Objects Session Notes
Bullet C/2006 M4 (Swan) - Comet
Bullet M31 - Extragalactic Nova: M31 2006 14
Bullet UGC 14 - Spiral Galaxy & Supernova 2006sr
Bullet C/2006 L1 (Garradd) - Comet
Bullet PLN 164+31.1 - Planetary Nebula ("Headphones Nebula")
Bullet IC 405 - Flaming Star Nebula
Bullet NGC 1491 - Nebula
Bullet NGC 1514 - Planetary Nebula (Crystal Ball Nebula)
Bullet Astrometric & Photometric Monitoring
- HD 5501/5513 (eclipsing variables)
- SS Cyg (dwarf novae)
- BL Lac (BL Lac blazer)
- U And, W And (mira variables)
- Z And, T Tau (variable)
- Teegarden's Star, 61 Cyg (Nearby Stars)
- 6.6 hr session, largely operated under automated control
- CCD operation of -25 degC (at 66% average cooling). .
- main objective was to acquire additional frames to extend a large scale image mosaic of M31 collected during previous session, along with acquisition of images as part of variable star monitoring.
-
- More Notes
-

C/2006 M4 (Swan) - Comet

Comet C/2006 M4 (Swan)
(passing through starfield in Aquila)


CCD Image
5 x 60s exposure (average combine, aligned on comet),
2x2 binning, C filter,  Linear scale
2006-12-15 18:54h UT (#163012-16)




False Colour CCD Image
Log brightness scaling (3000 ADU range)
(details as above)

Back to Top


M31 - Extragalactic Nova : M31 2006 14

M31 part (Andromeda)
An extragalactic nova (M31 2006 14) was discovered in M31 on 2006/11/25.468
by Koichi Itagak, with an apparent magnitude of +17.5
(Extragalactic Novae page at Rochester Supernova site | Discovery Image | Reference: 2006-11a)

Image below (2006-12-15.82) shows that nova object (shown by white marker)
Estimated magnitude +17.1 . Limiting Mag +17.5


CCD Image
7 x 3 min exposure (average combine), 2x2 binning, C Filter
2006-12-15 19:47h UT (#163061-65)

Back to Top


UGC 14 - Spiral Galaxy & Supernova 2006sr

UGC 14 (Pegasus) with SN 2006sr
2006sr was discovered 2006/12/12.95 by Doug Rich
(Rochester Supernova site | Discovery Image | Reference Image)

Image below (2006-12-15.84) was taken 3 days after discovery.
Estimated magnitude of 2006sr  is  >+16.5 (C filter).

Annotated CCD Image
3 x 180s exposure (average combine), 2x2 binning, C Filter
2006-12-15 20:15 hUT (#163085-87)

Back to Top


C/2006 L1 (Garradd) - Comet

Comet C/2006 L1 (Garradd)
(passing through starfield in Auriga)
The comet appears trailed in this 180 sec exposure due to its
motion relative to background stars


CCD Image
180s exposure, 2x2 binning, C filter,  Linear scale
2006-12-15 21:51h UT (#163173)

Back to Top


PLN 164+31.1 - Planetary Nebula ("Headphones Nebula")

PLN 164+31.1  (Lynx)
Also known as  Jones-Emberson 1 (JE-1) , PNG 164.8+31.1, PK 164+31.1

CCD Image
4 x 180s exposure (average combine), 2x2 binning, C Filter
Lightly Smoothed (blur function)
2006-12-15 22:33 hUT (#163196-200)

Back to Top


IC 405 - Flaming Star Nebula

IC 405 / Flaming Star Nebula (Auriga)
Caldwell 31


IC 405 - detail
False Colour CCD Image Mosaic (3x4)
Square Root brightness scaling
180s exposure, 2x2 binning, C Filter
2006-12-15 23:18 hUT (#163211-22)

Back to Top


NGC 1491 - Nebula

NGC 1491 (Perseus)

CCD Image
3 x 180s exposure (average combine), 2x2 binning, C Filter
2006-12-15 23:46h UT (#163226-28)
NGC 1491 - detail
False CCD Image
Square root brightness scaling
Image Details as above

Back to Top


NGC 1514 - Planetary Nebula (Crystal Ball Nebula)

NGC 1514 (Taurus)

CCD Image
3 x 180s exposure (average combine), 2x2 binning, C Filter
2006-12-15 23:58 hUT (#163232-34)

Back to Top


Astrometric and Photometric Monitoring
