CCD Images - Session 411 (2010-01-18)

Previous Imaging Session
Images
(S410)
  Home
Images
Sessions
  Home
Home
Page
  Next Imaging Session
Images
 (S412)

Objects Session Notes
Bullet IC 65 - Spiral Galaxy & Supernovae 2009mf
Bullet Mars
Bullet MACSJ0717 - Massive Galaxy Cluster
Bullet M43 - Nebula
Bullet Photometric Monitoring - Variables
- U And, W And, Z And, HR Aur, KR Aur, CN Ori, FO Ori, FU Ori, NV Ori, PY Per, GK Per, RR Tau

RX And attempt (failed due to dimmed state/short exposure)
TT Ari attempt (aborted)
Bullet Astrometric Monitoring - Nearby Stars
- Ross 248 (HH And), Groombridge 34, Luyten's Star, Teegardens Star

- Session  in two parts, using old 8" LX200 Classic scope, whilst main 12" LX200R scope has gone back to dealer for electrical repairs.

2010-01-17  Focusing, Focus Filter Offsets and Flat Frames

2010-01-18  Polar Alignment, Focus Temperature Coefficient
                   Imaging

2010-01-18
- Evening session (4.7 hrs), cold & frosty, dew on front lens by end of session despite dew shield and dew heater
- Session operated in observatory for first hour and then under semi-automated control, with remote monitoring from indoors computer. Problems encountered in last hour with wireless link to observatory laptop failing
- Ambient Temperature:  Initially 0 deg C, falling steadily to -3 deg C  (minimum)
- CCD operation -30 degC (at 66% average cooling).
- main objectives of the session was to make a successful return to imaging using back up 8" LX200 scope, with primary aim of acquiring images of selected project stars for ongoing photometric and astrometric analysis
- Notes from 2010-01-18

IC 65 - Spiral Galaxy & Supernovae 2009mf

IC 65 with SN 2009mf (Andromeda)
SN 2009mf (Type II) was discovered 2009/12/06.750 by Ron Arbour
Magnitude at discovery +16.1 (C)
(Rochester Supernova site | Discovery Image )

Image below (2010-01-18.97) was taken 43 days after discovery.
SN is still just visible

CCD Image (Linear Scale, cropped)
3 x 90s exposure (average combine), 3x3 binning, C Filter
2010-01-18 23:14hUT (#411398-400)
8" LX200 Classic (at f/10) + ST-10XME


IC 65 - earlier image (2009-12-11)
SN 2009mf marked by white cross hair (5.1 days after discovery)

CCD Image (Linear Scale, 200% size, ropped)
Image details as above

Back to Top


Mars

Mars

CCD Image Composite
0.3s, B Filter  / 0.2s,  V Filter  / 2s, Ha Filter
1x1 binning
2010-01-19 00:05 h UT  (#411458-69)
12" LX200R  (at f/5.7) + ST-10XME



CCD Image (with x2.5 enlarged insert)
0.3s sec exposure (single frame), 1x1 binning, B Filter
2010-01-19 00:05h UT  (#411458)
8" LX200 Classic (at f/10) + ST-10XME



Mars  - Change in Apparent Diameter and Phase
between 2009-12-11 and 2010-01-19
Changes associated with approaching opposition with Earth


CCD Images - scaled to same angular scale
Left : 2010-01-19 00:05h UT  (#411458) - 8" LX200
Right : 2009-12-11 04:18 h UT  (#403417) - 12" LX200



Earlier Image of Mars (2009-12-11)

CCD Image (with x3 enlarged insert)
0.12s sec exposure (single frame), 1x1 binning, B Filter
2009-12-11 04:18 h UT  (#403417)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


MACSJ0717 - Massive Galaxy Cluster

MACSJ0717 (Gemimi)
MACSJ0717.5+3745 (MACSJ0717 for short) is a 5.4 billion light years from Earth
and is one of the most complex galaxy clusters ever seen
http://chandra.harvard.edu/photo/2009/macs

A well publicised composite Chandra X-ray & HST Optical Image of MACSJ0717
shows the location of hot gas produced by multiple collisions from four separate galaxy clusters

The Image below taken through 8" LX200 scope shows the
location of the massive galaxy cluster MACSJ0717 (marked by white square)

CCD Image (50% size)
7 x 120s exposure (average combine), 3x3 binning, C Filter
2010-01-19 00:16 hUT (#411472-78)
8" LX200 Classic (at f/10) + ST-10XME


MACSJ0717 -  larger view
Whilst foreground stars (mag +14.4 to mag 17.0) and one very dim foreground galaxy (mag +17.0)
are visible in the square below, no detail of the MACSJ0717 super cluster itself can be seen
(compare this image with HST Optical Image)

(It hoped to attempt a longer exposure of MACSJ0717 in due course using main 12" LX200R scope)

Annotated CCD Image (normal scale, cropped)
Image details as above


Chandra + HST Composite Image
(click on image to see larger image on Chandra website)


Back to Top


M43 -  Nebula

M43 (Orion)
CCD Image, (35% size)
3 x 45s exposure (average combine), 3x3, Ha filter
2010-01-19 00:27h UT (#41219)
8" LX200 classic + ST-10XME

M43 - detail
CCD Image, (75% size, cropped)
Smoothed
mage details as above

Earlier Image of M43 (2003)
CCD Image, 30s exposure
2003-01-23 23:12h UT (#41219)
Image : 11.4 x 7.6 arc mins
8" LX200 classic + ST-7e

Back to Top
