David's Astronomy Pages
CCD Images - Session 678 (2019-08-02)

Objects Session Notes
Bullet C/2018 Y1 (Iwamoto) - Comet

Bullet UGC 118 & PGC 212483 - Spiral Galaxies
  (previously with Supernova AT2019B
)

Bullet Photometric Monitoring - Variables
  - RX And, U And, Z And, CI Cyg, AM Her, SS Her, U Her, BL Lac, CY Lyr, FG Sge, V Sge, X Tri

S Cyg attempt failed due to cloud

Bullet Astrometric Monitoring - Nearby Stars
 - Barnards Star, HH And, EV Lac, Teegardens Star


- Late evening / night session,  Duration 4.0hr

Session operated in  fully automated mode. Session was interrupted by one spell of cloudy sky.

- Main aim of the session was to return observatory to use after summer recess and perform general observing with mix of variable stars, nearby stars, comets and deep sky targets.

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  10°C (min)
- CCD Temperature:  -15°C  (100% av. power)
 (Notes:  set temperature was too low )
- Notes from 2019-08-02 >>



C/2018 Y1 (Iwamoto) - Comet

C/2018 Y1 (Iwamoto)
(passing through Perseus)

Sun Distance 2.74 AU
Earth Distance 3.15 AU (471.8 million km)
Location of comet (catalogue mag +18.4) is shown by white circle
   C/2018 Y1 (Iwamoto) - Closer View
Comet can only just be seen as a faint object at
position shown by the white cross hairs.
Image   Image
Annotated CCD Image (50% size)
6 x 30s exposure (average combine), 3x3 binning, C Filter
2019-08-02 23:11 UT (#678088-96)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  Annotated CCD Image (100% size, cropped)
Image details as left.




    More Images of C/2018 Y1 (Iwamoto)

C/2018 Y1 (Iwamoto) - Earlier Image (2019-03-04)
(passing through Auriga)
Sun Distance 1.34 AU
Earth Distance 0.83 AU (123.5 million km)
  C/2018 Y1 (Iwamoto) - Earlier Detail (2019-03-04)
Aligned on Comet

Image   Image
CCD Image (50% size)
2 x 30s exposure (average combine), 3x3 binning, C Filter
2019-03-04 21:51 UT (#671032-33)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (50% size, logscale)
11 x 30s exposure (average combine), 3x3 binning, C Filter
2019-03-04 21:51 UT (#671032-46)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Back to Top


UGC 118 & PGC 212483 - Spiral Galaxies (previously with Supernova AT2019B)

UGC 118 (NGC 42)  & PGC 212483 with SN 2019B (Pegasus)
SN 2019B (Type II, z=0.021) discovered 2019/01/01.250 by All Sky Automated Survey for SuperNovae (ASAS-SN)
 (Rochester Supernova site |  Discovery Image  )
The Rochester site implies that the SN is associated with UGC 118, but another
possibility is that the SN is actually associated with galaxy PGC 212483 as it has a smaller offset.


UGC 118 / NGC 42  & PGC 212483 - 2019-08-03 (T+213.8d)
Image below (2019-08-03.06) was taken 213.8 days after SN 2019B discovery
SN has faded and is no longer visible
Annotated Negative CCD Image (100% size, cropped)
2 x 180s exposure (average combine), 3x3 binning, C Filter
2019-08-03 01:25 UT (#678195-97)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 118 & PGC 212483 with SN 2019B - Earlier Image, 2019-01-02 (T+1.7d)
Image (2019-01-02.972) was taken 1.7 days after SN 2019B discovery
Annotated Negative CCD Image (100% size, cropped)
4 x 180 sec exposure (average combine), 3x3 binning, C Filter
2019-01-02 23:20 UT (#647239-43)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2019B (UGC 118 & PGC 212483) on Supernovae 2019 Page >>

Back to Top
