Images - Session 557 (2013-12-20)

 Previous Imaging Session
Images
(S556)		   Home
Images
Sessions		   Home
Home
Page		   Next Imaging Session
Images
(S558)
Objects Session Notes
Bullet Mars
Bullet Jupiter

Bullet C/2012 S1 (ISON) - Comet
Bullet C/2013 R1 Lovejoy - Comet

Bullet Variable Stars (photometric monitoring)
- R CrB,  CI Cyg

Bullet Nearby Stars (astrometric monitoring)
- None
- Morning session (1.5 hrs duration).  Clear. Some cloud and wind developing around dawn.
- Session operated under semi-automated control, with remote monitoring from indoors computer.
- Ambient Temperature:  -1.0°C minimum
- CCD operation -25°C (at 73% average cooling).
- main objectives of the combined session was to continue preparations towards an effective  return to imaging, concentrating on the following
- Polar Alignment Check & adjustment
- tracking rate and adjustment
- Notes 2013-12-20 >>

Mars

Mars


CCD Image(cropped)
5 x 0.3s exposure (average combine, aligned using Registax), 1x1 binning, Blue Filter
2013-12-20 07:01hUT (#557378-82)
12" LX200R  (at f/10.4) + ST-10XME

Back to Top

Jupiter

Jupiter & Moons


Annoated CCD Image (cropped)
0.2s exposure (single frame), 3x3 binning, Ha Filter
2013-12-20 06:48hUT (#557342)
12" LX200R  (at f/10.4) + ST-10XME



Jupiter


CCD Image (unsharp masked, cropped)
5 x 0.3s exposure (average combine, aligned using Registax), 1x1 binning, Blue Filter
2013-12-20 06:58hUT (#557374-77)
12" LX200R  (at f/10.4) + ST-10XME




CCD Image (unsharp masked, cropped)
8 x 1 exposure (average combine, aligned using Registax), 1x1 binning, Ha Filter
2013-12-20 06:55hUT (#557360-68)
12" LX200R  (at f/10.4) + ST-10XME



Jupiter - Earlier Image 2012-12-18


CCD Image (cropped)
0.5s exposure (single frame), 1x1 binning, V Filter
2012-12-18 22:17 hUT (#534178)
12" LX200R  (at f/9.7) + ST-10XME




Jupiter detail


Enhanced CCD Image (cropped)
Unsharp Masked
Image details as above

Back to Top

C/2012 S1 (ISON) - Comet

C/2012 S1 (ISON) - no more
Circle below shows the area where comet C/2012 S1 (ISON) should have been
if it hadn't broken up during its passage around the Sun
CCD Image (70% size)
90 sec exposure (single frame), 3x3 binning, C Filter
2013-12-20 06:22hUT (#557316)
12" LX200R  (at f/10.4) + ST-10XME


C/2012 S1 (ISON) - Earlier image (2013-11-01)
(moving through Leo)
Comet at 0.99 AU distance from sun
Stacked CCD Image (70% size)
28 x 10 sec exposure (average combine, aligned on comet), 3x3 binning, C Filter
2013-11-01 05:38 to 05:48hUT (#552020-49)
12" LX200R  (at f/9.7) + ST-10XME



C/2012 S1 (ISON) - Early Image 2013-02-25
(moving through starfield in Gemini)
Comet at 4.65 AU distance from sun
Annotated CCD Image (cropped)
5 x 90 sec exposure (average combine), 3x3 binning, C Filter
2013-02-25 19:53hUT (#539046-51)
12" LX200R  (at f/9.7) + ST-10XME



C/2012 S1 (ISON) - Early Image 2012-11-11
(moving through Gemini)
Comet at 5.75 AU distance from sun / i.e beyond the orbit of Jupiter
Annotated CCD Image (100% size, cropped)
5  x 180s exposure (average combine), 3x3 binning, C Filter
2012-11-11 04:22 hUT (#524411-15)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top

C/2013 R1 Lovejoy - Comet

C/2013 R1 Lovejoy
(passing through Hercules)
Sun Distance 0.81 AU

CCD Image (Square root scaling, 75% size)
3 x 30 sec exposure (average combine,), 3x3 binning, C filter,
2013-12-20 05:47hUT (#557262-64)
12" LX200R  (at f/10.4) + ST-10XME

C/2013 R1 Lovejoy - detail

CCD Image (linear scale, cropped)
46 x 10 sec exposure (aligned on comet, average combine), 3x3 binning, C filter
2013-12-20 06:00hUT (#557265-312)
12" LX200R  (at f/10.4) + ST-10XME


CCD Image (radial gradient, cropped)
Image details as above

  Comparison

CCD Image (Square root scaling, 50% size)
3 x 30 sec exposure (average combine,), 3x3 binning, C filter,
2013-12-20 05:47hUT (#557262-64)
12" LX200R  (at f/10.4) + ST-10XME


C/2013 R1 Lovejoy - Earlier Image (2013-11-01)
(passing through Cancer)
 Sun Distance 1.24 AU

Stacked CCD Image (50% size)
3 x 10 sec exposure (average combine,), 3x3 binning, C filter,
2013-11-01 06:23hUT (#552110-14)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top
