| 29P/Schwassmann-Wachmann - 2022-12-20 pm (passing through Gemini) Sun Distance 6.05 AU Earth Distance 5.09 AU (761.4 million km) |
29P/Schwassmann-Wachmann - 2022-12-20 pm Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -19.98 arcsec/hr, Dec 0.28 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 5 x 30s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 20:04 UT (#1074041-45) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, log scale, cropped) Image details as left |
|
| 29P/Schwassmann-Wachmann - 2022-12-20 pm Detail (passing through Gemini) Coma diameter: 153" |
||
 |
Sun Distance 6.05 AU Earth Distance 5.09 AU (761.4 million km) (Motion : Ra -19.98 arcsec/hr, Dec 0.28 arcsec/hr) Detail (150% size) Annotated CCD Image (150% size, log scale, cropped) 5 x 30s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 20:04 UT (#1074041-45) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of 29P/Schwassmann-Wachmann on Comets 2022 Page >> |
Back to Top
| 107P/Wilson-Harrington - 2022-12-20 (passing through Gemini) Sun Distance 1.75 AU Earth Distance 0.82 AU (122.3 million km) Comet (very faint) is indicated by white cross-hairs |
107P/Wilson-Harrington - 2022-12-20 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -65.22 arcsec/hr, Dec 5.28 arcsec/hr) Comet (very faint) is indicated by white cross-hairs |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 20:45 UT (#1074064-67) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) 12 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 20:50 UT (#1074064-75) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of 107P Wilson-Harrington on Comets 2022 Page >> |
Back to Top
| P/2010 H2 (Vales) - 2022-12-20 (passing through Taurus) Sun Distance 4.17 AU Earth Distance 3.28 AU (491.1 million km) Expected position of comet (not visible) is shown by white circle |
P/2010 H2 (Vales) - 2022-12-20 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -22.32 arcsec/hr, Dec 0.39 arcsec/hr) Expected position of comet (not visible) is shown by white circle |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 4 x 120s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 19:29 UT (#1074027-30) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) 4 x 120s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 19:29 UT (#1074027-30) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of P/2010 H2 (Vales) on Comets 2022 Page >> |
Back to Top
| C/2019 U5 (PANSTARRS) - 2022-12-21 (passing through Virgo) Sun Distance 3.73 AU (approaching) Earth Distance 4.03 AU (603.0 million km) Comet position is indicated by white cross-hairs |
C/2019 U5 (PANSTARRS) - 2022-12-21 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -0.99 arcsec/hr, Dec -15.23 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 3 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 04:41 UT (#1074276-78) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) 9 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 04:45 UT (#1074276-84) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of C/2019 U5 (PANSTARRS) on Comets 2022 Page >> |
Back to Top
| C/2021 Y1 (ATLAS) - 2022-12-20 (passing through Taurus) Sun Distance 2.55 AU (approaching) Earth Distance 1.70 AU (254.7 million km) |
C/2021 Y1 (ATLAS) - 2022-12-20 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -53.99 arcsec/hr, Dec -69.88 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 2 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 18:58 UT (#1074008-09) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) 6 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 19:02 UT (#1074008-14) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of C/2021 Y1 (ATLAS) on Comets 2022 Page >> |
Back to Top
| AT 2022usq (Auriga) AT 2022usq (Type: unk) discovered 2022-09-18.472 UT by ZTF Alias: ZTF22abghfwt Discovery Mag 13.67 (g-ZTF Filter) ( TNS 2022usq ) |
| AT 2022usq - 2022-12-20 (T+93.4d) Image below (2022-12-20.876) was taken 93.4 days after discovery of 2022usq Position of earlier transient (faded / not visible) is shown by white cross-hairs |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 21:08 UT (#1074078-81) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022usq on Transients 2022 Page >> |
Back to Top
| AT 2022vry (Cancer) Alias: In SDSS J083055.71+071556.5 AT 2022vry (Type: unk) discovered 2022-09-22.505 UT by ZTF Alias: ZTF22abhjmfy, Gaia22ebv Discovery Magnitude +16.35 (r-ZTF filter) [ TNS 2022vry | Gaia22ebv ] |
| AT 2022vry - 2022-12-20 (T+89.5d) Image below (2022-12-20.981) was taken 89.5 days after discovery of 2022vry Position of earlier transient (not visible) is shown by white circle No indication of transient or its host galaxy SDSS J083055.71+071556.5 |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 23:40 UT (#1074141-45) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022vry (SDSS J083055.71+071556.5) on Transients 2022 Page >> |
Back to Top
| AT 2022xao (Gemini) AT 2022xao (Type: QSO) discovered 2022-10-02.836 UT by Gaia Alias: Gaia22eda Alerting Magnitude 16.48 (vs Historic magnitude 15.20) Fading in known blazar QSO B0647+250 ( TNS 2022xao | Gaia22eda) |
| AT 2022xao - 2022-12-20 (T+79.1d) Image below (2022-12-20.938) was taken 79.1 days after discovery of 2022xao (this is about 3 years after fading actual started in late 2020, see Gaia Charts at Gaia22eda) Position of QSO (visible) is shown by white cross-hairs Measured magnitude +16.59 (Clear Filter) |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 22:35 UT (#1074119-21) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022xao (QSO B0647+250) on Transients 2022 Page >> |
Back to Top
| AT 2022xio (Gemini) AT 2022xio (Type: CV) discovered 2022-10-11.495 UT by ZTF Alias: ZTF22abewydn Discovery Magnitude 15.15 (r-ZTF filter) ( TNS 2022xio ) |
| AT 2022xio - 2022-12-20 (T+70.5d) Image below (2022-12-20.967) was taken 70.5 days after discovery of 2022xio Position of transient (very faint) is shown by white circle |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 23:21 UT (#1074133-37) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Position of transient (very faint) is shown by black cross-hairs |
 |
| Annotated negative CCD Image (100% size, square root scale, cropped) Image details as above |
| Images of AT 2022xio on Transients 2022 Page >> |
Back to Top
| AT 2022yeu (Andromeda) AT 2022yeu (Type: CV) discovered 2022-10-20.338 UT by PS1 Alias: PS22koo Discovery Data Source PanSTARS, Reporting Group YSE ( Young Supernova Experiment) Discovery Mag +15.34 ( TNS 2022yeu ) |
| AT 2022yeu - 2022-12-21 (T+61.7d) Image below (2022-12-21.036) was taken 61.7 days after discovery of 2022yeu Position of transient is shown by white cross-hairs Measured magnitude +13.31 |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 00:59 UT (#1074183-86) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022yeu on Transients 2022 Page >> |
Back to Top
| ARP 79 (Bootes) Alias: NGC 5490C [ ARP Galaxies ] |
| ARP 79 and adjacent galaxies ARP 79 (alias NGC 5490C/ PGC 50558, catalog mag +15.5), NGC 5490 (alias PGC 50558, catalog mag +13.1), PGC 50572 (catalog mag +16.3), PGC 214216 (catalog mag +16.4), PGC 50552 (catalog mag +16.4), PGC 1537141 (catalog mag +17.8), PGC 1536956 (catalog mag +18.0), PGC 1537530 (catalog mag +18.0) |
 |
| Annotated CCD Image (50% size, square root scale) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 04:03 UT (#1074260-64) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| ARP 79 - Detail Spiral Galaxy with large HSB companion on arm (HSB not readily visible in image below ?) |
 |
| Annotated CCD Image (150% size, square root scale, cropped) Image details as above |
 |
| Negative CCD Image (150% size, square root scale, cropped) Image details as above |
Back to Top
| M31 with Nova M31 2022-12a? (Andromeda) Nova M31 2022-12a? (Type: unk) discovered 2022-12-12.489 UT by Koichi Itagaki Alias: TCP J00411172+4023211 Discovery Mag 17.5 ( Rochester Latest Extragalactic Novae | Klaus Wenzel image ) |
| Nova M31 2022-12a? - 2022-12-21 (T+8.6d) Image below (2022-12-21.049) was taken 8.6 days after discovery of Nova M31 2022-12a? Position of reported candidate nova (faint) is shown by white cross-hairs Measured magnitude +17.51 |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 01:19 UT (#1074189-93) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of Nova M31 2022-12d? (M31) on Transients 2022 Page >> |
Back to Top
| M33 with Candidate Nova M33 2022-11a? (Triangulum) Nova M33 2022-11a? (Type: unk) discovered 2022-11-20.575 UT by XOSS Alias: TCP J01350893+3031503 Discovery Mag +13.4 ( Rochester Latest Extragalactic Novae | TCP J01350893+3031503 | Discovery Image ) |
| Nova M33 2022-11a? - 2022-12-21 (T+30.5d) Image below (2022-12-21.063) was taken 30.5 days after discovery of Nova M33 2022-11a? Position of reported nova (bright) is shown by white cross-hairs Measured magnitude +15.81 |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 01:39 UT (#1074197-201) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of Nova M33 2022-11a? (M33) on Transients 2022 Page >> |
Back to Top
| M63 (Canes Venatici) [ Messier Objects ] |
 |
| Annotated CCD Image (50% size, square root scale) 180s exposure (single frame), 3x3 binning, Clear Filter 2022-12-21 05:18 UT (#1074293) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| M63 - Detail Poor quality image (single sub only due to cloud) Target to be rescheduled |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 180s exposure (single frame), 3x3 binning, Clear Filter 2022-12-21 05:18 UT (#1074293) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| M63 - Earlier Image (2006) |
 |
| CCD Image 5 x 2 min exposure (summed combine), 2x2 binning, C Filter Log brightness scaling 2006-04-28 00:44 h UT (#118215-19) 8" LX200 classic + ST-7e |
Back to Top
| M64 (Coma Berenices) Alias: NGC 4826, Black-eye Galaxy [ Messier Objects ] |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 03:41 UT (#1074252-56) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| M64 - Detail |
 |
| Annotated CCD Image (100% size, square root scale, cropped) Image details as above |
 |
| Annotated negative CCD Image (100% size, square root scale, cropped) Image details as above |
| M64 - Earlier Image (2004) |
|
| CCD Image, 5 x 60 sec exposure (summed) 2004-03-29 01:20 h UT (#64225-29) 8" LX200 classic + ST-7e |
Back to Top
| NGC 2777 with SN 2022aagp (Cancer) SN 2022aagp (Type: II) discovered 2022-11-14.393 UT by ZTF Alias: ZTF22abtspsw Discovery Mag 15.76 (r-ZTF filter) ( TNS 2022aagp ) |
| NGC 2777 with SN 2022aagp - 2022-12-20 (T+36.6d) Image below (2022-12-20.994) was taken 36.6 days after discovery of 2022aagp Position of reported supernova (not separately distinguishable) is shown by white cross-hairs Measured magnitude +14.29 (nucleus + SN) |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 00:01 UT (#1074149-53) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022aagp (NGC 2777) on Supernova 2022 Page >> |
Back to Top
| NGC 3705 with SN 2022xxf (Leo) SN 2022xxf (Type: Ic-BL) discovered 2022-10-17.851 UT by Koichi Itagaki Alias: ZTF22abnvurz, ATLAS22blmn Discovery Mag 15.5 (Clear Filter) ( Rochester Supernova site | TNS 2022xxf ) |
| NGC 3705 with SN 2022xxf - 2022-12-21 (T+64.3d) Image below (2022-12-21.104) was taken 64.3 days after discovery of 2022xxf Position of SN (bright) is shown by white cross-hairs) is shown by white cross-hairs Measured magnitude +14.45 (aperture 8) |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 02:35 UT (#1074230-32) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022xxf (NGC 3705) on Supernovae 2022 Page >> |
Back to Top
| NGC 3938 with SN 2022xlp (Ursa Major) SN 2022xlp (Type: Ia-02cx) discovered 2022-10-13.808 UT by Koichi Itagaki Alias: ATLAS22bkeb Discovery Magnitude xx ( TNS 2022xlp ) |
| NGC 3938 with SN 2022xlp - 2022-12-21 (T+68.3d) Image below (2022-12-21.132) was taken 68.3 days after discovery of 2022xlp Position of SN (very faint) shown by white cross-hairs Measured magnitude +17.20 |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 03:19 UT (#1074245-49) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022xlp (NGC 3938) on Supernova 2022 Page >> |
Back to Top
| NGC 4340 with SN 2022zzz (Coma Berenices) SN 2022zzz (Type: II) discovered 2022-11-12.824 UT by Koichi Itagaki Alias: ATLAS22blqo ( Rochester Supernova site | TNS 2022zzz ) Although SN 2022zzz has been ascribed to NGC 4340 it seems more likely that the supernova's host galaxy is the small diminutive galaxy LEDA 213984 |
| NGC 4340 with SN 2022zzz - 2022-12-21 (T+38.3d) Image below (2022-12-21.118) was taken 38.3 days after discovery of 2022zzz Position of reported transient (very faint) is shown by white cross-hairs |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 02:59 UT (#1074238-42) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022zzz (NGC 4340) on Supernova 2022 Page >> |
Back to Top
| NGC 5230 (Virgo) |
 |
| Annotated CCD Image (50% size, square root scale) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 04:26 UT (#1074268-72) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 5230 - Detail |
 |
| Annotated CCD Image (125% size, square root scale, cropped) Image details as above |
 |
| Negative CCD Image (125% size, square root scale, cropped) Image details as above |
Back to Top
| NGC 5548 with AT 2022abcs (Bootes) AT 2022abcs (Type: AGN?) discovered 2022-11-16.541 UT by ZTF Alias: ZTF22abunqtv Discovery Mag -- (r-ZTF Filter) ( TNS 2022abcs ) |
| NGC 5548 with AT 2022abcs - 2022-12-21 (T+34.5d) Image below (2022-12-21.078) was taken 34.5 days after discovery of 2022abcs Position of reported transient (not separately distinguishable) is shown by white cross-hairs Measured magnitude +13.41 (nucleus + transient) |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 02:02 UT (#1074205-09) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT2022abcs (NGC 5548) on Transients 2022 Page >> |
Back to Top
| NGC 5631 with SN 2022aaiq (Ursa Major) SN 2022aaiq (Type: Ia) discovered 2022-11-15.057 UT by Patrick Wiggins Discovery Mag +16.0 (vs last non-detection, limiting mag +19) ( TNS 2022aaiq ) |
| NGC 5631 with SN 2022acsj - 2022-12-20 pm (T+24.4d) Image below (2022-12-20.905) was taken 24.4 days after discovery of 2022acsj Position of supernova (bright) is shown by white cross-hairs Measured Magnitude ? |
 |
| Annotated CCD Image (125% size, log scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 21:52 UT (#1074095-99) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022aaiq (NGC 5631) on Supernova 2022 Page >> |
Back to Top
| UGC 2926 with SN 2022acyd (Taurus) SN 2022acyd (Type: II) discovered 2022-12-15.248 UT by ZTF Alias: ZTF22abysshb Discovery Mag +18.3 ( Rochester Latest Extragalactic Novae | TNS 2022acyd | ZTF22abysshb ) |
| UGC 2926 with SN 2022acyd - 2022-12-20 (T+5.6d) Image below (2022-12-20.819) was taken 5.6 days after discovery of 2022acyd Position of reported SN (faint but still distinct) is shown by white cross-hairs |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 19:49 UT (#1074033-37) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022acyd (UGC 2926) on Supernova 2022 Page >> |
Back to Top
| UGC 3554 with SN 2022rbo (Auriga) SN 2022rbo (Type: Ib) discovered 2022-08-09.497 UT by ZTF Alias: ZTF22aazqoey Discovery Mag 17.95 (r-ZTF filter) ( TNS 2022rbo ) |
| UGC 3554 with SN 2022rbo - 2022-12-20 (T+133.4d) Image below (2022-12-20.848) was taken 133.4 days after discovery of 2022rbo Position of earlier supernova (not distinguishable) is shown by white cross-hairs |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 20:30 UT (#1074057-61) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022rbo (UGC 3554) on Supernova 2022 Page >> |
Back to Top
| UGC 3937 with SN 2022acfz (Lynx) SN 2022acfz (Type: II) discovered 2022-11-30.476 UT by ATLAS Alias: ATLAS22bngp Discovery Mag +18.00 (orange-ATLAS filter) ( TNS 2022acfz ) |
| UGC 3937 - Spiral Galaxy Alias: PGC 21425 (catalog mag +14.2) with adjacent galaxies PGC 21407 (catalog mag +15.5), PGC 21419 (catalog mag +17.1), PGC 2067786 (catalog mag +17.1), |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 22:59 UT (#1074125-29) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 3937 with SN 2022acfz - 2022-12-20 (T+20.5d) Image below (2022-12-20.952) was taken 20.5 days after discovery of 2022acfz Position of SN (bright) is shown by white cross-hairs Measured magnitude +14.99 |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 22:59 UT (#1074125-29) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022acfz (UGC 3937) on Supernova 2022 Page >> |
Back to Top
| UGC 8046 with SN 2022zxr (Ursa Major) SN 2022zxr (Type: II) discovered 2022-11-10.491 UT by ZTF Alias: ZTF22abtcyhv Discovery Mag +16.65 ( Rochester Supernova site | TNS 2022zxr ) |
| UGC 8046 with SN 2022zxr - 2022-12-20 (T+40.4d) Image below (2022-12-20.891) was taken 40.4 days after discovery of 2022zxr Position of reported SN (distinct) is shown by white cross-hairs) is shown by white cross-hairs Measured magnitude +15.78 |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 21:30 UT (#1074087-90) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022zxr (UGC 8046) on Supernova 2022 Page >> |
Back to Top
| UGC 8317 with AT 2022qvu (Coma Berenices) AT 2022qvu (Type: unk) discovered 2022-08-06.274 UT by ATLAS Alias: ATLAS22zjv ( Rochester Supernova site | TNS 2022qvu ) |
| UGC 8317 with AT 2022qvu - 2022-12-21 (T+136.9d) Image below (2022-12-21.204) was taken 136.9 days after discovery of 2022qvu Position of reported transient (not visible) is shown by white cross-hairs |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-21 05:03 UT (#1074287-91) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022qvu (UGC 8317) on Transients 2022 Page >> |
Back to Top
