David's Astronomy Pages
CCD Images - Session 198 (2007-05-19)

Previous Imaging Session
Images
(S197)
  Home
Images
Sessions
  Home
Home
Page
  Next Imaging Session
Images (S199)

Objects Session Notes
Day Time Session
Bullet Sunspot 956


Night Time Session
Bullet Venus
Bullet Moon
Bullet M53 - Globular Cluster
Bullet M58 - Spiral Galaxy
Bullet M90 - Spiral Galaxy
Bullet Astrometric & Photometric Monitoring
- U Her, U And (Mira variables)
- SS Cyg (Dwarf Nova)
- And Z, AM CVn (variables)
- BL Lac (Blazar)

- Barnards Star, 61 Cyg, Gamma Dra,  HIP 67593, Wolf 359 (Nearby Stars)

Digital Photos
Bullet Mercury (from 1 day earlier)
Bullet Moon (from 1 night later)

Bullet Moon
Bullet Moon & Venus

Bullet Moon (from 1 night later)
- Day Time Session, 0.5 hr
- CCD operation of -5 degC (at 72% average cooling). .
- main objective was to acquire images of sunspot group 956
-
- Night Time Session, 5.0 hr
- CCD operation of -20 degC (at 78% average cooling). .
- main objective was to acquire test new scripts for monitoring star position & S/N and for performing a guide operation in between image frames, and collect to acquire further baseline images of the exosolar planet host star HAT-P-2
- secondary objective was to acquire images of selected variable stars and nearby stars for photometric and astrometric  monitoring.
- opportunity was taken to take a acquire gallery images of M53, M85, M90, and images of Venus & New Moon.
- More Notes
-

Day Time Session

Sunspot 956

Sun
with Sunspot Group 956

[ see equivalent SOHO/MDI Image for 2007-05-19
CCD Image Mosaic (30% size)
0.2s exposure, 2x2 binning, Solar Filter + V filter
2007-05-19 14:34h UT (#198063-74)

Sun Spot 956
Sunspot Group through Solar Filter + V Filter
CCD Image  (60% size)
0.2s exposure, 1x1 binning, Solar Filter + V filter
2007-05-19 14:42h UT (#198104)

False Colour CCD Image
Image details as above
Cropped, Unsharp Mask Sharpened,
Colourised

Back to Top


Night Time Session

Venus

Venus
(mag -4.2, 60% phase, angular diameter 19")
CCD Image (with insert at 300% size)
0.11s exposure, 1x1 binning, B Filter
2007-05-19  21:43 h UT (#198127)
Previous Image of Venus - 2007-04-27
(mag -4.1, 70% phase, angular diameter 16")
Earlier CCD Image (with insert at 300% size)  (#192068)

Previous Image of Venus - 2007-03-03
(mag -4.0, 86% phase, angular diameter 12")
Earlier CCD Image (with insert at 300% size) (#180010)

Back to Top


Moon

Moon (13% phase)

 CCD Image Mosaic (60% size)
0.2 sec exposure, 2x2 binning, B Filter,
2007-05-19 21:46h UT (#198128-40)

  Moon - detail
 CCD Image
0.2 sec exposure, 1x1 binning, V Filter,
2007-05-19 21:54h UT (#198150)

Back to Top


M53 - Globular Cluster

M53 (Coma Berenices)

 CCD Image, linear brightness scaling
3 x 60 sec exposure (average combine), 2x2 binning, C Filter
2007-05-19 22:12h UT (#198165-67)

  M53 - detail
 CCD Image, square root brightness scaling
(image details as above)

 False Colour CCD Image
Square root brightness scaling,
False Colour (Inverse Spectrum)
(image details as above)

Back to Top


M58 - Spiral Galaxy

M58 (Virgo)

 CCD Image
3 x 180 sec exposure (average combine), 2x2 binning, C Filter,
linear brightness scaling
2007-05-19 23:43h UT (#198299-301)

  M58 - false colour
  False Colour CCD Image
Log brightness scaling,
False Colour (Inverse Spectrum)
(image details as above)

Back to Top


M90 - Spiral Galaxy

M90 (Virgo)

 CCD Image
3 x 180 sec exposure (average combine), 2x2 binning, C Filter,
linear brightness scaling
2007-05-20 00:05h UT (#198310-15)

  M90 - false colour
with small irregular galaxy IC 3583 at top/right centre
  CCD Image
Square Root brightness scaling,
False Colour (Inverse Spectrum)
(image details as above)

  M90 & Cosmic Ray
  CCD Image
180 sec exposure, 2x2 binning, C Filter,
2007-05-20 00:08h UT (#198313)

Back to Top


Astrometric and Photometric Monitoring

Back to Top




Digital Photos

Mercury (from 1 day earlier)

Mercury (from 1 day earlier)
Digital Photo (EOS 400D)
1/3s, f/4, ISO 400, 70mm (cropped)
2007-05-18  21:47 h UT (#IMG_0470)

Back to Top


Moon (from 1 night earlier)

Moon, 1 night earlier (6.4% phase)

Digital Photo (EOS 400D)
1/10s, f/8, ISO 400, 300mm (75% size, cropped)
2007-05-18  21:44 h UT (#IMG_0465)

Back to Top


Moon & Venus

Moon & Venus
(Separation 3 degrees)

Digital Photo (EOS 400D)
1/40s, f/8, ISO 400, 190mm (cropped)
2007-05-19  21:05 h UT (#IMG_0480)
[Larger Image]

Back to Top


Moon

Moon  (13% Phase)

Digital Photo (EOS 400D)
1/80s, f/8, ISO 400, 280mm (80% size, cropped)
2007-05-19  21:10 h UT (#IMG_0484)

Back to Top


Moon (from 1 night later)

Moon, 1 night later (21% Phase)

Digital Photo (EOS 400D)
1/40s, f/8, ISO 400, 300mm (75% size, cropped)
2007-05-20  21:33 h UT (#IMG_0498)

Back to Top
