CCD Images - Session 379 (2009-07-30)

Previous Imaging Session
Images
(S378)
  Home
Images
Sessions
  Home
Home
Page
  Next Imaging Session
Images
 (S380)

Objects Session Notes
Bullet M57 - Planetary Nebula (Ring Nebula)
Bullet NGC 6822 - Irregular Galaxy (Barnard's Galaxy)
Bullet M27 - Planetary Nebula (Dumbbell Nebula)
Bullet SAC B137-8 - Dark Nebula
Bullet 22/P Kopff - Comet
Bullet Jupiter & moons
Bullet Photometric Monitoring - Variables
- RZ And, U And, W And, FO Aql, AM CVn,  CI Cyg
- SS Cyg, AM Her, SS Her, BL Lac, CY Lyr,
- RU Peg, GK Per, FG SgeDY Per, GK Per
- FG Sge, U Sge, V Sge, WZ Sge, ER UMa
Bullet Photometric Monitoring - Nearby Stars
- Barnards Star, 61 Cyg, Gliese 412, Groombridge 1618, Groombridge 1830
- Night time session (3.8 hrs). Clear skies. Some NLC in extreme northern skies before dawn
- Operated in observatory under semi-automated control for first part of session, then with automated control / remote monitoring
- Ambient Temperature  initially 12 deg C, decreasing to 8 deg C by end of observing session.
- CCD operation -20 degC (at 71% average cooling).
- main objective of the session was to acquire images of key selected stars for ongoing photometric and astrometric analysis.
- opportunity taken to acquire images of Jupiter, Comet 22/P Kopff and a number of deep sky objects, including Caldwell 57 (NGC 6822)

M57 - Planetary Nebula (Ring Nebula)

M57 (Lyra)

CCD Image (50% size reduction, square root scaling)
3x30 sec exposure (average combine), 3x3 binning, C Filter
2009-07-30 22:42 h UT  (#379349-52)
12" LX200R  (at f/5.7) + ST-10XME
[Full Size Frame]



M57 - detail

CCD Image
Cropped to Central Area, Sharpened (Unsharp Mask)

22 x 30 sec exposure (average combine), 1x1 binning, C Filter
2009-07-30 22:07 h UT  (#379295-348)
12" LX200R  (at f/5.7) + ST-10XME



Colour CCD Image (LRGB)
Cropped to Central Area, Sharpened (Unsharp Mask)
Luminance : 22 x 30 sec exposure (average combine), 1x1 binning, C Filter
Red: 4 x 30s, Green : 5 x 30s, Blue: 4 x 45s (average combine), 1x1 binning
2009-07-30 22:07 h UT  (#379295-348) + (colour #379323-41)
12" LX200R  (at f/5.7) + ST-10XME
(RGB frame enlargement factor x1.0096 wrt to C Frame)



Colour CCD Image (RGB)
Red: 4 x 30s, Green : 5 x 30s, Blue: 4 x 45s (average combine), 1x1 binning
2009-07-30 22:07 h UT  (#379323-41)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


NGC 6822 - Irregular Galaxy (Barnard's Galaxy) - Local Group

NGC 6822 / Caldwell 57 (Sagittarius)
CCD Image 50% size reduction)
6 x 120 sec exposure (average combine), 3x3 binning, C Filter
2009-07-30 23:53 h UT  (#379451-58)
12" LX200R  (at f/5.7) + ST-10XME
[Larger View, 75%]
NGC 6822 - Earlier Image (ST7 CCD)
CCD Image
6 x 60 sec exposure (average), clear filter
2005-08-14  22:28 h UT (#92109-14)

Back to Top


M27 - Planetary Nebula (Dumbbell Nebula)

M27 (Vulpecula)

CCD Image (50% size reduction)
4 x 20 sec exposure (average combine), 3x3 binning, C Filter
2009-07-31 00:25 h UT  (#379478-82)
12" LX200R  (at f/5.7) + ST-10XME



M27 - detail

CCD Image / Cropped to Central Area
Image details as above



CCD Image / Cropped to Central Area
Log scaling

Image details as above
[ full frame image ]

Back to Top


SAC B137-8 - Dark Nebula

SAC B137-8 (Aquila)


CCD Image Mosaic (5x4 frames, 20% size reduction)
Field of View : 1.7 degrees x 1.4 degrees
20s sec exposure,, 3x3 binning, C Filter
2009-07-31 00:53 h UT (#379511-36)
12" LX200R  (at f/5.7) + ST-10XME
[larger image, 50% size]

Back to Top


22/P Kopff - Comet

Comet 22/P Kopff
passing through star field in Aquarius


CCD Image (cropped)
3 x 30s sec exposure (average combine), 3x3 binning, C Filter
2009-07-31 01:07 h UT (#379539-41)
12" LX200R  (at f/5.7) + ST-10XME


Earlier Image of Comet 22/P Kopff (2009-07-28)


CCD Image (cropped)
2 x 30s sec exposure (average combine), 3x3 binning, C Filter
2009-07-28 00:34 h UT (#378219-20)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


Jupiter & Moons

Jupiter with Moons
Annotated CCD Image (cropped)
0.12s sec exposure, 3x3 binning, R Filter
2009-07-31 01:30 h UT (#379569)
12" LX200R  (at f/5.7) + ST-10XME

Jupiter

Jupiter in colour
Approximate Colour CCD Image (cropped)
Sharpened (Unsharp mask, 8)
Red : 0.12s sec exposure, 1x1 binning, R Filter
Green : 0.12s sec exposure, 1x1 binning, V Filter
Blue : 0.2s sec exposure, 1x1 binning, B Filter
2009-07-31 01:35 h UT (#379584-88)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


Astrometric and Photometric Monitoring
