David's Astronomy Pages
CCD Images - Session 730 (2019-12-17)

Objects Session Notes
Bullet C/2017 T2 (PanStarrs) - Comet
Bullet C/2018 N2 (ASASSN) - Comet

Bullet NGC 109 - Spiral Galaxy, with Type Ia SN 2019upw
Bullet NGC 2237 - Nebula  (Rosette Nebula)
Bullet NGC 2244 - Open Cluster (H VII-2)

Bullet Rosette HH1 - Young Stellar Object

Bullet Variable Stars (photometric monitoring)
  - RX

Bullet Nearby Stars (astrometric monitoring)
 - HH



- Post-Midnight Session (6.0 hours)

Session operated under automated control
Session preceeded by PHD2 testing/tuning

- Main aim of the session was to test a number of new program features and to acquire images of a selection of targets

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  Starting at -1°C (min) before rising to +1°C by dawn
(Dew heaters on new automated control)
- CCD Temperature:  -20/-25°C  (61%/68% av. power)
- Notes from 2019-12-17 >>



C/2017 T2 (PanStarrs) - Comet

C/2017 T2 (PanStarrs) - 2019-12-17
 (passing through Perseus)
Sun Distance 2.42 AU
Earth Distance 1.54 AU (230.1 million km)
   C/2017 T2 (PanStarrs) - 2019-12-17, Detail
Autoguided on a star using Lock Shift set at
the comet's rate of motion
(Ra -116.66, Dec 42.68 arcsec/hr)
Image   Image
CCD Image (50% size, square root scale)
45s exposure (single frame), 3x3 binning, C Filter
2019-12-17 20:58 UT (#730106)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, square root scale, cropped)
9 x 45s exposure (average combine), 3x3 binning, C Filter
2019-12-17 21:01 UT (#730106-14)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of C/2017 T2 (PanStarrs) on Comets 2019 Page

Back to Top


C/2018 N2 (ASASSN)  - Comet

C/2018 N2 (ASASSN) - 2019-12-17
 (passing through Andromeda)
Sun Distance 3.15 AU
Earth Distance 2.77 AU (413.7 million km)
   C/2018 N2 (ASASSN)  - 2019-12-17, Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra -20.75, Dec 2.53 arcsec/hr)
CCD Image (50% size)
3 x 45s exposure (average combine), 3x3 binning, C Filter
2019-12-17 19:49 UT (#730032-34)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, square root scale, cropped)
9 x 45s exposure (average combine), 3x3 binning, C Filter
2019-12-17 19:52 UT (#730032-40)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of C/2018 N2 (ASASSN) on Comets 2019 Page >>

Back to Top


NGC 109 - Spiral Galaxy, with Type Ia Supernova  2019upw

NGC 109 & SN 2019upw  (Andromeda)
 SN 2019upw  (Type Ia, z=0.02) discovered 2019/11/12.407 by ATLAS
 (Rochester Supernova site | Rafael G. Farfán image, mag 16.1  | Enrico Prosperi image, mag 15.1)

NGC 109 & SN 2019upw  - 2019-12-18 (T+36.5d)
Image below (2020-02-02.192) was taken 35.6 days after discovery of SN 2019upw
Estimated magnitude +16.3
Annotated CCD Image (100% size, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2019-12-18 00:04 UT (#730257-60)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2019upw (NGC 109) on Supernovae 2019 Page >>

Back to Top


NGC 2237 - Nebula  (Rosette Nebula)

NGC 2237   (Monoceros)
with NGC 2244 open cluster

Located an estimated 1,500 light-years from Earth in the constellation Monoceros,
the Rosette Nebula is a spectacular region of ionized hydrogen excavated by the
strong stellar winds from hot O- and B-type stars in the center of the young open cluster NGC 2244.
It is a region of on-going star formation with an age of about three million years.
CMOS Colour Image (20% size, cropped)
89 x 10s, 1x1 binning,  Gain 200, Raw16
2019-10-17 23:24 UT (Set 1, SharpCap LiveStack, Stretched)
ASI178MC (OSC) + TS 80mm f/6 APO, mounted on 12" LX200R

NGC 2237 - Detail
Heavily stretched CMOS  Image (20% size, cropped, gamma)
Image details as above

NGC 2237 - Detail
Part of the Rosette Nebula
CMOS  Image (53% size, croppred)
Image details as above

NGC 2237 - Earlier Image (2017)
Part of the Rosette Nebula
CCD Image (70% size)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2017-12-14 00:47h UT (#607138-42)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)


Back to Top


NGC 2244 - Open Cluster (H VII-2)

NGC 2244   (Monoceros)
(Note: NGC 2237 nebula is also present in this image but very faint)
CMOS Colour Image (20% size, cropped)
89 x 10s, 1x1 binning,  Gain 200, Raw16
2019-10-17 23:24 UT (Set 1, SharpCap LiveStack, Stretched)
ASI178MC (OSC) + TS 80mm f/6 APO, mounted on 12" LX200R
Larger Image (50% size)

NGC 2244  - Detail
(14.8 mins total exposure)
CMOS  Image (52% size, cropped)
Image details as above

NGC 2244 / H VII-2 - Earlier Image (2019-02-04)
Bright star to lower left is HIP 31159 (Mag +5.9)
Some nebulosity is visible
(2.5 mins total exposure)
CCD Image (70% size)
5 x 30s exposure (average combine), 3x3 binning, C Filter
2019-02-04 19:58 UT (#657073-77)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Rosette HH1 - Young Stellar Object

Rosette HH1   (Monoceros)
Position of Rosette HH1 is indicated by arrow
HH1 is a young star in the fierce environment of the Rosette Nebula that is
ejecting a complex jet of material (HH1) riddled with knots and bow shocks.
Annotated CMOS Colour Image (50% size, cropped)
89 x 10s, 1x1 binning,  Gain 200, Raw16
2019-10-17 23:24 UT (Set 1, SharpCap LiveStack, Stretched)
ASI178MC (OSC) + TS 80mm f/6 APO, mounted on 12" LX200R

Rosette HH1 - Detail
No sign of jet in this 14.8 min stacked exposure
Heavily stretched CMOS  Image (20% size, cropped, gamma 0.3,)
Image details as above

Rosette HH1 - Reference Image
Optical images of the jet taken at the WIYN 0.9-meter telescope at the
National Science Foundation’s Kitt Peak National Observatory
Jet is indicated by arrow
Image Credit: T. Rector/University of Alaska Anchorage, WIYN and NOAO/AURA/NSF
https://www.noao.edu/outreach/press/pr04/pr0403.html#images
