Bullet HD 5501 - Binary Eclipsing Variable
Bullet SS Cyg - Variable Star
Bullet NGC 7243 - Open Cluster
Bullet NGC 6781 - Planetary Nebula
Bullet 4P/Faye - Comet
Bullet CY Lyr - Variable (Dwarf Nova)
Bullet Uranus
Bullet Moon
Bullet NGC 752 - Open Cluster
Bullet AXP Monitoring (4U 0142+615 & 1E 2259+586)
Bullet Nearby Stars
- Barnard's Star
- 61 Cygni - Star (the 'flying star')
- SO025300.5+165258 ("Teegarden's Star")
- HIP 67593
- Gamma Draconis
Bullet Variable Star Monitoring
- U Her, W And, U And, EZ And (Mira variables)
- R CrB
- Delta Cepheid
- 5.2 hr session, Moon 98% phase
- CCD operation of -15 degC
- main objectives where to acquire images of selected nearby stars and variables as part of ongoing observing projects.
- opportunity taken to acquire images of Uranus and the Moon.
- More Notes

HD 5501 - Binary Eclipsing Variable



HD 5501 (Cassiopeia)

CCD Image
20s exposure, 2x2 binning , C Filter
2006-09-08 20:16h UT (#141018)

3 sets of measurements made in B, V, R filters as part of ongoing study on the
variable behavior of this eclipsing variable. [ HD 5501 Project ]


Back to Top


SS Cyg - Variable Star

Measurements made in B, V, R filters as part of ongoing study on variable behavior of this dwarf nova. (SS Cyg project)

SS Cyg (Cygnus)


 SS Cyg - Magnitude and Colour Variation between 2006-05-24 and 2006-09-01 (+)
Three outbursts are noted within this interval

Back to Top


NGC 7243 - Open Cluster

Central portion of NGC 7243 / Caldwell 16 (Lacerta)


CCD Image
60 sec exposure, 2x2 binning, C Filter
2006-09-08 21:46 h UT (#141148)

Back to Top


NGC 6781 - Planetary Nebula

NGC 6781  / Herschel H743-3 / PLN 41- 2.1 (Aquila)


CCD Image
3 x 3 min & 5 x 2 min exposure (summed), 2x2 binning , C Filter
2006-09-08 22:05 h UT (#141160-71)



NGC 6781 - detail


CCD Image (300% size)
Image details as above

Back to Top


4P/Faye - Comet

Comet 4P/Faye
(passing through starfield in Pisces)


CCD Image
3 x 2 min exposure, 2x2 binning (average combine), C Filter
2006-09-08 22:31 h UT (#141176-78)

Back to Top


CY Lyr - Variable Star

CY Lyr (Lyra)
Dwarf Nova CY Lyr is too faint to see in this 3 x 2 min image.
 Magnitude limit is ~ +15.8/+16


Annotated CCD Image
3 x 120s sec exposure (average combine), 2x2 binning, V Filter
2006-09-08 22:58 h UT (#141205-07)
[ AAVSO Star Chart for CY Lyr ]

Back to Top


Uranus

Uranus with Oberon/Titania
Oberon/Titania are too close to split (combined mag  ~ +13)
(Other moons are within glare from Uranus and can't be seen)


Annotated CCD Image (cropped)
30 sec exposure, 1x1 binning, C Filter
2006-09-08 23:10 h UT (#141213)

Back to Top


Moon

Moon, 97.6% Phase


CCD Image Mosaic (3 x 4)
0.11s sec exposure, 1x1 binning, B Filter
Unsharp Masked
2006-09-09 00:10 h UT (#141307-18)
Moon (detail)
CCD Image
0.11s sec exposure, 1x1 binning, B Filter, Unsharp Masked
2006-09-09 00:09 h UT (#141310)

CCD Image
0.11s sec exposure, 1x1 binning, B Filter, Unsharp Masked
2006-09-09 00:10 h UT (#141311)

Back to Top


NGC 752 - Open Cluster

Central portion of NGC 752 / Caldwell 28 (Andromeda)


Annotated CCD Image (cropped)
3 x 60 sec exposure (average combine), 2x2 binning, C Filter
2006-09-09 00:44 h UT (#141404-06)

Back to Top


AXP Monitoring (4U 0142+615 & 1E 2259+586)

Two Anomalous X-ray pulsers (AXPs),  4U 0142+615 and  1E 2259+586 (both lying in Cassiopeia) were checked for brightening. No indication of activity was observed at location of either AXP.   [AXP stars project

Star field of 1E 2259+586 area
no sign of AXP
CCD Image
2 min exposure,  C Filter
2006-09-09 00:52h UT (#141426)

Star field of 4U 0142+615 area
no sign of AXP
CCD Image
2 min exposure,  C Filter
2006-09-09  00:56h UT (#141430)

Back to Top


Nearby Stars

Set of images (7 x 10s exp, C Filter) acquired for astrometric measurements.
Part of a ongoing study to attempt to measure proper motion and annual parallax of Barnard's Star.  (Barnards Star Project).

Set of images (7 x 5s exp, C Filter) acquired for astrometric measurements.
Part of a ongoing study to attempt to measure proper motion and annual parallax of 61 Cygni  ( 61 Cygni Project )

Set of images (7 x 60s exp, C Filter) acquired for astrometric measurements.
Part of a ongoing study to attempt to measure proper motion and annual parallax of "Teegarden's star" (official name SO025300.5+165258)    ("Teegarden's Star" project).

Set of images (7 x 60s exp, C Filter) acquired for astrometric measurements.
Part of a ongoing study to attempt to measure proper motion and annual parallax of HIP 67593 (Bootes)     (HIP 67593 project).

Back to Top


Variable Stars

Set of BRV images collected as part of an ongoing study to develop a light curve for this Mira variable [U Her project

Set of BRVI Images collected as part of an ongoing study to develop a light curve for this Mira variable [W And project

Set of BRVI Images collected as part of an ongoing study to develop a light curve for this Mira variable [EZ And project

Set of BVRI Images collected as part of an ongoing study to develop a light curve for this Mira variable [U And project

Series of images of R CrB and a reference star (HIP 77373) were taken through B, V, R & I bands, as part of an ongoing study of this star

Back to Top
