David's Astronomy Pages
CCD Images - Session 233 (2007-11-05)

Previous Imaging Session
Images
(S232)
  Home
Images
Sessions
  Home
Home
Page
  Next Imaging Session
Images (S234)

Objects Session Notes
Bullet Comet 17P/Holmes
Bullet Moon
Bullet Astrometric & Photometric Monitoring
- SS Cyg (dwarf nova)
- BL Lac (Blazar)
- U Her (mira variable)
- RX And, TT Ari (variables)
- Barnard's Star, Teegarden's Star (Nearby Star)


-
(unsuccessful attempts at - U Her due to cloud)
- Evening session (2.3hr), thin cloud / poor transparency as per previous evening. Session cut short by developing cloud.  Followed by early morning session (1.6 hr) with attempted piggy-backed digital camera imaging.
CCD operation of -20 degC (at 67% average cooling).
- main objective of the session was to acquire follow up images of the comet 17P/Holmes
-secondary objectives were to acquire images of certain selected stars of ongoing photometric and astrometric analysis

Comet 17P/Holmes

Comet 17P/Holmes  (passing through starfield in Perseus)
(Mosaic collected under poor sky condition,
causing significant light balance problems)

Part of CCD Image Mosaic (3 x 3)
Linear Scale
20s exposure, 2x2 binning, C Filter,
2007-11-05 19:45h UT (#233063-79)



Earlier image of Comet 17P/Holmes from 7 days previous
(at same scale)

CCD Image
5 x 10s exposure (average combine),
2x2 binning, C Filter, Log Scale
2007-10-29 04:43h UT (#228038-42)
[ Full Size ]


Comet 17P/Holmes - Detail

CCD Image (50% size)
Linear Scale
7 x 60s exposure (average combine), 1x1 binning, C Filter,
2007-11-05 18:56h UT (#233015-21)

Isophote Lines (2007-11-05)
False Colour CCD  Image (50% size)
Square Root brightness scaling & Isophote Contoured,
False Colour (Inverse Spectrum)
7 x 60s exposure (average combine), 1x1 binning, C Filter,
2007-11-05 18:56h UT (#233015-21)
Isophote Lines from earlier session (2007-10-30)
False Colour CCD  Image (50% size)
Square Root brightness scaling & Isophote Contoured,
False Colour (Inverse Spectrum)
2007-10-30 04:44h UT (#229028)


Comet 17P/Holmes - Rotational Gradient Processing

Normal Image
CCD Image (50% size)
Linear Scale
7 x 60s exposure (average combine), 1x1 binning, C Filter,
2007-11-05 18:56h UT (#233015-21)

Processed CCD Image  (50% size)
Rotational Gradient Processing, 20 deg
(Image details as above)

Detail
Processed CCD Image  (100% size)
Rotational Gradient Processing, 20 deg
Cropped
(Image details as above)


Comet 17P/Holmes - Montage of Images


CCD Image Montage (30% size)
[Larger Image,  50% size]



Back to Top


Moon

Moon (139% Phase Angle)


 CCD Image Mosaic (35% size)
0.11s, 1x1 binning, V Filter
Unsharp Masked
2007-11-06 06:17 hUT (#233184-95)

Back to Top


Astrometric and Photometric Monitoring

Back to Top
