CCD Images - Session 235 (2007-11-16)

Previous Imaging Session
Images
(S234)
  Home
Images
Sessions
  Home
Home
Page
  Next Imaging Session
Images (S236)

Objects Session Notes
Bullet 17P/Holmes - Comet
Bullet 93P/Lovas - Comet
Bullet NGC 1058 - Spiral Galaxy
Bullet UGC 12846 - Spiral Galaxy with Supernova 2007od
Bullet IC 1613 - irregular galaxy, local group
Bullet Astrometric & Photometric Monitoring
- SS Cyg (dwarf nova)
- BL Lac (Blazar)
- U And, W And (mira variable)
- RX And, TT Ari (variables)
- CY Lyr, TZ Lyr, Z And (variables)
- Barnard's Star, 61 Cyg, Teegarden's Star (Nearby Stars)
- Evening session (7.4hr), operated under automated control for majority of session. Cold for 5-6 hrs, but then temperatures rose by 5 deg and seeing deteriorated as a warm front came through.  Eventually thin cloud developed.
CCD operation of -25 degC (at 67% average cooling).  Backed off to -20 degC from last part of session.
- main objective of the session was to acquire an image mosaic of comet 17P/Holmes (now grown to larger than the apparent diameter of the moon)
-secondary objectives were to acquire images of certain selected stars of ongoing photometric and astrometric analysis
-opportunity was also taken to acquire gallery images of Caldwell 51 (IC 1613), and certain other comets and deep sky objects.

17P/Holmes - Comet

Comet 17P/Holmes  - passing through starfield in Perseus,  2007-11-16
bright star in bottom left corner is the star Mirfak (Alpha Persei)

Part of CCD Image Mosaic (6 x 7), 35% size
30s exposure, 2x2 binning, C Filter,  Linear Scale
2007-11-16 23:31h UT (#235301-42)
[ Full Mosaic, 70% Size ]



Part of CCD Image Mosaic (6 x 7), 70% size
30s exposure, 2x2 binning, C Filter, Linear Scale
2007-11-16 23:31h UT (#235301-42)
[ Full Size ]


Comet 17P/Holmes - Central Detail

CCD Image (50% size), Linear Scale
7 x 60s exposure (av. combine), 1x1 binning, C Filter,
2007-11-16 19:23h UT (#235106-12)

Isophote Lines
False Colour CCD  Image (50% size)
Square Root brightness scaling & Isophote Contoured,
False Colour (Inverse Spectrum). Details as above

Processed CCD Image  (50% size)
Rotational Gradient Processing, 15 deg
(Image details as above)


Comet 17P/Holmes - Montage of Images -  2007-10-25 to 2007-11-16


CCD Image Montage (30% size)
Images from 2007-10-25 to 2007-11-16
2x2 binning, various exposures
[Larger Image,  50% size]



Back to Top


93P/Lovas - Comet

Comet 93P/Lovas (moving through starfield in Andromeda)
Estimated mag +14.9
CCD Image,
3 x 120 sec exposure (average combine), 2x2 binning, C Filter
2007-11-16  20:57h UT (#235197-99)

Animation showing motion of 93P/Lovas over 121 minutes
CCD Image Animation (2 frames)
3 x 120 sec exposure (average combine),
2x2 binning, C Filter, Linear Scale
2007-11-16  20:57 h UT (#235197-99)
2007-11-16  22:58h UT (#235292-94)

Back to Top


50P/Arend - Comet

Comet 50P/Arend  (moving through starfield in Andromeda)
CCD Image,
3 x 120 sec exposure (average combine), 2x2 binning, C Filter
2007-11-16  21:09h UT (#235203-05)

Back to Top


NGC 1058 - Spiral Galaxy

NGC 1058 (Perseus)

2 x 180s exposure (average combine),
2x2 binning, C Filter, Linear Scale
2007-11-16 21:29 hUT (#235222-23)


Earlier Image of NGC 1058 (Perseus)
The bright star like object just to upper right of galaxy centre
is amalgamation of  light from a foreground star in our galaxy and
supernova 2007gr in NGC 1058 galaxy.
The image does not have sufficient resolution to
separate the two objects, though a slight elongation is noted.
(Rochester Supernova site | Discovery Image )

4 x 120s exposure (average combine),
2x2 binning, C Filter, Linear Scale
2007-08-22 22:55 hUT (#207096-99)

Back to Top


UGC 12846 - Spiral Galaxy with Supernova 2007od

UGC 12846 with Supernova 2007od (Pegasus)
Galaxy UGC 12846 is very faint, but the supernova is very clear.
(Note : stars slightly trailed)

2007od is a Type 2 Supernova 2007/11/02.85 by Crni Vrh Observatory at mag +13.9 (R)
(Rochester Supernova site | Discovery Image | )

Image below (2007-11-16.95) was taken 14.1 days after discovery.
Measured magnitude of 2007od is +14.2 (C)

Annotated CCD Image
3 x 180s exposure (average combine), 2x2 binning, C Filter,
2007-11-16 22:41 hUT (#235287-89)


Back to Top


IC 1613 - irregular galaxy, local group

IC 1613 / Caldwell 51 (Cetus)
1 min exposure


Annotated CCD Image Mosaic (3x3), 50% size
60sec, 2x2 binning, C Filter
2007-11-17 00:21hUT (#235353-61)



IC 1613 - detailed image
21 min exposure
(location of image shown by rectangular box above)


 CCD Image
slight blur, contrast adjusted
7 x 3 min (average combine), 2x2 binning, C Filter
2007-11-17 00:03 hUT (#235346-52)


 CCD Image - Normal View
(Image details as above)




 CCD Image - negative
(Image details as above)

Back to Top


Astrometric and Photometric Monitoring

Back to Top


This Web Page: CCD Images - Session 235  (2007-11-16)
Last Updated : 2015-05-16
Site Owner : David Richards
