CCD Images - Session 713 (2019-10-22)

Objects Session Notes
Bullet NGC 489 - Spiral Galaxy (LGG 23 Group Member)
Bullet NGC 502 - Spiral Galaxy (LGG 23 Group Member)
Bullet NGC 509 - Spiral Galaxy (LGG 23 Group Member)
Bullet NGC 516 - Spiral Galaxy (LGG 23 Group Member)
Bullet NGC 2506 - Open Cluster (Caldwell 54)
Bullet NGC 4183 - Spiral Galaxy
Bullet NGC 5777 - Spiral Galaxy

Bullet Variable Stars (photometric monitoring)
  - RX And, U And, Z And, TT Ari, CI Cyg, S Cyg, SS Cyg, BL Lac, DY Per, GK Per, V Sge, RR Tau

- CN Ori, ER UMa attempts failed due to cloud


Bullet Nearby Stars (astrometric monitoring)
 - HH And, 61 Cyg, Groombridge 34, Teegardens Star

- DX Cnc attempt failed due to cloud


- Full night session (10.9 hours)

Session operated in detailed monitoring in first 1.5 hours.  Cloud developed in last 3 to 4 hours of session

- Main aim of the session was to test automated SharpCap imaging capture and integration with AstroMain /PHD2 and acquire selection of targets

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  9°C (min)
(Dew heaters on new automated control)
- CCD Temperature:  -15°C  (69% av. power)
- Notes from 2019-10-22 >>



NGC 489 - Spiral Galaxy (LGG 23 Group Member)

NGC 489 (Pisces)
NGC 524/LGG 23 Group.
Ast. Now Deep Sky Challenge, Nov 2019
CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-22 20:33 UT (#713042-46)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 489 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


NGC 502 - Spiral Galaxy (LGG 23 Group Member)

NGC 502 (Pisces)
NGC 524/LGG 23 Group.
Ast. Now Deep Sky Challenge, Nov 2019
(the single frame below picks up no detail from this small
spiral galaxy, target to be rescheduled)
CCD Image (50% size, square root scale)
180s exposure (single frame), 3x3 binning, C Filter
2019-10-23 00:17 UT (#713231)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 502 - Detail
CCD Image (100% size, square root scale, cropped)
180s exposure (single frame), 3x3 binning, C Filter
2019-10-23 00:17 UT (#713231)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


NGC 509 - Spiral Galaxy (LGG 23 Group Member)

NGC 509 (Pisces)
NGC 524/LGG 23 Group.
Ast. Now Deep Sky Challenge, Nov 2019
CCD Image (50% size, linear scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-22 22:38 UT (#713150-54)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 509 - Detail
CCD Image (100% size, linear scale, cropped)
Image details as above


Back to Top


NGC 516 - Spiral Galaxy (LGG 23 Group Member)

NGC 516 (Pisces)
NGC 524/LGG 23 Group.
Ast. Now Deep Sky Challenge, Nov 2019
CCD Image (50% size, square root scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-22 22:58 UT (#713158-62)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 516 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


NGC 2506 - Open Cluster (Caldwell 54)

NGC 2506 \ H VI-37 (Monoceros)
CCD Image (70% size, square root scale)
3 x 60s exposure (average combine), 3x3 binning, C Filter
2019-10-23 05:28 UT (#713316-18)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 2506 - Earlier Image (2010)
CCD Image (75% size, linear scale)
3 x 45s exposure (average combine), 3x3 binning, C Filter
2010-03-09 20:26 hUT (#416110-12)
12" LX200R (at f/9.7) + ST-10XME


Back to Top


NGC 4183 - Spiral Galaxy

NGC 4183 (Canes Venatici)
Flat Galaxy Atlas
(poor quality single frame, target to be reschedulued)
CCD Image (100% size, linear scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-22 22:38 UT (#713150-54)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


NGC 5777 - Spiral Galaxy

NGC 5777 (Draco)
Flat Galaxy Atlas
CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-22 18:54 UT (#713004-08)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 5777 - Detail
NGC 5777 (catalog mag +13.3),
PGC 53057 (catalog mag +17.1)
Annotated CCD Image (100% size, square root scale, cropped)
Image details as above
