Images - Session 644 (2018-12-24)

Objects Session Notes
Bullet 37P/Forbes - Comet (attempt)
Bullet 38P/Stephan-Oterma - Comet
Bullet 46P/Wirtanen - Comet

Bullet M77 - Spiral Galaxy with SN 2018ivc

Bullet NGC 2681 - Spiral Galaxy
Bullet NGC 6946 - Spiral Galaxy (Caldwell 12 / Herschel IV-76)

Bullet Photometric Monitoring - Variables
   - RX And, Z And, S, Cyg, SS Cyg, RZ LMi, BL Lac,
FO Ori, NV Ori, GK Per, RR Tau, SU Tau, ER UMa

- AM Her, FU Ori attempts (failed due to cloud)

Bullet Astrometric Monitoring - Nearby Stars
 - HH And, 61 Cyg, Groombridge 34, Teegardens Star

- Schloz's Star attempt failed (due to incorrect location)



- Evening Session (7.8 hours duration) .

Poor-Moderate sky transparency
- Main aim of the session was acquire images of a selection of nearby stars, variable stars and deep sky objects , and perform software testing.'

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  -3°C (minimum)
- CCD Temperature:  -25°C (77% av. power)
- Notes from 2018-12-24 >>


37P/Forbes - Comet (attempt)

37P/Forbes (passing through star-field in Pisces)
Sun Distance 2.63 AU
Predicted position is marked by white cross-hairs
Comet is not visible. This is due to the dimming of comet as it moves further
away from the sun (catalogue mag +17.5)
Annotated CCD Image (50% size)
5 x 60 sec exposure (average combine), 3x3 binning, C Filter
2018-12-26 19:13 UT (#644089-93)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

37P/Forbes - Earlier Image (2018-09-08)
 (passing through star-field in Pisces)
Sun Distance 2.25 AU
Predicted position is marked by white circle
Comet is not visible. This may be partly due to a) thin cloud and
b) dimming of comet as it moves further away from the sun
Annotated CCD Image (50% size)
3 x 60 sec exposure (average combine), 3x3 binning, C Filter
2018-10-20 19:21 UT (#632017-19)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

37P/Forbes - Earlier Image (2018-09-08)
(passing through star-field in Pisces)
Sun Distance 2.02 AU
Comet is marked by white cross hairs
Bright star is SAO 128092 (magnitude +9.5)
Annotated CCD Image (50% size)
5 x 60 sec exposure (average combine), 3x3 binning, C Filter
2018-09-08 22:33 UT (#627002-06)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

37P/Forbes - Earlier Image (2018-08-31)
Sun Distance 1.98 AU
Annotated CCD Image (100% size, cropped)
5 x 60 sec exposure (average combine), 3x3 binning, C Filter
2018-08-31 23:09 UT (#623111-15)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Back to Top


38P/Stephan-Oterma - Comet

38P/Stephan-Oterma
(passing through Cancer)
Sun distance 1.68 AU.
Annotated CCD Image (50% size)
5 x 30s exposure ( average combine), 3x3 binning, C Filter
2018-12-24 23:23 UT (#644292-97)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided on a guide star using TS 80mm APO + ZWO ASI178MC)

38P/Stephan-Oterma - Earlier Image (2018-12-04)
(passing through Cancer)
Sun distance 1.62 AU.
Annotated CCD Image (50% size)
5 x 30s exposure ( average combine), 3x3 binning, C Filter
2018-12-04 00:30 UT (#639041-47)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided on a guide star using TS 80mm APO + ZWO ASI178MC)

38P/Stephan-Oterma  - Earlier Image (2018-11-08)
(passing through Gemini)
Sun distance 1.59 AU.
CCD Image (50% size)
26 x 30s exposure ( aligned on comet, average combine), 3x3 binning, C Filter
2018-11-08 03:32 UT (#636029-59)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided on a guide star using TS 80mm APO + ZWO ASI178MC)

38P/Stephan-Oterma  - Earlier Image (2018-10-21)
(passing through Gemini)
Sun distance 1.61 AU.
CCD Image (50% size)
7 x 30s exposure (average combine), 3x3 binning, C Filter
2018-10-21 20:03 UT (#633206-12)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

38P/Stephan-Oterma - Earlier detail  (2018-10-21)
Annotated CCD Image (100% size, Cropped)
Image details as above


Back to Top


46P/Wirtanen - Comet

46P/Wirtanen
(passing through Auriga)
Sun Distance 1.07 AU
Earth Distance 0.09 AU (13.8 million km)
  46P/Wirtanen - Detail
Image   Image
CCD Image (50% size, linear scale)
15s exposure (single frame), 3x3 binning, C Filter
2018-12-24 18:33 UT (#644036)
12" LX200R  (at f/10.4) + ST-10XME
  CCD Image (70% size, log scale)
31 x 15s exposure (average combine), 3x3 binning, C Filter
2018-12-24 18:33 to 18:47 UT (#644036-7)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided on comet using TS 80mm APO + ZWO ASI178MC)

    False Color CCD Image (50% size, logscale)
Inverse Spectrum
Image details as above

    More Images of 46P/Wirtanen

46P/Wirtanen  - Earlier Image (2018-12-16)
(passing through Taurus)
Near to point of closest distance from earth
Sun Distance 1.06 AU
Earth Distance 0.08 AU (11.6 million km)
  46P/Wirtanen  - Earlier Detail (2018-12-16)
Image   Image
CCD Image (50% size, linear scale)
15s exposure (single frame), 3x3 binning, C Filter
2018-12-16 21:03 UT (#641184)
12" LX200R  (at f/10.4) + ST-10XME
  CCD Image (50% size, log scale)
31 x 15s exposure (average combine), 3x3 binning, C Filter
2018-12-16 21:03 to 21:16 UT (#641184-222)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided on comet using TS 80mm APO
+ ZWO ASI178MC & PHD2)

    False Color CCD Image (50% size, logscale)
Inverse Spectrum
Image details as above

Back to Top


M77 - Spiral Galaxy with SN 2018ivc

M77 with SN 2018ivc   (Perseus)
SN 2018ivc discovered 2018/11/24.074 by DLT40
 ( (Rochester Supernova site |  K. Itagaki image )

M77 with SN 2018ivc - 2018-12-24 (T+30.7d)
Image below (2018-12-24.791) taken 30.7 days after discovery of SN 2018ivc
No positive indication of supernova (image either has nsufficient resolution
to resolve SN 208ivc or the supernova has faded too far to be seen
Annotated CCD Image (100% size, cropped, logscale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2018-12-24 18:59 UT (#644080-84)
12" LX200R  (at f/10.4) + ST-10XME

M77 w/ SN 2018ivc   - Earlier Image, 2018-12-04 (T+10.8d)
Image below (2018-12-04.842) was taken 10.8 days after discovery of SN 2018ivc
SN is just visible in image below (shown by white cross-hairs)
Annotated CCD Image (100% size, cropped, logscale)
180s exposure (single frame), 3x3 binning, C Filter
2018-12-04 20:12 UT ( 640059)
12" LX200R  (at f/10.4) + ST-10XME

Images of SN 2018ivc (M77) on Supernovae 2018 Page >>

Back to Top


NGC 2681 - Spiral Galaxy

NGC 2681  (Perseus)
Galaxy with possible supernova AT2018irv near core
(not resolveable in image)

AT2018irv discovered discovered 2018/11/09.514 by by Zwicky Transient Facility (ZTF)
 (Rochester Supernova site |  K. Itagaki image )
SN show in image below by white cross-hairs
Type II Supernova
Annotated CCD Image (100% size, cropped, logscale)
5 x 120s exposure (average combine), 3x3 binning, C Filter
2018-12-24 18:59 UT (#644248-52)
12" LX200R  (at f/10.4) + ST-10XME

Back to Top


NGC 6946 - Spiral Galaxy (Caldwell 12 / Herschel IV-76)

NGC 6946 / Caldwell 12 / Herschel IV-76 (Cepheus)
taken with Ha filter
CCD Image (75% size, cropped)
8 x 180s exposure (average combine), 3x3 binning, Ha Filter
2018-12-24 17:29h UT (#644013-20)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 6946 - Earlier Image taken in 2010
taken with C Filter
CCD Image (80% size, cropped)
8 x 90s (average combine), 3x3 binning, C Filter
2010-02-20 19:44h UT (#414129-36)
12" LX200R  (at f/9.7) + ST-10XME
