David's Astronomy Pages Images - Session 581 (2015-03-24)

Images (S580)

Images Sessions

Home Page

Images (S582)

Objects

Session Notes

Moon Jupiter - Planet Jupiter Moons     C/2014 Q2 (Lovejoy) - Comet     Tombaugh 5 - Open Cluster     Photometric Monitoring - Variables   - IW And, Z And, CZ Ori, FU Ori, RR Tau     Astrometric Monitoring - Nearby Stars   - Groombridge 34     Solar Eclipse 2015-03-20

- Evening session (2.3 hrs duration).   First session with new filters : BVRI,  Xo (Blue-Blocking Exoplanet), S (Star Analyser 200) and Nd (1.5% Neutral Density). - Session operated under semi-automated control, with remote monitoring from indoors computer.   - Ambient Temperature:  Temperature falling progressively to minimum of -2°C before rising to 0°C as cloud began to develop. - CCD operation -30°C (at 68% average cooling).  - Main objectives of the session was to monitor selected variable stars & nearby stars and to take gallery images of a range of deep sky objects.   -   - Focus Offsets for new filters determined during a short session three nights beforehand (2015-03-21). Flats for new and existing filters taken the following day (2015-03-25).

Moon

Moon (25.4% phase)

CCD Image Mosaic (20% size) 3x4 mosaic, 0.2 sec exposure, 2x2 binning, 1.5% Neutral Density Filter 2015-03-24 20:56hUT (#581036-47) 12" LX200R  (at f/10.4) + ST-10XME

Moon - detail

Part of CCD Image Mosaic (75% size, cropped) Image details as above

Back to Top

Jupiter - Planet

Jupiter

Processed CCD Image (stacked, unsharp masked, cropped) 12 x 0.2 sec exposure (combined), 1x1 binning, 1.5% Neutral Density Filter 2015-03-24 21:14hUT (#581052-67) 12" LX200R  (at f/10.4) + ST-10XME

Jupiter

Rotated CCD Image  (stacked, unsharp masked, rotated, cropped) Image details as above

Back to Top

Jupiter Moons

Jupiter Moons

Annotated CCD Image (100% size, cropped) 1 sec exposure, 3x3 binning, 1.5% Neutral Density Filter 2015-03-24 21:11hUT (#581048) 12" LX200R  (at f/10.4) + ST-10XME

Back to Top

C/2014 Q2 (Lovejoy) - Comet

C/2014 Q2 (Lovejoy) (Passing through starfield in Perseus) Sun distance 1.33 AU

CCD Image (50% size, cropped) 9 x 15 sec exposure (average combine), 3x3 binning, C Filter 2015-03-24 21:33hUT (#581123-31) 12" LX200R  (at f/10.4) + ST-10XME

Back to Top

Tombaugh 5  -  Open Cluster

Tombaugh 5 (Camelopardalis)

CCD Image (75% size) 5 x 60 sec exposure (average combine), 3x3 binning, C Filter  2015-03-24 22:33 h UT  (#581212-16) 12" LX200R  (at f/10.4) + ST-10XME

Earlier Tombaugh 5 Attempt (2014-12-02)

CCD Image (50% size) 5 x 45 sec exposure (average combine), 3x3 binning, C Filter  2014-11-30 22:59 h UT  (#572283-87) 12" LX200R  (at f/10.4) + ST-10XME

Back to Top

Variable Stars

Back to Top

Solar Eclipse - 2015-03-20

Solar Eclipse Observing from just south of Stonehaven, NE Scotland Photos with handheld digital camera 2015-03-20 Conditions largely overcast but with occasional thinning / gap in cloud

Solar Eclipse (near maximum eclipse) c. 94% coverage by moon disk

Solar Eclipse - More photos

Solar Eclipse - detail
