Objects Session Notes
Bullet C/2006 M4 (Swan) - Comet
Bullet NGC 7000 (southern part) - Nebula ("North America nebula")
Bullet PLN 102- 2.1 - Planetary Nebula
Bullet M31 - Extragalactic Nova: M31 2006 14
Bullet NGC 7674 - Spiral Galaxy / Type 2 Seyfert galaxy
Bullet NGC 383 and adjacent galaxies ("Pisces Cloud")
Bullet NGC 7741 - Spiral Galaxy
Bullet Moon (82% phase)
Bullet Astrometric & Photometric Monitoring
- HD 5501/5513 (eclipsing variables)
- SS Cyg (dwarf novae)
- BL Lac (BL Lac blazer)
- U And (Mira variables)
- Z And, T Tau (variables)
- Ross 248/HH And, Groombridge 34, HIP 3829 (Nearby Stars)
- 8.4 hr session, largely operated under automated control
- CCD operation of -25 degC (at 72% average cooling). .
- main objective was to acquire an image mosaic of part of the North American Nebula (NGC 7000) as a prelude to a future mosaic imaging project in 2007.
- the other main objectives where to acquire images of specific variables stars and a current nova in M31 as part of ongoing photometric studies.
- opportunity was also taken to acquire images of certain deep sky objects and to obtain various follow-up images of current comets and nearby stars for astrometric analysis.
- More Notes
-

C/2006 M4 (Swan) - Comet

Comet C/2006 M4 (Swan)
(passing through starfield in Aquila)


CCD Image
5 x 60s exposure (average combine, aligned on comet),
2x2 binning, C filter,  Linear scale
2006-12-08 18:12h UT (#160039-43)




False Colour CCD Image
Log brightness scaling (3000 ADU range)
(details as above)

Back to Top


NGC 7000 (southern part) - Nebula ("North America nebula")

Southern Part of NGC 7000 - North America nebula (Cygnus)


CCD Image Mosaic-  4x4 frames (50% size)
180s exposure, 2x2 binning, C filter,  Linear scale. Slight Smoothing
2006-12-08 19:10h UT (#160077-92)
[larger image, 75% size]




False Colour CCD Image Mosaic
(image details as above)

Back to Top


PLN 102- 2.1 - Planetary Nebula

PLN 102-2.1 (Lacerta)


CCD Image
3 x 120s exposure (average combine),
2x2 binning, C filter,
2006-12-08 20:03h UT (#160116-18)




Negative CCD Image (250% size)
(details as above)

Back to Top


M31 - Extragalactic Nova : M31 2006 14

M31 part (Andromeda)
An extragalactic nova (M31 2006 14) was discovered in M31 on 2006/11/25.468
by Koichi Itagak, with an apparent magnitude of +17.5
(Extragalactic Novae page at Rochester Supernova site | Discovery Image | Reference: 2006-11a)

Image below (2006-12-08.85) was taken 13.4 days after discovery.
Location of object, shown by white marker, is consistent with nova recorded by K.Itagaki
Estimated magnitude (+16.0) is distinctly brighter than in earlier image (+17.1). Limiting mag of image +17.5


CCD Image
5 x 3 min exposure (average combine), 2x2 binning, C Filter
2006-12-08 20:17h UT (#160122-26)

Back to Top


NGC 7674 - Spiral Galaxy / Type 2 Seyfert galaxy

NGC 7674 (Pegasus)


Annotated CCD Image
3 x 3 min exposure (average combine), 2x2 binning, C Filter
2006-12-08 20:32h UT (#160128-32)



NGC 7674 in R Filter


Annotated CCD Image
120 sec exposure, 2x2 binning, R Filter
2006-12-08 20:28h UT (#160129)

Back to Top


NGC 383 and adjacent galaxies ("Pisces Cloud")

NGC 383 and adjacent  galaxies - "Pisces Cloud" (Pisces)
Cluster of mainly elliptical galaxies
NGC 373  (catalog mag +15.9), NGC 375 (catalog mag +14.5),
NGC 380 (catalog mag +12.6), NGC 382 (catalog mag +13.2),
NGC 383 (catalog mag +12.2), NGC 384 (catalog mag +13.0),
NGC 385 (catalog mag +13.0), NGC 386 (catalog mag +14.5),
NGC 387 (catalog mag +15.5), NGC 388 (catalog mag +15.6),
PGC 4021 (catalog mag +16.1), PGC 3950 (catalog mag +16.5)
Other galaxies (fainter than 16.5 mag) are not labelled


Annotated CCD Image Mosaic (2x2 frames)
3 x 3 min exposure (average combine), 2x2 binning, C Filter
2006-12-08 21:12h UT (#160149-60)

Back to Top


NGC 7741 - Spiral Galaxy

NGC 7741 (Pegasus)


CCD Image
5 x 3 min exposure (average combine), 2x2 binning, C Filter
2006-12-08 21:59h UT (#160184-88)

Back to Top


Moon  (82% phase)

Moon (82% phase)


CCD Image Mosaic (25% size)
0.11 sec exposure, 1x1 binning, B Filter
2006-12-09 01:55h UT (#160398-313)

Back to Top


Astrometric and Photometric Monitoring
