Objects Session Notes
Bullet C/2009 F6 (Yi-SWAN) - Comet
Bullet NGC 2419 - Globular Cluster
Bullet Hubble Deep Field (HDF) - North
Bullet NGC 3877 - Spiral Galaxy
Bullet Galaxies near SS Cyg
Bullet NGC 5897 - Globular Cluster (Herschel VI-19)
Bullet M80 - Globular Cluster
Bullet M97 - Planetary Nebula (Owl Nebula)
Bullet Astrometric & Photometric Monitoring
- SS Cyg, U Gem (dwarf nova)
- U Her (mira variables)
- DY Per (variables)


- Late Evening Session (3.6 hrs),
- Operated under automated control / remote control. Problems with wireless link required several visit to observatory
- Ambient Temperature  5 deg C, decreasing to 2.5 deg C by end of session.   Poor seeing at times
- CCD operation -25 degC (at 66% average cooling).
- main objective of the session was to collect images of G2V stars using different filters in order to determine appropriate colour balance corrections
- secondary objective of the session was  to acquire images of key selected stars for ongoing photometric and astrometric analysis.
- opportunity taken to acquire images of certain low declination objects
-
-

C/2009 F6 (Yi-SWAN) - Comet

C/2009 F6 (Yi-SWAN) passing through starfield in Perseus


CCD Image (Cropped to central area)
3 x 30s sec exposure (average combine), 3x3 binning, C Filter
2009-04-21 22:00 h UT (#364036-38)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


NGC 2419 - Globular Cluster

NGC 2419 (Lynx)

CCD Image (50% size scaling)
7 x 10 sec exposure (average combine), 2x2 binning, C Filter
2009-04-21 23:50 h UT  (#364142-55)
12" LX200R  (at f/5.7) + ST-10XME



NGC 2419  - detail

CCD Image (cropped)
Image details as above

Back to Top


Hubble Deep Field (HDF) - North

Hubble Deep Field (Ursa Major)
In December 1995 the Hubble Space Telescope assembled an image of a small 2x2' region in Ursa Major
over the course of 10 consecutive days. Known as the Hubble Deep Field (HDF), it was was the deepest ever field
taken at that time and showed tens of thousands of galaxies out to a distance of 13 billion light years.

With an image of 24 minute (total) exposure, objects as faint as +19 are visible, including at least 2 of the brightest galaxy objects in HDF

(position of HDF area shown as red polygon)
CCD Image (50% size reduction)
12 x 2 mins (average combine), 3x3 binning, clear filter
2009-04-21  22:52 h UT (#364113-26)
12" LX200R  (at f/5.7) + ST-10XME
 [ Full Size Image ]

Detail view of HDF area Hubble Image
Image  Image
Negative CCD Image (enlarged, cropped)
Image details as above
Hubble Deep Field Image
(reduced from HST WFPC2 Mosaic
HST Gallery Image

Galaxies in HDF with measured magnitudes

Previous attempt at imaging HDF ( 2006-05-04)
(position of HDF area shown as red polygon)
CCD Image
8 x 2 mins (average combine), clear filter
2006-05-04  00:42 h UT (#121166-75)
8" LX200 Classic + ST-7E
Other HDF atempts : (2005-06-10).

Back to Top


NGC 3877 - Spiral Galaxy

NGC 3877 (Ursa Major)

CCD Image ( 50% size scaling)
60 sec exposure (single frame), 3x3 binning, C Filter
2009-04-22 00:03 h UT  (#364176)
12" LX200R  (at f/5.7) + ST-10XME



NGC 3877 - detail

CCD Image ( cropped)
Image details as above

Back to Top


Galaxies near SS Cyg

Star field surrounding SS Cyg (Cygnus)

CCD Image (slightly cropped)
6 x 60 sec exposure (average combine), 3x3 binning, C Filter
2009-04-22 00:28h UT  (#364227-32)
12" LX200R  (at f/5.7) + ST-10XME



Detail with galaxies

CCD Image (200% size enlargement, cropped)
Image details as above



CCD Image (200% size enlargement, cropped)
Image details as above

Back to Top


NGC 5897 - Globular Cluster (Herschel VI-19)

NGC 5897 (Libra)
Alias: Herschel VI-19, Hidden Treasures catalog object 76
[ Herschel 400 Objects ]  [ Hidden Treasures ]

CCD Image (50% size scaling)
7 x 30 sec exposure (average combine), 3x3 binning, C Filter
2009-04-2200;48h UT  (#364255-61)
12" LX200R  (at f/5.7) + ST-10XME



NGC 5897 - detail

CCD Image (cropped)
Image details as above

Back to Top


M80 - Globular Cluster

M80 (Scorpius)

CCD Image (logscale, 50% size scaling)
5 x 30 sec exposure (median combine), 3x3 binning, C Filter
2009-04-22 00:57 h UT  (#364264-68)
12" LX200R  (at f/5.7) + ST-10XME



M80 - detail

CCD Image (logscale, cropped)
Image details as above

Back to Top


M97 - Planetary Nebula (Owl Nebula)

M97 (Ursa Major)

CCD Image (50% size scaling)
5 x 90 sec exposure (average frame), 3x3 binning, C Filter
2009-04-22 01:05 h UT  (#364272-75)
12" LX200R  (at f/5.7) + ST-10XME



M97 - detail

CCD Image (cropped)
Image details as above

Back to Top


Astrometric and Photometric Monitoring
