Objects Session Notes
Moon
C/2017 T1 (Heinze) - Comet (attempt) M45 - Open Cluster M108 - Spiral Galaxy NGC 2239 - Open Cluster NGC 2244 - Open Cluster NGC 2403 - Spiral Galaxy (Caldwell 7) Photometric Monitoring - Variables - None Astrometric Monitoring - Nearby Stars - None SharpCap Files (S609)
- Evening Session (2 hrs duration).
Clear skies, low wind.- Session operated under semi-automated control, with remote monitoring from indoors computer. - Main aims of the session were to acquire images of selected deep sky objects and to test updated routines for initiating PHD2 Guiding from my CCDApp2 Observatory Control Software. The session also aimed to continue testing of dual camera operations using both PHD2 and SharpCap 3.0.
- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging- Ambient Temperature: 0°C (minimum) - Notes from 2018-01-03 >>
| Moon |
||
 |
CMOS Image (10% size) Image details as below |
|
 |
CMOS Image (25% size, cropped) 60 x 8ms exposure, 1x1 binning (P20 stacking of 302 raw frames) Gain 0, Raw16, ROI 3096x2080 2018-01-03 22:07h UT (#22_07_34Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 Larger Image (50% size) |
|
 |
CMOS Image (78% size) 68 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:14h UT (#22_14_05Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (78% size) 62 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:15h UT (#22_15_28Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (78% size) 103 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:16h UT (#22_16_45Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (78% size, Unsharp Masked) 103 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:16h UT (#22_16_45Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (78% size) 102 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:17h UT (#22_17_43Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (78% size) 103 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:18h UT (#22_18_22Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (78% size) 103 x 7ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:20h UT (#22_20_08Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (100% size, cropped) 103 x 7ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:29h UT (#22_29_50Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (78% size) 105 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:32h UT (#22_32_30Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (100% size, cropped) Image details as above |
|
 |
CMOS Image (78% size) 105 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:33h UT (#22_33_35Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (100% size, cropped) 103 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:34h UT (#22_34_15Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (100% size, cropped) 103 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:35h UT (#22_35_43Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (78% size) 105 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:36h UT (#22_36_54Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (78% size) 105 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:38h UT (#22_38_33Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (78% size) 105 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:39h UT (#22_39_07Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 (Larger Size, 100% size) |
|
 |
CMOS Image (78% size) 103 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:40h UT (#22_39_53Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (100% size, cropped) 103 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:41h UT (#22_41_02Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (150% size, cropped) 103 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 640x480 2018-01-03 22:41h UT (#22_41_41Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
 |
CMOS Image (25% size, cropped) 90 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 3096x2080 2018-01-03 22:54h UT (#22_54_13Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 Larger Image (75% size) |
|
 |
CMOS Colour Image (25% size, cropped) Image Details as above Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 Displayed using DeepSkyStacker |
|
 |
CMOS Image (32% size, cropped, unsharp masked (um6) ) 100 x 8ms exposure, 1x1 binning Gain 0, Raw16, ROI 3096x2080 2018-01-03 22:55h UT (#22_55_08Z / AS P20 Conv) ASI178MC + TS 80mm f/6 APO Mounted on 12" LX200R Frames Acquired using SharpCap (SER file) Processed using Autostakkert 2 |
|
Back to Top
Attempted observation of comet C/2017 T1 (Heinze), but the orbital elements that I was using were out of date, which meant that the imaged star field (below) was 1 deg 35 min away from the correct position of the comet
| C/2017 T1 (Heinze) - attempt (Camelopardalis, Sun distance 1.17 AU) (Comet lies 1 deg 35 min away due to the use of invalid/out-of-date orbital elements) This was considerably more than the 3 arc minute error just 3 weeks earlier) |
 |
| CCD Image (50% size) 7 x 45s exposure (average combine), 3x3 binning, C Filter 2018-01-03 21:09h UT (#609002-08) 12" LX200R (at f/10.4) + ST-10XME (Autoguided using TS 80mm APO + ZWO ASI178MC) |
| C/2017 T1 (Heinze) - earlier image (2017-12-04) |
| (passing
through Hydra) Sun distance 1.49 AU (Comet was some 3 arc minutes away from stated oribital elements) |
 |
| CCD Image (50% size, Linear Scaling) 6 x 45s exposure (average combine), 3x3 binning, C Filter 2017-12-14 00:35h UT (#607129-35) 12" LX200R (at f/10.4) + ST-10XME (Autoguided using TS 80mm APO + ZWO ASI178MC) |
Back to Top
| M45 (Taurus) |
 |
| CMOS Colour Image (16% size) 110 secs (11 x 10s) Binning 1x1, Gain 400, Raw16, ROI 3096x2080 (Full) Non-Guided 2018-01-03 20:50h UT (#20_50_11Z) TS 80mm f/6 APO + ASI178MC (OSC) Mounted on 12" LX200R Frames acquired using SharpCap (Live Stack) Frames displayed using DeepSkyStacker 4.1.1 |
Back to Top
| M108 (Ursa Major) |
 |
| CCD Image (50% size) 11 x 30s exposure (average combine), 3x3 binning, C Filter 2018-01-03 23:37h UT (#609031-50) 12" LX200R (at f/10.4) + ST-10XME (Autoguided using TS 80mm APO + ZWO ASI178MC) |
| M108 - Detail |
 |
| CCD Image (100% size, cropped) Image details as above |
 |
| Negative CCD Image (100% size, cropped) Image details as above |
| M108 - ASI178MC image |
 |
| CMOS Colour Image (16% size) 16.6 mins (1000 x 10s) Binning 1x1, Gain 400, Raw16, ROI 3096x2080 (Full) Non-Guided 2018-01-03 23:40h UT (#23_40_58Z) TS 80mm f/6 APO + ASI178MC (OSC) Mounted on 12" LX200R Frames acquired using SharpCap (Live Stack) Frames displayed using DeepSkyStacker 4.1.1 |
| M108 - detail |
 |
| CMOS Colour Image (cropped) Image details as above |
Back to Top
| NGC 2239 (Monoceros) Open Cluster at centre of Rosette Nebula (NGC 2237) |
 |
| CMOS Colour Image (16% size) 13.5 mins (81 x 10s) Binning 1x1, Gain 200, Raw16, ROI 3096x2080 (Full) Non-Guided 2018-01-03 23:03h UT (#23_03_39Z) TS 80mm f/6 APO + ASI178MC (OSC) Mounted on 12" LX200R Frames acquired using SharpCap (Live Stack) Frames displayed using DeepSkyStacker 4.1.1 |
| NGC 2239 - detail |
 |
| CMOS Colour Image (24% size, cropped) Image details as above |
| NGC 2239 - earlier image (2006) |
 |
| CCD Image Mosaic (59% size, cropped) 180s exposure, 2x2 binning, C Filter 2006-12-23 22:02 hUT (#169258-345) 8" LX200 + ST-7E |
Back to Top
| NGC 2244 (Monoceros) (Part of Rosette Nebula) |
 |
| CCD Image (50% size) 3 x 30s exposure (average combine), 3x3 binning, C Filter 2018-01-03 23:17h UT (#609023-29) 12" LX200R (at f/10.4) + ST-10XME (Autoguided using TS 80mm APO + ZWO ASI178MC) |
Back to Top
| NGC 2403 (Camelopardalis) |
 |
| CCD Image (50% size) 3 x 30s exposure (average combine), 3x3 binning, C Filter 2018-01-04 00:09h UT (#609053-55) 12" LX200R (at f/10.4) + ST-10XME (Autoguided using TS 80mm APO + ZWO ASI178MC) |
| NGC 2403 - Detail |
 |
| CCD Image (75% size, cropped) Image details as above |
 |
| CCD Image (75% size, cropped) 4 x 180s exposure (average combine), 3x3 binning, C Filter 2018-01-04 00:24h UT (#609058-62) 12" LX200R (at f/10.4) + ST-10XME (Autoguided using TS 80mm APO + ZWO ASI178MC) |
| NGC 2403 - ASI178MC image |
 |
| CMOS Colour Image (16% size) 90 secs (9 x 10s) Binning 1x1, Gain 400, Raw16, ROI 3096x2080 (Full) Non-Guided 2018-01-04 01:29h UT (#00_01_29ZZ) TS 80mm f/6 APO + ASI178MC (OSC) Mounted on 12" LX200R Frames acquired using SharpCap (Live Stack) Frames aligned, stacked & displayed using DeepSkyStacker 3.3.2 Larger Image (32% size) |
| NGC 2403 - detail |
 |
| CMOS Colour Image (cropped) Image details as above |
Back to Top
SharpCap Session - 2018-01-03 S00609
| Object | Folder | Capture Area | Colour Space | Bin | Exp | Gain | Gamma | Temp. (C) | Subtract Dark | Output Format | Num Frames | Stacked Frames | Total Exp | Num .fits | Raw .fits | Num .png | Proc .png | Num .ser |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| M45 | 20_15_15Z | 3096x2080 | RAW16 | 3 | 10s | 400 | 50 | 6.2 | FITS | 1 | 1 | 0 | 0 | 0 | 0 | |||
| " | 20_50_11Z | 3096x2080 | RAW16 | 3 | 10s | 400 | 50 | 6.0 | FITS | 10 | 8 | 1.3m | 2 | 10 | 0 | 1 | 0 | |
| Pointing | 20_15_15Z | 3096x2080 | RAW16 | 3 | 10s | 400 | 50 | 6.2 | FITS | 1 | 1 | 0 | 0 | 0 | 0 | |||
| Moon | 22_07_34Z | 3096x2080 | RAW16 | 1 | 8ms | 0 | 50 | 11.2 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_14_05Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 13.2 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_15_28Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 13.5 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_16_45Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 13.6 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_17_43Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 13.7 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_18_22Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 13.8 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_20_08Z | 640x480 | RAW16 | 1 | 7ms | 0 | 50 | 14.1 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_29_50Z | 640x480 | RAW16 | 1 | 7ms | 0 | 50 | 14.7 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_32_30Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.3 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_33_35Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.5 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_34_15Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.5 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_35_43Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.5 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_36_54Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.6 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_38_33Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.6 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_39_07Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.6 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_39_53Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.7 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_41_02Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.8 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_41_41Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.8 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_41_47Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.8 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_41_53Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.8 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_41_58Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.8 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_42_05Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.8 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_42_11Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.8 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_42_16Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.8 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_42_18Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.8 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_42_23Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.8 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_42_29Z | 640x480 | RAW16 | 1 | 8ms | 0 | 50 | 14.8 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_54_13Z | 3096x2080 | RAW16 | 1 | 8ms | 0 | 50 | 13.0 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| " | 22_55_08Z | 3096x2080 | RAW16 | 1 | 8ms | 0 | 50 | 12.7 | SER | 0 | 0 | 0 | 0 | 1 | ||||
| NGC 2237 | 23_03_39Z | 3096x2080 | RAW16 | 1 | 10s | 200 | 50 | 5.7 | FITS | 96 | 81 | 13.5m | 5 | 96 | 0 | 2 | 0 | |
| " | 23_24_40Z | 3096x2080 | 16 | 1 | 10s | 5.7 | FITS | 1 | 0 | 1 | 0 | 0 | 0 | |||||
| M108 | 23_29_45Z | 3096x2080 | 16 | 1 | 10s | 5.8 | FITS | 5 | 0 | 5 | 0 | 0 | 0 | |||||
| " | 23_36_44Z | 3096x2080 | 16 | 1 | 10s | 6.1 | FITS | 12 | 0 | 12 | 0 | 0 | 0 | |||||
| " | 23_40_58Z | 3096x2080 | RAW16 | 1 | 10s | 400 | 50 | 5.5 | FITS | 109 | 100 | 16.7m | 1 | 109 | 0 | 1 | 0 | |
| NGC 2403 | 00_01_29Z | 3096x2080 | 16 | 1 | 10s | 5.5 | FITS | 25 | 0 | 25 | 0 | 0 | 0 |
