).
With an image of 16 minute (total) exposure, objects as faint as +18 to +19 are visible, including at least 2 of the brightest galaxy objects in HDF
CCD Image
8 x 2 mins (average combine), clear filter
2006-05-04  00:42 h UT (#121166-75)
(position of HDF area shown as red polygon)
Detail view of HDF area (300% size)
Image  Image
Hubble Deep Field Image
(reduced from HST WFPC2 Mosaic
HST Gallery Image

Back to Top


M81 - Spiral Galaxy (Bode's Nebula)

M81  (Ursa Major)
Image Image
CCD Image
7 x 2 min exposure (average combine),
2x2 binning, C Filter
2006-05-04 01:07 h UT (#121176-82)
CCD Image (as left)
Log Scale

Image Image
CCD Image (as above)
Log Scale, False Colour
CCD Image (as above left)
Histo Equalise Scale, False Colour (Inverse Spectrum)

Back to Top


IC 2574 - Spiral Galaxy (Coddington Nebula)

IC 2574   (Ursa Major)
- an outlying member of the M81 group
CCD Image
5 x 2 min exposure (median combine), 2x2 binning, C Filter
2006-05-04 01:35 h UT (#121197-201)

Back to Top
