CCD Images - Session 687 (2019-08-31)

Objects Session Notes
Bullet C/2018 W2 (Africano) - Comet

Bullet ARP 4 - Spiral Galaxy with companion (MCG-2-5-50 & 50a)

Bullet NGC 1247 - Spiral Galaxy (UGCA 58)
Bullet NGC 5557 - Ellipical Galaxy (H I-99)
Bullet NGC 5624 - Spiral Galaxy (LGG 384 member)
Bullet NGC 5673 - Spiral Galaxy (LGG 384 member)
Bullet NGC 6760 - Globular Cluster

Bullet Pal 13 - Globular Cluster

Bullet UGC 11798 - Spiral Galaxy (Trio w/ UGC 11797 & UGC 11801)

Bullet Variable Stars (photometric monitoring)
  - RX And, U And, Z And, R CrB, CI Cy, SS Cyg, U Her, BL Lac, FG Sge, V Sge, W Sge, RR Tau

Bullet Nearby Stars (astrometric monitoring)
 - HH And, Barnards Star, Groombridge 34, EV Lac



- Full night session,  Duration 6.3 hr

Session operated in fully automated mode without any interventions and with limited monitoring

- Main aim of the session was a full night of general observing with a mix of variable stars, nearby stars, comets and deep sky targets.

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  Falling  to 7.5°C (min)
Outdoors 1°C cooler than Observatory)
(Dew heaters on manual,  50% & 80%)
- CCD Temperature:  -15°C  (67% av. power)
- Notes from 2019-08-31 >>



C/2018 W2 (Africano) - Comet

C/2018 W2 (Africano)
(passing through Camelopardalis)
Sun Distance 1.46 AU
Earth Distance 1.05 AU (157.4 million km)
   C/2018 W2 (Africano) - Detail
Frames aligned on comet
(stars appear trailed due to movement of comet)
Image   Image
CCD Image (50% size)
3 x 45s exposure (average combine), 3x3 binning, C Filter
2019-08-29 00:35 UT (#686102-04)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, square root scale, cropped)
6 x 45s exposure (average combine), 3x3 binning, C Filter
2019-08-29 00:36 UT (#686100-07)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

C/2018 W2 (Africano)  - Earlier Image (2019-08-27)
(passing through Camelopardalis)
Sun Distance 1.46 AU
Earth Distance 1.10 AU (164.8 million km)
   C/2018 W2 (Africano) - Earlier Detail (2019-08-27)
Frames aligned on comet
(stars appear trailed due to movement of comet)
Image   Image
CCD Image (50% size)
3 x 45s exposure (average combine), 3x3 binning, C Filter
2019-08-27 03:15 UT (#685243-45)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, square root scale, cropped)
9 x 45s exposure (average combine), 3x3 binning, C Filter
2019-08-27 03:15 UT (#685243-51)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

C/2018 W2 (Africano) - Earlier Image (2019-08-21)
  (passing through Camelopardalis)
Sun Distance 1.47 AU
Earth Distance 1.26 AU (188.3 million km)
   C/2018 W2 (Africano) - Earlier Detail (2019-08-21)


Image   Image
CCD Image (50% size)
9 x 45s exposure (average combine), 3x3 binning, C Filter
2019-08-21 02:22 UT (#681086-94)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, linear scale, cropped)
Image details as left



C/2018 W2 (Africano) - Earlier Image (2019-08-09)
 (passing through Camelopardalis)
Sun Distance 1.51 AU
Earth Distance 1.56 AU (233.5 million km)
   C/2018 W2 (Africano) - Earlier Detail (2019-08-09)


Image   Image
CCD Image (50% size)
6 x 45s exposure (average combine), 3x3 binning, C Filter
2019-08-09 00:23 UT (#680143-49)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, linear scale, cropped)
Image details as left




Back to Top


ARP 4 - Spiral Galaxy with companion (MCG-2-5-50 & 50a)

   ARP 4  (Cetus)
Taken at altitude 18°
Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-01 02:01 UT (#687232-36)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

   ARP 4  - Detail
MCG-2-5-50 (PGC 6626) (catalog mag +14.0) and companion
MCG-2-5-50a (PGC 6629) (catalog mag +15.0)
with adjacent galaxies PGC 953837 (catalog mag +17.3) &   PGC 953858 (catalog mag +18.2)
Annotated CCD Image (100% size, square root scale, cropped)
Image Details as above

Negative CCD Image (100% size, square root scale, cropped)
Image Details as above
    Note: Images affected by dust motte lying just just below the larger spiral galaxy


Back to Top


NGC 1247 - Spiral Galaxy (UGCA 58)

   NGC 1247 (Eridanus)
Flat Galaxy Atlas Object
Alias: UGCA 58
CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-01 02:22 UT (#687239-43)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

   NGC 1247 - Detail
CCD Image (100% size, square root scale, cropped)
Image Details as above

Negative CCD Image (100% size, square root scale, cropped)
Image Details as above

Back to Top


NGC 5557 - Ellipical Galaxy (H I-99)

NGC 5557 \ H I-99 (Bootes)
CCD Image (50% size, log scale)
4 x 120s exposure (average combine), 3x3 binning, C Filter
2019-08-31 21:33 UT (#687004-08)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 5557 - Detail
  CCD Image (100% size, log scale)
Image detail as above

Negative CCD Image (100% size, log scale)
Image detail as above

Back to Top


NGC 5624 - Spiral Galaxy (LGG 384 member)

NGC 5624 (Bootes)
Part of LGG 384 Galaxy Group,
Associated with Ast. Now Challenge Object, May 2019

NGC 5624 (catalog mag +13.2) with adjacent galaxies
PGC 2398307 (catalog mag +16.5), PGC 2396062 (catalog mag +17.6)
Annotated CCD Image (50% size, log scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-08-31 21:50 UT (#687011-15)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 5624 - Detail
  CCD Image (100% size, log scale)
Image detail as above


Back to Top


NGC 5673 - Spiral Galaxy (LGG 384 member)

NGC 5673 (Bootes)
Part of LGG 384 Galaxy Group,
Associated with Ast. Now Challenge Object, May 2019
CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-08-31 22:09 UT (#687019-23)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 5673 - Detail
  CCD Image (100% size, square root scale)
Image detail as above


Back to Top


NGC 6760 - Globular Cluster

NGC 6760 (Aquila)
CCD Image (70% size, log scale)
6 x 30s exposure (average combine), 3x3 binning, C Filter
2019-08-31 22:51 UT (#687065-71)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Pal 13 - Globular Cluster

Pal 13 (Pegasus)
Pal 13 is one of the dimmest globular clusters within the Palomar catalog.
 It's apparent diameter of approximately 1.8 arc-minutes
also makes it one of the smallest member of the catalog
CCD Image (50% size)
2 x 120s exposure (average combine), 3x3 binning, C Filter
2019-09-01 00:09 UT (#687144-48)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Pal 13  - Detail
CCD Image (100% size, cropped)
Image details as above

Negative CCD Image (100% size, cropped)
Image details as above

Pal 13  - Earlier Image (2019-08-27)
Negative CCD Image (100% size, cropped)
2 x 60s exposure (average combine), 3x3 binning, C Filter
2019-08-27 02:01 UT (#685207-09)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Pal 13  - Earlier Image (2019-08-22)
Pal 13 is only just visible in this single 60s exposure.
Other frames were affected by passing cloud
Annotated CCD Image (50% size)
60s exposure (single frame), 3x3 binning, C Filter
2019-08-22 21:34 UT (#683020)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


UGC 11798 - Spiral Galaxy (Galaxy Trio with UGC 11797 & UGC 11801)

UGC 11798 (Cygnus)
Galaxy Trio UGC 11797, UGC 11798 & UGC 11801
The bright star in FOV is SAO 51224 (mag +8.5)
CCD Image (50% size, square root scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-01 00:58 UT (#687183-87)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 11798 - Detail
UGC 11797 (catalog mag +15.2), UGC 11798 (catalog mag +14.8),
UGC 11801 (catalog mag +15.2),  PGC 214785 (catalog mag +17.9)
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above

UGC 11798 - Earlier Image (2019-08-27)
Negative CCD Image (100% size, linear scale, cropped)
2 x 180s exposure (average combine), 3x3 binning, C Filter
2019-08-27 00:08 UT (#685119-21)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 11798 - Earlier Image (2003)
CCD Image Composite
Top 5 x 30 sec exposure (summed)
Bottom 7 x 30 sec exposure (summed)
2003-12-07  23:29 to 23:36h UT (#55195-206)
8" LX200 + ST-7E
