Images - Session 504 (2012-03-05)

Objects Session Notes
Bullet Venus
Bullet Mars
Bullet Jupiter

Bullet Abell 1213 - Galaxy Cluster

Bullet NGC 3179 - Spiral Galaxy
Bullet NGC 3184 - Spiral Galaxy (Herschel I - 168)

Bullet Photometric Monitoring - Variables
- RX And, U And, FS Aur, KR Aur, CV CMi, RS CVn, RZ LMi, CN Ori, CZ Ori, FOR Ori, FU Ori, GK Per, RR Tau, SU Tau, ER UMa

Bullet Astrometric Monitoring - Nearby Stars
- Groombridge 34
- Evening session (3.5 hrs duration).
- Session parts operated under semi-automated control, with remote monitoring from indoors computer.
- Ambient Temperature: -2.5°C (minimum)
- CCD operation -30°C (at 65% average cooling).
- main objectives of the session were
1) to acquire image of Venus, Mars & Jupiter. In order to prevent oversaturation of the CCD the front of the telescope stopped down to approximately 3", using a sheet of cartridge paper with rough circular hole cut in it.
2) to acquire images of selected project stars for ongoing photometric and astrometric analysis.
-

Venus

Venus (Phase 62%)
CCD Image (cropped)
0.12 sec exposure (single frame), 1x1 binning, B Filter
2012-03-05 20:24 h UT (#504054)
12" LX200R  (at f/9.7) + ST-10XME
Stopped down to approx 3"

Back to Top


Mars

Mars
Colour CCD Image (cropped)
Unsharp Masked
Blue : 5 x 0.5 sec exposure (average combine), 1x1 binning, B Filter
Green : 5 x 0.2 sec exposure (average combine), 1x1 binning, V Filter
Red : 5 x 0.2 sec exposure (average combine), 1x1 binning, R Filter
2012-03-05 20:35 h UT (#504072-86)
12" LX200R  (at f/9.7) + ST-10XME
Stopped down to approx 3"
Frames registered using AIP4WIN

Mars
CCD Image (cropped)
Unsharp Masked (alternative params)
Image details as above

Back to Top


Jupiter

Jupiter
Colour CCD Image (cropped)
Unsharp Masked
Blue : 5 x 2 sec exposure (average combine), 1x1 binning, B Filter
Green : 5 x 1 sec exposure (average combine), 1x1 binning, V Filter
Red : 5 x 0.5 sec exposure (average combine), 1x1 binning, R Filter
2012-03-05 20:08 h UT (#504001-30)
12" LX200R  (at f/9.7) + ST-10XME
Stopped down to approx 3"
Frames registered using AIP4WIN

Jupiter
CCD Image (cropped)
Unsharp Masked
5 x 1 sec exposure (average combine), 1x1 binning, V Filter
2012-03-05 20:08 h UT (#504001-05)
12" LX200R  (at f/9.7) + ST-10XME
Stopped down to approx 3"

Back to Top


Abell 1213 - Galaxy Cluster

Central part of Abell 1213 (Ursa Major)
CCD Image (75% size)
7 x 90 sec exposure (average combine), 3x3 binning, C Filter
2012-03-05 23:19 h UT (#504262-68)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


NGC 3179 - Spiral Galaxy

NGC 3179 (Ursa Major)
CCD Image (cropped)
5 x 90 sec exposure (average combine), 3x3 binning, C Filter
2012-03-05 23:06 h UT (#504255-59)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


NGC 3184 - Spiral Galaxy (Herschel I-168)

NGC 3184 / Herschel I - 168 (Ursa Major)
CCD Image (75% scale, cropped)
4 x 90 sec exposure (average combine), 3x3 binning, C Filter
2012-03-05 22:56 h UT (#504248-52)
12" LX200R  (at f/9.7) + ST-10XME

NGC 3184 - Earlier Image  (2008-02-25)
 CCD Image
7 x 2 min exposure (average combine),
2x2 binning, C Filter
2008-02-25 01:20 h UT (#268286-92)
