CCD Images - Session 362 (2009-04-08)

Previous Imaging Session
Images
(S361)
  Home
Images
Sessions
  Home
Home
Page
  Next Imaging Session
Images
 (S363)

Objects Session Notes
Bullet C/2007 N3 (Lulin) - Comet
Bullet NGC 6543 - Planetary Nebula (Caldwell 6, "Cats Eye Nebula", H IV-37)
Bullet NGC 6552 - Spiral Galaxy
Bullet C/2009 F6 (Yi-SWAN) - Comet
Bullet NGC 2403 - Spiral Galaxy (Caldwell 7)
Bullet IC 342 - Spiral Galaxy (Caldwell 5)
Bullet NGC 4236 - Spiral Galaxy (Caldwell 3)
Bullet Moon
Bullet R Leo - Star
Bullet Astrometric & Photometric Monitoring
- SS Cyg (dwarf nova)
- CI Cyg (mira variables)}

- attempts at BL Lac, S Cyg (failed - poor sky transparency/cloud)

- Late Evening Session (3.2 hrs),
- Operated under automated control / remote control
- Ambient Temperature  1 deg C, then rising to 3 deg C
Thin cloud blocking Southern Sky, cloud developing by dawn
Full Moon
- CCD operation -25 degC (at 66% average cooling).
- main objective of the session was to collect images of gallery objects (mainly Caldwell objectives) that were not easily acquired using previous 8" LX200
- secondary objective of the session was  to acquire images of key selected stars for ongoing photometric and astrometric analysis.
- opportunity taken to acquire images of Comet C/2009 F6 (Yi-SWAN)
-
-

C/2007 N3 (Lulin) - Comet

C/2007 N3 (Lulin) passing through starfield in Gemini


Annotated CCD Image (Cropped, Linear Scale)
3 x 30s sec exposure (average combine), 3x3 binning, C Filter
2009-04-08 21:26 h UT (#362004-06)
12" LX200R  (at f/5.7) + ST-10XME



Back to Top


NGC 6543 - Planetary Nebula ("Cats Eye Nebula", Caldwell 6, Herschel IV-37)

NGC 6543  /  Caldwell 6  /  Herschel IV-37  (Draco)


Annotated CCD Image (Cropped to central area)
3 x 30s sec exposure (average combine), 3x3 binning, C Filter
2009-04-08 21:31 h UT (#362010-12)
12" LX200R  (at f/5.7) + ST-10XME



NGC 6543  - detail


CCD Image (100% size, cropped)
3 x 10s sec exposure (average combine), 2x2 binning, C Filter
2009-04-08 21:314 h UT (#362016-18)
12" LX200R  (at f/5.7) + ST-10XME




CCD Image (200% size, logscale, cropped)
Image details as above



  NGC 6543  - false colour


False Colour CCD Image
 (200% size enlargement, Cropped to central area, log scaling)
Image details as above



  NGC 6543  - Spectra


CCD Spectral mage (cropped)
 30s sec exposure, 2x2 binning, S Filter (Star Analyser 100)
2009-04-08 21:314 h UT (#362022
12" LX200R  (at f/5.7) + ST-10XME



Back to Top


NGC 6552 - Spiral Galaxy

NGC 6552 with adjacent planetary Nebula NGC 6543  (Draco)


Annotated CCD Image (Cropped to central area)
3 x 30s sec exposure (average combine), 3x3 binning, C Filter
2009-04-08 21:31 h UT (#362010-12)
12" LX200R  (at f/5.7) + ST-10XME



NGC 6552  - detail


Annotated CCD Image (200% size, Cropped)
Image details as above

Back to Top


C/2009 F6 (Yi-SWAN) - Comet

C/2009 F6 (Yi-SWAN) passing through starfield in Cassiopeia


Annotated CCD Image (Cropped to central area)
30s sec exposure (single frame), 3x3 binning, C Filter
2009-04-08 21:43 h UT (#362030)
12" LX200R  (at f/5.7) + ST-10XME



C/2009 F6 (Yi-SWAN) - detail


 CCD Image (Cropped to central area)
3x 90s sec exposure (average combine), 3x3 binning, C Filter
2009-04-08 21:43 h UT (#362031-33)
12" LX200R  (at f/5.7) + ST-10XME



C/2009 F6 (Yi-SWAN) - animation showing motion over 10 minute interval


 CCD Image (Cropped to central area)
30s sec exposure, 3x3 binning, C Filter
2009-04-08 21:48 to 21:57 h UT (#362034-48)
12" LX200R  (at f/5.7) + ST-10XME



Back to Top


NGC 6543 - Planetary Nebula ("Cats Eye Nebula", Caldwell 6)

NGC 6543 / Caldwell 6 (Draco)


Annotated CCD Image (Cropped to central area)
3 x 30s sec exposure (average combine), 3x3 binning, C Filter
2009-04-08 21:31 h UT (#362010-12)
12" LX200R  (at f/5.7) + ST-10XME



NGC 6543  - detail


CCD Image (Cropped to central area)
3 x 10s sec exposure (average combine), 2x2 binning, C Filter
2009-04-08 21:314 h UT (#362016-18)
12" LX200R  (at f/5.7) + ST-10XME




CCD Image
(200% size enlargement, Cropped to central area, log scaling)
Image details as above



  NGC 6543  - false colour


False Colour CCD Image
 (200% size enlargement, Cropped to central area, log scaling)
Image details as above



  NGC 6543  - Spectra


CCD Spectral mage (cropped)
 30s sec exposure, 2x2 binning, S Filter (Star Analyser 100)
2009-04-08 21:314 h UT (#362022
12" LX200R  (at f/5.7) + ST-10XME



Back to Top


NGC 2403 - Spiral Galaxy (Caldwell 7)

NGC 2403 / Caldwell 7 / Herschell V-44  (Camelopardalis)


CCD Image (60% size reduction, Linear Scale)
5 x 90s sec exposure (average combine), 3x3 binning, C Filter
2009-04-08 22:31 h UT (#362064-68)
12" LX200R  (at f/5.7) + ST-10XME



NGC 2403 - detail


CCD Image (60% size reduction, Square Root Scale)
Image details as above




False colour CCD Image (60% size reduction, Log Scale)
Image details as above




False colour CCD Image (60% size reduction, Log Scale)
Image details as above



NGC 2403 - colour images


CCD Colour Image (RGB Combine, cropped to central area)
1 x 90s (Red), 1 x 90s (Green), 1 x 120s (Blue),  3x3 binning
2009-04-08 22:38 h UT (#362069-71)
12" LX200R  (at f/5.7) + ST-10XME




CCD Colour Image (LRGB combine, cropped to central area)
5 x 90s (Luminance, C), 1 x 90s (Red), 1 x 90s (Green), 1 x 120s (Blue),
3x3 binning
2009-04-08 22:38 h UT (#362069-71)
12" LX200R  (at f/5.7) + ST-10XME




CCD Colour Image (LRGB combine in  AIP4WIN, cropped to central area)
5 x 90s (Luminance, C), 1 x 90s (Red), 1 x 90s (Green), 1 x 120s (Blue),
3x3 binning, Luminance Gamma Adjusted
2009-04-08 22:38 h UT (#362069-71)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


IC 342 - Spiral Galaxy (Caldwell 5)

IC 342 / Caldwell 5  (Camelopardalis)


CCD Image (60% size reduction, Linear Scale)
5 x 90s sec exposure (average combine), 3x3 binning, C Filter
2009-04-08 22:31 h UT (#362064-68)
12" LX200R  (at f/5.7) + ST-10XME



IC 342 - detail


Negative CCD Image (60% size reduction, Enhanced Gamma Scale)
Image details as above




False colour CCD Image (60% size reduction, Log Scale)
Reverse Spectrum Colour Bar
Image details as above

Back to Top


NGC 4236 - Spiral Galaxy (Caldwell 3)

NGC 4236 / Caldwell 3  (Draco)


CCD Image (60% size reduction, Linear Scale)
3 x 90s sec exposure (average combine), 3x3 binning, C Filter
2009-04-08 22:31 h UT (#362085-89)
12" LX200R  (at f/5.7) + ST-10XME



NGC 4236 - detail


Negative CCD Image (60% size reduction)
Image details as above

Back to Top


Moon

Full Moon
(99.4% phase)


CCD Image Mosaic (50% size reduction, 2x3 mosaic)
0.12s sec exposure, 3x3 binning, U Filter
2009-04-09 00:26h UT (#362143-48)
12" LX200R  (at f/5.7) + ST-10XME
[ Full Size, Sharpened


Back to Top


R Leo - Star

Star Name
(designation)
Spectra Type
(catalog)

Star Spectra  (Star Analyser 100)


Image details
R Leo  M6-M9 Image 3 x 10s, 2x2 binning
2009-04-08 22:13hUT (#362106-08)
12" LX200R  (at f/5.7) + ST-10XME
R Leo  M6-M9 Image 200% size enlargement
(simulating the size of a
1x1 binned spectral image)
image details as above
R Leo  M6-M9 Image 2nd order spectra
image details as above

R Leo

(Earlier
 Image)
 M6-M9 Image 3 x 60s, 1x1 binning
2008-04-24 22:13hUT (#284043-45)
8" LX200 Classic (at f/6.6) + ST-7E


Star Name
(designation)
Spectra Type
(catalog)

Spectra Lines  ( Star Analyser 100)


Image Date/No. & Notes

R Leo

1st
 order spectra
 M6-M9 Image 10s, 2x2 binning
2009-04-08 22:13hUT (#362106)
12" LX200R  (at f/5.7) + ST-10XME
R Leo

1st + 2nd
 order spectra
 M6-M9 Image 10s, 2x2 binning
2009-04-08 22:13hUT (#362106)
12" LX200R  (at f/5.7) + ST-10XME

R Leo

(Earlier
 Image)
 M6-M9 Image 3 x 60s, 1x1 binning
2008-04-24 22:13hUT (#284043-45)
8" LX200 Classic (at f/6.6) + ST-7E



Back to Top


Astrometric and Photometric Monitoring
