CCD Images - Session 382 (2009-08-07)

Previous Imaging Session
Images
(S381)
  Home
Images
Sessions
  Home
Home
Page
  Next Imaging Session
Images
 (S383)

Objects Session Notes
Bullet C/2006 W3 (Christensen) - Comet
Bullet Jupiter & moons
Bullet Moon
Bullet Photometric Monitoring - Variables
- U And, W And, AM CVn,  AM Her, SS Her, U Her
- DY per, GK Per, U Sge, V Sge, ER UMa, SU UMa
Bullet Photometric Monitoring - Nearby Stars
- Barnards Star, Ross 248 (HH And), Groombridge 34

- Night time session (2.8 hrs). Initially clear with patchy cloud in Southern Sky. Session cut short by deteriorating sky conditions due to haar/mist and cloud. Very good seeing.
- Operated in observatory under semi-automated control
- Ambient Temperature  Initially 14 deg C falling to 10 deg C by end of session
- CCD operation -20 degC (at 78% average cooling).
- secondary objective of the session was to acquire images of key selected stars for ongoing photometric and astrometric analysis.
- secondary objective was to test recent software updates including revised focusing logic, and Zenith FWHM extrapolation.
- Notes from 2009-08-07

C/2006 W3 (Christensen) - Comet

C/2006 W3 (Christensen)
passing through star field in Vulpecula


CCD Image (50% size reduction)
3 x 30s sec exposure (average combine), 3x3 binning, C Filter
2009-08-07 22:27 h UT (#382003-05)
12" LX200R  (at f/5.7) + ST-10XME



C/2006 W3 (Christensen) - detail


CCD Image (logs scale, 100% size, cropped, )
Image details as above



Earlier Image of C/2006 W3 (Christensen) - 2009-06-08
passing through star field in Lacerta


CCD Image (cropped)
6 x 10s sec exposure (average combine), 3x3 binning, C Filter
2009-06-08 00:14 h UT (#372038-44)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


Jupiter & Moons

Jupiter with Moons
Annotated CCD Image (cropped)
0.12s sec exposure, 3x3 binning, R Filter
2009-08-07 23:18 h UT (#382074)
12" LX200R  (at f/5.7) + ST-10XME

Jupiter
CCD Image (cropped)
0.12s sec exposure, 1x1 binning, B Filter
2009-08-07 23:29 h UT (#381108)
Unsharp Masked
12" LX200R  (at f/5.7) + ST-10XME

CCD Image (cropped)
0.12s sec exposure, 1x1 binning, B Filter
2009-08-07 23:30 h UT (#381111)
Unsharp Masked
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


Moon

Moon (phase 96.5%)
CCD Image (25% size reduction)
1s sec exposure, 1x1 binning, U Filter
2009-08-07 23:45 h UT (#382136-4)
12" LX200R  (at f/5.7) + ST-10XME
[Larger Image, 50%]

Mare Imbrium (Day 16)
CCD Image (cropped from Mosaic above., 50% size reduction)
1s sec exposure, 1x1 binning, U Filter
2009-08-07 23:45 h UT (#382136-4)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


Astrometric and Photometric Monitoring
