David's Astronomy Pages
Images - Session 653 (2019-01-30)

Objects Session Notes
Bullet UGC 118 & PGC 212483 with Supernova AT2019B
Bullet 46P/Wirtanen - Comet
Bullet NGC 3254 - Spiral Galaxy with Type Ia Supernova 2019np
Bullet NGC 2628 - Spiral Galaxy (UGC 4519)
Bullet C/2015 O1 (PANSTARRS) - Comet
Bullet PGC 32384 & PGC 213739 - Spiral Galaxies
Bullet NGC 6181 - Spiral Galaxy

Bullet Photometric Monitoring - Variables
  - RX And, AM CVn, SY Cnc, R CrB, CI Cyg, S Syg, SS Cyg, U Gem, SS Her, U Her, RZ LMi, BL Lac, U Mon,  CN Ori, FO Ori, FU Ori, NV Ori, DY Per, GK Per, RR Tau, SU Tau, ER UMa



Bullet Astrometric Monitoring - Nearby Stars
 - HH And, DX Cnc, 61 Cyg, LAMOST-HVS1, EV Lac,  CN Leo, Teegardens Star

-DX Cnc attempt failed (due to a dome slew issue)


- All Night Session (10.6 hours duration) .

Session operated in fully automated mode, but monitored over remote connection for 1s half of session.

Sky quality good, good seeing.

- Main aim of the session was acquire images of a selection of nearby stars, variable stars and deep sky objects taking advantage of moderate weather conditions. Secondary aim was to test recent  changes and additions to AstroMain program

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  -6.5°C (minimum)
- CCD Temperature:  -30°C (74% av. power)
- Notes from 2019-01-30 >>



UGC 118 & PGC 212483 with Supernova AT2019B - Spiral Galaxies

UGC 118 / NGC 42  (Pegasus)
AT2019B Estimated magnitude +17.2
Annotated Negative CCD Image (50% size)
2 x 180s exposure (average combine), 3x3 binning, C Filter
2019-01-30 18:58 UT (#653003-04)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 118 / NGC 42  (Pegasus) - Earlier Image (2019-01-30)
NGC 42 (catalog mag +14.3 )
Annotated CCD Image (50% size)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-01-29 20:23 UT (#652123-27)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

AT2019B - Close Up - Earlier Image (2019-01-30)
AT2019B  TNS discovered 2019/01/01.250 by All Sky Automated Survey for SuperNovae (ASAS-SN)
 (Rochester Supernova site |  Discovery Image | SN Type II,  z=0.021 )
SN is shown in the image below by white cross-hairs.
Image (2019-01-29.849) was taken 28.6 days after discovery
Annotated CCD Image (150% size, cropped)
Image details as above

AT2019B - Detail
The Rochester site implies that SN might be associated with UGC 118, but another possibility
 is that it is associated with the closer lying PGC 212483
Annotated Negative CCD Image (100% size, cropped)
Image details as above

AT2019B - Earlier Image (2019-01-02)
SN is pointed out in the image below by white cross-hairs.
Image (2019-01-02.972) was taken 1.7 days after discovery
Annotated Negative CCD Image (100% size, cropped)
4 x 180 sec exposure (average combine), 3x3 binning, C Filter
2019-01-02 23:20 UT (#647239-43)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


46P/Wirtanen - Comet

46P/Wirtanen (passing through Ursa Major)
Sun Distance 1.24 AU
Earth Distance 0.30 AU (45.6 million km)
CCD Image (50% size, linear scale)
5 x 15s exposure (average combine), 3x3 binning, C Filter
2019-01-30 19:39 UT (#653051-55)
12" LX200R (at f/10.4) + ST-10XME

46P/Wirtanen - Earlier Image (2019-01-28)
(passing through Ursa Major)
Sun Distance 1.23 AU
Earth Distance 0.29 AU (43.6 million km)
CCD Image (50% size, linear scale)
7 x 15s exposure (average combine), 3x3 binning, C Filter
2019-01-28 23:20 UT (#651148-54)
12" LX200R (at f/10.4) + ST-10XME

46P/Wirtanen - Earlier Image  (2019-01-23, pm)
(passing through Ursa Major)
Sun Distance 1.20 AU
Earth Distance 0.26 AU (38.4 million km)
CCD Image (50% size, linear scale)
8 x 15s exposure (average combine), 3x3 binning, C Filter
2019-01-23 22:25 UT (#650166-73)
12" LX200R (at f/10.4) + ST-10XME

46P/Wirtanen - Earlier Image (2019-01-23, am)
(passing through Ursa Major)
Sun Distance 1.19 AU
Earth Distance 0.25 AU (37.5 million km)
CCD Image (50% size, linear scale)
40 x 15s exposure (average combine), 3x3 binning, C Filter
2019-01-23 02:38 UT (#649474-513)
12" LX200R (at f/10.4) + ST-10XME

46P/Wirtanen - Earlier Image (2019-01-20)
 (passing through Ursa Major)
Sun Distance 1.18 AU
Earth Distance 0.24 AU (35.4 million km)
CCD Image (50% size, linear scale)
19 x 15s exposure (average combine), 3x3 binning, C Filter
2019-01-20 19:39 UT (#648111-29)
12" LX200R (at f/10.4) + ST-10XME

46P/Wirtanen - Earlier Image (2019-01-02)
(passing through Lynx)
Sun Distance 1.09 AU
Earth Distance 0.13 AU (19.8 million km)
CCD Image (50% size, linear scale)
15s exposure (single frame), 3x3 binning, C Filter
2019-01-02 23:58 UT (#647261)
12" LX200R (at f/10.4) + ST-10XME

CCD Image (50% size, logscale)
Image details as above

46P/Wirtanen - detail
CCD Image (50% size, logscale)
18 x 15s exposure (aligned on comet, average combine), 3x3 binning, C Filter
2019-01-03 00:01 UT (#647261-81)
12" LX200R (at f/10.4) + ST-10XME)

   46P/Wirtanen  - RotationalGradient Processing
15 deg rotational shift
(Processing performed in IRIS 5.59)
Processed CCD Image (50% size,rotational gradient)
Image details as above

46P/Wirtanen  - Earlier Image (2018-12-24)
(passing through Auriga)
Sun Distance 1.07 AU
Earth Distance 0.09 AU (13.8 million km)
CCD Image (50% size, linear scale)
15s exposure (single frame), 3x3 binning, C Filter
2018-12-24 18:33 UT (#644036)
12" LX200R  (at f/10.4) + ST-10XME

CCD Image (70% size, log scale)
31 x 15s exposure (average combine), 3x3 binning, C Filter
2018-12-24 18:33 to 18:47 UT (#644036-7)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided on comet using TS 80mm APO + ZWO ASI178MC)

False Color CCD Image (50% size, logscale)
Inverse Spectrum
Image details as above

46P/Wirtanen  - Earlier Images (2018-12-16)
(passing through Taurus)
Near to point of closest distance from earth
Sun Distance 1.06 AU
Earth Distance 0.08 AU (11.6 million km)
CCD Image (50% size, linear scale)
15s exposure (single frame), 3x3 binning, C Filter
2018-12-16 21:03 UT (#641184)
12" LX200R  (at f/10.4) + ST-10XME

CCD Image (50% size, log scale)
31 x 15s exposure (average combine), 3x3 binning, C Filter
2018-12-16 21:03 to 21:16 UT (#641184-222)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided on comet using TS 80mm APO + ZWO ASI178MC)

False Color CCD Image (50% size, logscale)
Inverse Spectrum
Image details as above


Back to Top


NGC 3254 - Spiral Galaxy with Type Ia Supernova 2019np

NGC 3254 with SN 2019np (Leo Minor)
SN 2019np TNS discovered 2019/01/09.665 by Koichi Itagaki
 (Rochester Supernova site |  Discovery Image | SN Type Ia, +16.9 (C) at discovery)

NGC 3254 with SN 2019np - 2019-01-30 pm (T+21.3d)
Image below (2019-01-30.992) was taken 21.3 days after discovery
SN is shown by white cross-hairs. Estimated magnitude +13.15
Annotated CCD Image (100% size, cropped)
3 x 120s exposure (average combine), 3x3 binning, C Filter
2019-01-30 23:49 UT (#653303-06)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2019np (NGC 3254) on Supernovae 2019 Page >>

NGC 3254 with Supernova 2019np - Detail
SN 2019np:  estimated magnitude + 13.3
Annotated CCD Image (100% size, cropped)
4 x 120s exposure (average combine), 3x3 binning, C Filter
2019-01-29 01:24 UT (#651248-52)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


NGC 2628 - Spiral Galaxy (UGC 4519)

NGC 2628 (Cancer)
CCD Image (50% size, linear scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-01-31 01:30 UT (#653411-15)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 2628 - Detail
Image below (2019-01-31.063) was taken 4.7 days after discovery of
potential TNS AT2019agw  (Type Unknown), discovered 2019/01/26.338
 by Catalina Real-Time Transient Survey and Nikolay Mishevskiy
 (Rochester Supernova site |  Discovery Image )

I don't see any sign of AT2019agw in my image
(The discovery image on SNhunt site doesn't look convincing to me
)
CCD Image (200% size, square root scale, cropped)
Images details as above

Back to Top


C/2015 O1 (PANSTARRS) - Comet

C/2015 O1 (PANSTARRS) (passing through Ursa Major)
Sun Distance 4.79 AU
Earth Distance 3.96 AU (592.0 million km)
Annotated CCD Image (50% size)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2019-01-31 01:55 UT (#653423-27)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

C/2015 O1 (PANSTARRS)  - Detail
CCD Image (100% size,cropped)
Image details as above

C/2015 O1 (PANSTARRS) - Earlier Image (2019-01-28)
(passing through Ursa Major)
Sun Distance 4.78 AU
Earth Distance 3.96 AU (592.1 million km)
Bright star in image is HIP 53295 (magnitude +4.6)
Annotated CCD Image (50% size)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2019-01-28 21:56 UT (#651068-72)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

C/2015 O1 (PANSTARRS)  - Earlier Detail (2019-01-28)
CCD Image (100% size,cropped)
Image details as above

C/2015 O1 (PANSTARRS) - Earlier Image (2019-01-03)
(passing through star field in Ursa Major)
Sun distance 4.65 AU.
(comet seems particularly bright given its distance from the Sun)
Annotated CCD Image (50% size)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2019-01-03 04:57 UT (#647441-45)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

C/2015 O1 (PANSTARRS) - Earlier Detail  (2019-01-03)
Estimated Magnitude +16.8
Annotated CCD Image (100% size,cropped)
Image details as above

Back to Top


PGC 32384 & PGC 213739 - Spiral Galaxies

PGC 32384 & PGC 213739 (Ursa Major)
Annotated CCD Image (50% size)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2019-01-31 01:55 UT (#653423-27)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

PGC 32384 & PGC 213739 - Detail
PGC 32384 (catalog mag +15.4),  PGC 213739 (catalog mag +16.3)
CCD Image (100% size,cropped)
Image details as above


Back to Top


NGC 6181 - Spiral Galaxy

NGC 6181 (Hercules)
Annotated CCD Image (50% size, linear scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2019-01-31 03:50 UT (#653479-82)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 6181  - Detail
AT 2019aai
CCD Image (100% size, log scale, cropped)
Image details as above

Annotated Negative CCD Image (100% size,  log scale, cropped)
Image details as above

>> Later Image of NGC 6181 (2022-04-27, S1004)
