Images - Session 555 (2013-11-18)

Objects Session Notes
Bullet GSC 3169:2228 - Star Field

Bullet M33 - Spiral Galaxy (Pinwheel Galaxy)

Bullet Variable Stars (photometric monitoring)
- None

Bullet Nearby Stars (astrometric monitoring)
- None
- Evening session (4.7 hrs duration).  Poor sky transparency
- Session operated under semi-automated control, with remote monitoring from indoors computer.
- Ambient Temperature:  -3.0°C minimum
- CCD operation -25°C (at 57% average cooling).
- main objectives of the session was to test out auto-guiding using AO-8 unit and to prepare an effective  return to imaging.
 - focusing
 - focusing offsets for filter
 - polar alignment check
- Notes 2013-11-18

GSC 3169:2228 - Star Field

GSC 3169:2228 and adjacent stars (Cygnus)
GSC 3169:2228, mag +10, is the brightest star in the image (lying towards bottom right)


CCD Image (75% size)
180 sec exposure (single frame), 3x3 binning, C filter,
Autoguided on the mag+ 5.9 star SAO 71303 using AO-8 Unit
operating with ~ 10 HZ corrections (0.05s autoguide exposures)
2013-11-01 06:14hUT (#552081-102)
12" LX200R  (at f/10.4) + ST-10XME

Back to Top


M33 - Spiral Galaxy (Pinwheel Galaxy) - 3.0 mly

M33 (Triangulum)
poor transparency, stars sharp due to good seeing and use of AO-8 unit

CCD Image (Linear Brightness Scale, 75% size)
10 x 180s exposure (average combine), 3x3 binning, C Filter
Autoguided on mag 8 guide star using AO-8
2013-11-18 20:25hUT (#555079-90)
12" LX200R  (at f/10.4) + ST-10XME

Earlier Image of M33 - showing named HII regions
much better sky transparency
CCD Image (Linear Brightness Scale, 75% size)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2010-10-07 00:51hUT (#430334-36)
12" LX200R  (at f/9.7) + ST-10XME
[Full Size Image]
