CCD Images - Session 757 (2020-02-27)

Objects Session Notes
Bullet Basel 7 - Open Cluster

Bullet NGC 5496 - Spiral Galaxy
Bullet NGC 5674 - Spiral Galaxy

Bullet SHK 360 - Faint Galaxy Group (PGC 1272444 et al)

Bullet Variable Stars (photometric monitoring)
  - SY Cnc, FU Ori, NV Ori, RR Tau

- CN Ori attempt failed due to cloud

Bullet Nearby Stars (astrometric monitoring)
 - None

- Groombridge 34 and Teegardens Star attempts failed due to wind



- All night session (8.9 hours total), , but shutter closed through middle of night due to cloud.

- Main aims of the session was to  acquire images of a selection of deep sky and comet objects

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  1.5°C (min)
(Dew heaters on auto)
- CCD Temperature:  -20°C  (58% av. power)
- Notes from 2020-02-27 >>



Basel 7 - Open Cluster

Basel 7 (Monoceros)
SAC Basel 7, Saguaro Astronomy Club Database
Target offsets of 3.7' W, -0.8' N  used to place the center of star clustering at image center.
CCD Image (70% size, linear scale)
3 x 30s exposure (average combine), 3x3 binning, C Filter
2020-02-27 22:02 UT (#757089-97)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Basel 7 - Earlier Image (2020-02-13 pm)
Target offsets of 3.7' W, -0.8' N  used to place the center of star clustering at image center.
CCD Image (70% size, linear scale)
5 x 30s exposure (average combine), 3x3 binning, C Filter
2020-02-13 20:40 UT (#752094-100)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Basel 7  - Earlier Image (2020-02-13 am)
Target offsets of 3.7' W, -0.8' N  used to place the center of star clustering at image center.
CCD Image (70% size, linear scale)
3 x 30s exposure (average combine), 3x3 binning, C Filter
2020-02-13 00:09 UT (#751267-72)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Basel 7 - Earlier Image (2020-02-02)
CCD Image (70% size, linear scale)
5 x 30s exposure (average combine), 3x3 binning, C Filter
2020-02-02 00:09 UT (#749133-41)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Basel 7 - Earlier Image (2020-01-26)
Although the image is centered on the target object 'SAC Basel 7' in TheSky6
the center of star clustering appears to lie slightly to the right of center.
CCD Image (70% size, linear scale)
3 x 30s exposure (average combine), 3x3 binning, C Filter
2020-01-26 21:14 UT (#746003-05)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


NGC 5496 - Spiral Galaxy

NGC 5496 (Virgo)
Flat Galaxy Atlas
Poor sky conditions. Target needs to be rescheduled
 Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-02-28 04:43 UT (#757110-14)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

 NGC 5496 - Detail
 CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


NGC 5674 - Spiral Galaxy

NGC 5674 (Virgo)
Ring Galaxy, J.Lowrey List
Poor sky conditions. Quality of new images noticeably poorer than earlier images
CCD Image (100% size, square root scale, cropped)
2 x 180s exposure (average combine), 3x3 binning, C Filter
2020-02-28 04:58 UT (#757116-17)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

 NGC 5674 - Earlier Image (2020-02-26)
CCD Image (100% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-02-26 03:42 UT (#755203-06)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
More NGC 5674 images from 2020-02-26

Back to Top


SHK 360 - Faint Galaxy Group (PGC 1272444 et al)

SHK 360 / PGC 1272444 et al (Serpens)
Shakhbazian Group
PGC 1272444 et al
 Annotated CCD Image (50% size, square root scale)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2020-02-28 04:26 UT (#757104-06)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

 SHK 360 - Detail
 CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above
