Objects Session Notes
C/2018 N2 (ASASSN) - Comet C/2018 W2 (Africano) - Comet Abell 1400 - Galaxy Cluster (NGC 3921 et al) ARP 72 - Spiral Galaxy, NGC 5996 & NGC 5994 ARP 143 - Irregular Galaxies (NGC 2444 and NGC 2445) NGC 2445 - Irregular Galaxy NGC 3921 - Spiral Galaxy (ARP 224) NGC 5229 - Spiral Galaxy (M51 Group) NGC 5829 - Spiral Galaxy UGC 2614 - Spiral Galaxy with Type Ia Supernova 2019pxo Variable Stars (photometric monitoring) - U Gem, SS Her, U Her, FO Ori Nearby Stars (astrometric monitoring) - Barnards Star
- Night session (9.1 hours)
Session operated in fully automated mode with monitoring
- Main aim of the session was to take images of selected comets & deep sky targets - 12" LX200 + ST-10XME for imaging - TS 80mm APO + ZWO ASI178MC for guiding & imaging - Ambient Temperature: 4.5°C (min)
(Dew heaters on automated)- CCD Temperature: -15°C (59% av. power) - Notes from 2019-10-04 >>
| C/2018 N2 (ASASSN) (passing through Triangulum) Sun Distance 3.15 AU Earth Distance 2.26 AU (337.5 million km) |
 |
| CCD Image (50% size, linear scale) 2 x 45s exposure (average combine), 3x3 binning, C Filter 2019-10-04 22:18 UT (#705105-06) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| C/2018 N2 (ASASSN) - Detail |
 |
| CCD Image (100% size, square root scale, cropped) 9 x 45s exposure (average combine), 3x3 binning, C Filter 2019-10-04 22:21 UT (#705105-13) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
 |
| Negative CCD Image (100% size, square root scale, cropped) Image details as above |
| More Images of C/2018 N2 (ASASSN) |
Back to Top
| C/2018 W2 (Africano) (passing through Aquarius) Sun Distance 1.51 AU Earth Distance 0.55 AU (82.5 million km) |
C/2018 W2 (Africano) - Detail Frames guided using Lock Shift (stars appear trailed due to movement of comet image badly affected by guiding issue) |
|
 |
 |
|
| CCD Image (50% size, linear scale) 45s exposure (single frame), 3x3 binning, C Filter 2019-10-04 22:04 UT (#705094) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (50% size, square root scale, cropped) 9 x 45s exposure (average combine), 3x3 binning, C Filter 2019-10-04 22:07 UT (#705094-102) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of C/2018 W2 (Africano) on Comets 2019 Page >> |
Back to Top
| NGC 3921 & Adjacent Galaxies (part of Abell Galaxy
Cluster 1400) NGC 3921 (catalog mag +13.2) , plus: PGC 2489542 (catalog mag +16.7), PGC 37013 (catalog mag +15.3), PGC 2488118 (catalog mag +16.8), PGC 2491113 (catalog mag +16.1), PGC 2491459 (catalog mag +17.5), PGC 2491736 (catalog mag +16.8), PGC 2490363 (catalog mag +17.7), PGC 2491428 (catalog mag +18.2), |
 |
| Annotated Negative CCD Image (70% size, linear scale) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2019-10-04 20:29 UT (#705068-72) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
| ARP 72 (Serpens) NGC 5996 and NGC 5994 Single frame due to autoguiding issue/cloud, The other member of ARP 72 (NGC 5994) is very faint in this image |
 |
| CCD Image (50% size, linear scale) 180s exposure (single frame), 3x3 binning, C Filter 2019-10-04 19:19 UT (#705009) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| ARP 72 - Detail |
 |
| CCD Image (100% size, linear scale) Image details as above |
Back to Top
| ARP 143 (Lynx) |
 |
| CCD Image (50% size, logscale) 4 x 180s exposure (average combine), 3x3 binning, C Filter 2019-10-05 02:03 UT (#705143-46) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| ARP 143 - Detail |
 |
| Annotated CCD Image (100% size, log scale, cropped) Image details as above |
 |
| Negative CCD Image (100% size, log scale, cropped) Image details as above |
 |
| Negative CCD Image (100% size, linear scale, cropped) Image details as above |
| ARP 143 - Earlier Image (2014) |
 |
| Negatiive CCD Image (100% size, cropped) 5 x 120s sec exposure (average combine), 3x3 binning, C Filter 2014-12-04 01:00 h UT (#574405-09) 12" LX200R (at f/10.4) + ST-10XME |
Back to Top
| NGC 2445 (Lynx) Ring Galaxy, J.Lowrey List |
 |
| CCD Image (50% size) 4 x 180s exposure (average combine), 3x3 binning, C Filter 2019-10-05 02:03 UT (#705143-46) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 2445 - Detail |
|
|
| Annotated CCD Image (100% size, log scale, cropped) Image details as above |
Back to Top
| NGC 3921 (Ursa Major) Ring Galaxy, J.Lowrey List [ Ring Galaxies ] |
 |
| CCD Image (50% size, square root scale) CCD Image (50% size) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2019-10-04 20:29 UT (#705068-72) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 3921 / ARP 224 - Detail |
 |
| CCD Image (100% size, square root scale, cropped) Image details as above |
Back to Top
| NGC 5229 (Canes Venatici) Flat Galaxy Atlas |
|
| CCD Image (50% size) 3 x 180s exposure (average combine), 3x3 binning, C Filter 2019-10-04 20:48 UT (#705076-78) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 5229 - Detail (taken under dark sky, solar depression 25 deg) |
|
| CCD Image (100% size, linear scale, cropped) Image details as above |
|
| Negative CCD Image (100% size, linear scale, cropped) Image details as above |
| NGC 5229 - Earlier Image (2014-11-23) (taken under nautical twilight sky, solar depression 8.8 deg) |
|
| CCD Image (100% size, cropped) 2 x 90 sec exposure (average combine), 3x3 binning, C Filter 2014-11-23 23:58hUT (#571290-94) 12" LX200R (at f/10.4) + ST-10XME |
| NGC 5229 - Earlier Image (2014-11-23) (taken under dark moonless sky, solar depression 53 deg) |
|
| CCD Image (100% size, cropped) 5 x 90 sec exposure (average combine), 3x3 binning, C Filter 2014-11-23 23:58hUT (#571290-94) 12" LX200R (at f/10.4) + ST-10XME |
| NGC 5229 - Earlier Image (2014-11-02) (taken under dark moonlit sky (53% phase), solar depression 47 deg) |
|
| CCD Image (100% size, cropped) 5 x 60 sec exposure (average combine), 3x3 binning, C Filter 2014-11-02 23:17hUT (#567326-30) 12" LX200R (at f/10.4) + ST-10XME |
Back to Top
| NGC 5829 / ARP 42 (Bootes) |
 |
| CCD Image (50% size, linear scale) 3 x 180s exposure (average combine), 3x3 binning, C Filter 2019-10-04 19:06 UT (#705003-05) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 5829 - Detail |
 |
| CCD Image (100% size, linear scale) Image details as above |
| NGC 5829 - Earlier Image (2008) NGC 5829 with Supernova SN 2008b Image (2008-01-12.20) taken 9.4 days after SN discovery. 2008B measured magnitude +16.0 (C) |
 |
| Annotated CCD Image (250% size, cropped) 5 x 120s exposure (average combine), 2x2 binning, C Filter, 2008-01-12 04:45h UT (#252525-29) 8" LX200 Classic + ST-7E |
| NGC 5829 - Wider View Image (2008) Several galaxies adjacent to NGC 5829 including IC 4526 (catalog mag +15.8), PGC 53720 (catalog mag +16.9), PGC 53703 (catalog mag +17.5), PGC 1685296 (catalog mag +18.1), PGC 53702 (catalog mag +17.6), PGC 1684237 (catalog mag +17.7), & PGC 1684042 (catalog mag +17.0 |
 |
| Annotated CCD Image 5 x 120s exposure (average combine), 2x2 binning, C Filter, 2008-01-06 06:14 hUT (#250045-49) 8" LX200 Classic + ST-7E |
Back to Top
| UGC 2614 with SN 2019pxo (Perseus) SN 2019pxo (Type Ia, z=0.017519), discovered 2019/09/10.546 by ATLAS Alias : ATLAS19uve Discovery Magnitude 16.21 (orange-ATLAS Filter) vs Prior Non-Detection Limiting Magnitude 19.65 ( TNS 2019pxo ) |
| UGC 2614 with SN
2019pxo - 2019-10-04 (T+24.4) Image below (2019-10-04.942) was taken 24.4 days after discovery of SN 2019pxo |
 |
| CCD Image (100% size, log scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, C Filter 2019-10-04 22:37 UT (#705116-19) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 2614 - Detail |
 |
| Negative CCD Image (100% size, log scale, cropped) Image details as above |
| Images of SN 2019pxo (UGC 2614) on Supernovae 2019 Page >> |
Back to Top
