CCD Images - Session 746 (2020-01-26)

Objects Session Notes
Bullet Basel 7 - Open Cluster
Bullet Biur 7 - Open Cluster
Bullet Biur 9 - Open Cluster
Bullet Biur 11 - Open Cluster

Bullet IC 410 - Nebula (Tadpole Nebula)
Bullet IC 3074 - Spiral Galaxy

Bullet M100 - Spiral Galaxy
Bullet M100 - Spiral Galaxy with SN 2020oi

Bullet NGC 1893 - Open Cluster (part of IC 410)
Bullet NGC 2339 - Spiral Galaxy

Bullet Rose 5 - Compact Galaxy Group (PGC 36826 et al)
Bullet Rose 11 - Compact Galaxy Group (PGC 89674 et al)

Bullet Variable Stars (photometric monitoring)
  - RR Tau

Bullet Nearby Stars (astrometric monitoring)
 - CN Leo



- All night session (9.8 hours total).

- Main aims of the session was to test new features in AstroMain program and acquire a selection of deep sky objects if sky conditions allowed

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  0°C (min)
(Dew heaters on auto)
- CCD Temperature:  -20°/25°C  (63%/71% av. power)
- Notes from 2020-01-26 >>



Basel 7 - Open Cluster

Basel 7 (Monoceros)
SAC Basel 7, Saguaro Astronomy Club Database
Although the image is centered on the target object 'SAC Basel 7' in TheSky6
the center of star clustering appears to lie slightly to the right of center.
Target to be re-imaged in a follow-up session using target offsets 3.7' W, -0.8' N
CCD Image (70% size, linear scale)
3 x 30s exposure (average combine), 3x3 binning, C Filter
2020-01-26 21:14 UT (#746003-05)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Biur 7 - Open Cluster

Biur 7 (Monoceros)
SAC Biur 7, Saguaro Astronomy Club Database
Biurakan (or Byurakan) comes from the Armenian observatory (BAO).

It is clear where the center of Biur 7 star clustering is exactly.
Biur 7 to be re-imaged in a follow-up session
as a wider field shot to be taken using Secondary Scope
CCD Image (70% size, linear scale)
8 x 30s exposure (average combine), 3x3 binning, C Filter
2020-01-26 22:28 UT (#746043-51)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Biur 9 - Open Cluster

Biur 9 (Monoceros)
SAC Biur 9, Saguaro Astronomy Club Database
Biurakan (or Byurakan) comes from the Armenian observatory (BAO).

It is clear where the center of Biur 9 star clustering is exactly.
Biur 9 to be re-imaged as a wider field shot in a follow-up session
using the TS80 Secondary Scope
CCD Image (70% size, linear scale)
6 x 30s exposure (average combine), 3x3 binning, C Filter
2020-01-26 22:56 UT (#746067-74)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Biur 11 - Open Cluster

Biur 11 (Monoceros)
SAC Biur 11, Saguaro Astronomy Club Database
Biurakan (or Byurakan) comes from the Armenian observatory (BAO).

It is clear where the center of Biur 11 star clustering is exactly.
Biur 11 and adjacent Biur 12 cluster to be re-imaged in a follow-up session
as a wider field taken with Secondary Scope
CCD Image (70% size, linear scale)
8 x 30s exposure (average combine), 3x3 binning, C Filter
2020-01-26 22:17 UT (#746032-40)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


IC 410 - Nebula (Tadpole Nebula)

IC 410 (Auriga)
Single frame taken through Optolong L-eNhance filter
'Tadpole' in top right corner
To be re-imaged in follow-up session using multiple exposures
(DB filter) centered on tadpole
CCD Image (70% size, square root scale)
180s exposure (single frame), 3x3 binning, db Filter
2020-01-26 21:56 UT (#746017)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

IC 410 'Tadpole'
Single frame taken through Optolong L-eNhance filter
CCD Image (125% size, square root scale, cropped)
Image details as above

Negative CCD Image (125% size, square root scale, cropped)
Image details as above

 Central Area of IC 410 / NGC 1893.
Target to be re-imaged  in a follow-up session
as a mosaic or wider field shot using Secondary Scope
CCD Image (70% size, square root scale)
3 x 45s exposure (average combine), 3x3 binning, C Filter
2020-01-26 21:43 UT (#746011-15)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

False Colour CCD Image (70% size, log cale)
Image details as above


Back to Top


IC 3074 - Spiral Galaxy

IC 3074 (Virgo)
Flat Galaxy Atlas
CCD Image (50% size, linear scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-01-27 02:26 UT (#746105-08)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

IC 3074 - Detail
CCD Image (100% size, linear scale, cropped)
Image details as above


Back to Top


M100 - Spiral Galaxy

M100 (Coma Berenices)
Annotated CCD Image (50% size, log scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-01-26 23:38 UT (#746085-89)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

M100 - Detail
CCD Image (100% size, log scale, cropped)
Image details as above

False Colour CCD Image (100% size, log scale, cropped)
Inverse Spectrum Color Bar
Image details as above



Back to Top


M100 - Spiral Galaxy with SN 2020oi

M100 with SN 2020oi (Coma Berenices)
SN 2020oi (Type Ic) discovered 2020/01/07.542 by Zwicky Transient Facility (ZTF)
 ( Rochester Supernova siteK.Itagaki Image | SN 2020oi sub-page )

Picture below (2020-01-26.985) was taken 19.4 days after discovery
Annotated CCD Image (100% size, log scale, cropped, insert 200% size
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-01-26 23:38 UT (#746085-89)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

M100 with SN 2020oi - Detail
CCD Image (200% size, log scale, cropped)
Image details as above

Images of SN 2020io (M100) on Supernovae 2020 Page >>


Back to Top


NGC 1893 - Open Cluster (part of IC 410)

NGC 1893 (Auriga)
Central Area of IC 410.  Target to be re-imaged in a follow-up session
as a mosaic or wider field shot using Secondary Scope
CCD Image (70% size, linear scale)
3 x 45s exposure (average combine), 3x3 binning, C Filter
2020-01-26 21:43 UT (#746011-15)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 1893 / IC 410 - Detail
CCD Image (70% size, square root scale)
Image details as above

NGC 1893 / IC 410 - Earlier Image (2004)
Mosaic covering 59 x 48 arc min
Nebulosity associated with cluster (IC410) is not visible due to short exposure
CCD  Mosaic [ 4 x 5 frames],  30 sec exposures, 30% resize
2004-03-21  22:13 to 22:26 h UT (#63060-79)
8" LX200 + ST-7E


Back to Top


NGC 2339 - Spiral Galaxy

NGC 2339 (Gemini)
CCD Image (70% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-01-26 23:15 UT (#746077-81)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 2339 - Detail
CCD Image (70% size, square root scale)
Image details as above

NGC 2339 & Adjacent Galaxies
 NGC 2339 (catalog mag +12.6) with
PGC 20201 (catalog mag +15.9) &
PGC 143096 (catalog mag +16.1)
Annotated CCD Image (50% size, square root scale)
(Inserts at 150% size)
Image details as above

NGC 2339 - Earlier Image (2004)
CCD  Image,
5 x 60 sec exposure (median combine)
2004-03-28 22:21 h UT (#64058-62)
8" LX200 + ST-7E


Back to Top


Rose 5 - Compact Galaxy Group (PGC 36826 et al)

Rose 5 / PGC 36826 et al (Ursa Major)
Single frame. Target to be re-imaged in a follow-up session using multiple frames
CCD Image (100% size, linear scale, cropped)
180s exposure (single frame), 3x3 binning, C Filter
2020-01-26 21:35 UT (#746008)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Rose 11 - Compact Galaxy Group (PGC 89674 et al)

Rose 11 / PGC 89674 et al (Coma Berenices)
Rose Catalogue
CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-01-27 02:45 UT (#746110-14)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Rose 11 - Detail
A.  PGC 89675 (catalog mag +17.3)
B./C.  PGC 1672656 (catalog mag+17.4)
D.  PGC 89674 (catalog mag +17.0)
Annotated CCD Image (150% size, square root scale, cropped)
Image details as above

Negative CCD Image (150% size, square root scale, cropped)
Image details as above


Back to Top
