Objects Session Notes
AT 2023tdi - Type BL Transient (QSO B1028+511) AT 2023aaky - CV Type Transient (Near NGC 957) CGCG 182-071 - Galaxy with Type Ia Supernova 2023emd M33 - Spiral Galaxy with EGN Type Transient AT 2023ypg M98 - Spiral Galaxy NGC 5853 - Spiral Galaxy NGC 6745 - Spiral Galaxy with Transient AT 2023ucy UGC 530 - Spiral Galaxy with Type Ia Supernova 2023yma UGC 5764 - Irregular Galaxy (ARP 267) UGC 6265 - Spiral Galaxy with Type Ia-91T Supernova 2023wcw - AT2023ud attempt failed (single frame/bad guiding) Variable Stars (photometric monitoring) - RX And, RR Leo Nearby Stars (astrometric monitoring) - None
- Attempted All-Night Session (13.5 hrs) - 12" LX200 + ST-10XME for imaging - TS 80mm APO + ZWO ASI178MC for guiding & imaging - Ambient Temperature: 3.5°C (min) - CCD Temperature: -20° C - Notes from 2023-12-19 >> -
AT 2023tdi (Ursa Major) AT 2023tdi (Type: BL) discovered 2023-09-15.424 UT by Gaia Alias: Gaia23ckv, QSO B1028+511 Discovery Mag 16.34 (G-Gaia Filter) vs Historic Mag 14.06 Known BL Lac type object (QSO B1028+511) brightens by 0.5 mag ( TNS 2023tdi | Gaia23ckv ) |
AT 2023tdi - 2023-12-20 (T+95.6d) Image below (2023-12-20.065) was taken 95.6 days after discovery of 2023tdi Position of reported transient (faint, stable) is shown by white cross-hairs Measured Magnitude +15.60 (Clear Filter) |
Annotated CCD Image (100% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-20 01:43 UT (#1176040-44) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023tdi on Transients 2023 Page >> |
Back to Top
AT 2023aaky (Perseus) AT 2023aaky (Type: CV) discovered 2023-12-15.096 UT by Gaia Alias: Gaia23dql Discovery magnitude 11.62 (G-Gaia Filter) vs Historic Magnitude 11.97 +/- 0.07 SD Bright Gaia source brightens by 0.4 mag, previous events seen ( TNS 2023aaky | Gaia23dql ) |
AT 2023aaky - 2023-12-19 (T+4.7d) Image below (2023-12-19.824) was taken 4.7 days after discovery of 2023aaky Position of reported transient (distinct) is shown by white cross-hairs Measured Magnitude +11.80 (Clear Filter) |
Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-19 19:49 UT (#1176027-31) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023aaky on Transients 2023 Page >> |
Back to Top
CGCG 182-071 with SN 2023emd (Leo
Minor) SN 2023emd (Type: Ia) discovered 2023-04-02.259 UT by ZTF Alias: ZTF23aaeeawl, Gaia23bkm Discovery Magnitude 18.32 (r-ZTF filter) SN in galaxy MCG+06-22-068 Gaia, 2023-04-05 03:17:30, Mag +17.60 ( TNS 2023emd | Gaia23bkm ) |
CGCG 182-071 - Galaxy CGCG 182-071 (alias: MCG+06-22-068 / PGC 29248, catalog mag +14.9) |
Annotated CCD Image (60% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-20 05:18 UT (#1176065-68) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CGCG 182-071 with SN 2023emd - 2023-12-20 (T+262.0d) Image below (2023-12-20.216) was taken 262.0 days after discovery of 2023emd Position of earlier SN (no longer visible) is indicated by white cross-hairs. |
Annotated CCD Image (175% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-20 05:18 UT (#1176065-68) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2023emd (in CGCG 182-071) on Supernova 2023 Page >> |
Back to Top
M33 with Nova M33 AT 2023ypg
(Triangulum) AT 2023ypg (Type: EGN) discovered 2023-11-29.609 UT by XOSS Alias: PSP23O, PNV J01325400+3021387, Gaia23dnw Discovery Magnitude 18.2 (Clear filter) Confirmed Nova Gaia, 2023-12-06 23:55, Mag +18.59 Gaia, 2023-12-07 07:42 , Mag +18.71 Gaia, 2023-12-12 05:59 , Mag +18.42 Gaia, 2024-01-20 18:52, Mag +19.50 ( TNS 2023ypg | Gaia23dnw ) |
M33 with Nova AT 2023ypg Image taking with secondary scope showing position of reported EGN (blue circle) relative to M33 Galaxy centre (labelled) and outline of M33 (white ellipse) |
|
CMOS Image (16% size) 10s exposure (stacked), 1x1 binning 2023-12-19 19:21 UT (#Cam2_Ref) TS 80mm APO, ZWO ASI178MC & PHD2 |
M33 with Nova AT 2023ypg (T+20.2d) |
Annotated CCD Image (50% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-19 19:33 UT (#1176021-24) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
M33 with Nova AT 2023ypg - 2023-12-19 (T+20.2d) Image below (2023-12-19.809) was taken 20.2 days after discovery of 2023ypg Position of reported Transient (faint) is indicated by white cross-hairs. Measured Magnitude +18.57 (Clear Filter) |
Annotated CCD Image (100% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-19 19:33 UT (#1176021-24) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023ypg (in M33) on Transients 2023 Page >> |
Back to Top
M98 (Coma Berenices) [ Messier Objects ] Poor quality image (single frame only) |
Annotated CCD Image (70% size, square root scale) 180s exposure (single frame), 3x3 binning, Clear Filter 2023-12-20 05:40 UT (#1176081) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
M98 - Earlier Image (Dec 2022) |
Annotated CCD Image (70% size, square root scale) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-12-20 04:54 UT (#1073112-16) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
M98 - Earlier Image (Mar 2007) |
CCD Image 7 x 180s exposure (average combine), 2x2 binning, C filter 2007-03-13 00:25h UT (#182297-303) 8" LX200 Classic + ST-7E |
Back to Top
NGC 5853 (Bootes) Poor quality image (single frame only) |
Annotated CCD Image 50% size, square root scale) 180s exposure (single frame), 3x3 binning, Clear Filter 2023-12-20 06:15 UT (#1176086) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
NGC 5853 - Detail |
Annotated CCD Image (125% size, square root scale, copped) Image details as above |
Back to Top
NGC 6745 with SN 2023ucy (Lyra) SN 2023ucy (Type: II) discovered 2023-10-05.151 UT by ZTF Alias: ZTF23abhzxwm Discovery Mag +17.9 (r-ZTF filter) vs last non-detection image with 19.91 limiting mag It is noted that SN 2022prr (19:01:41.897, +40:45:03.67) occurred in Jul 2022 at approximately the same location as this newly reported transient 2023ucy (19:01:41.992, +40:45:05.89) (are they possibly related ?) ( TNS 2023ucy ) ( TNS 2022prr ) |
NGC 6745 with SN 2023ucy - 2023-12-20 (T+76.1d) Image below (2023-12-20.276) was taken 76.1 days after discovery of 2023ucy Position of SN (faint) is shown by white cross-hairs Measured magnitude +14.79 Poor quality image (single frame only) |
Annotated CCD Image (150% size, square root scale, cropped) 180s exposure (single frame), 3x3 binning, Clear Filter 2023-12-20 06:38 UT (#1176090) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2023ucy (NGC 6745) on Supernovae 2023 Page >> |
Back to Top
UGC 530 with SN 2023yma (Andromeda) |
UGC 530 - Spiral Galaxy |
|
Annotated CCD Image (50% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-19 17:41 UT (#1176005-09) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
UGC 530 with SN 2023yma - 2023-12-19 (T+24.4d) Image below (2023-12-19.731) was taken 24.4 days after discovery of 2023yma Position of reported supernova (difficult to separate from nucleus) is shown by white cross-hairs Measured Magnitude ? (Clear Filter) |
|
Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-19 17:41 UT (#1176005-09) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
UGC 530 with SN 2023yma - Detail 2023-12-19 (T+24.4d) Image below (2023-12-19.731) was taken 24.4 days after discovery of 2023yma Position of reported supernova (faint but distinct) is shown by white cross-hairs |
|
Annotated CCD Image (175% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-19 17:41 UT (#1176005-09) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2023yma (in UGC 530) on Supernova 2023 Page >> |
Back to Top
UGC 5764 (Leo Minor) Alias: ARP 267 [ ARP Galaxies ] [ Irregular Galaxies ] |
Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-03-25 21:54 UT (#995041-45) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
UGC 5764 - Detail |
Annotated CCD Image (125% size, square root scale,
cropped) Image details as above |
UGC 5764 - Earlier Detail |
Annotated CCD Image (125% size, square root scale,
cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-03-25 21:54 UT (#995041-45) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Negative CCD Image (125% size, square root scale,
cropped) Image details as above |
Back to Top
UGC 6265 with SN 2023wcw (Ursa Major) SN 2023wcw (Type: Ia-91T, z= 0.032834) discovered 2023-11-01.491 UT by ZTF Alias: ZTF23abnoilr Discovery Magnitude 17.14 (r-ZTF Filter) ( TNS 2023wcw ) |
UGC 6265 with SN 2023wcw - 2023-12-20 (T+48.7d) Image below (2023-12-20.146) was taken 48.7 days after discovery of 2023wcw Position of reported supernova (faint) is shown by white cross-hairs Estimated Mag 17.1 (Clear filter) Poor quality image (single frame) |
Annotated CCD Image (150% size, square root scale, cropped) 180s exposure (single frame), 3x3 binning, Clear Filter 2023-12-20 03:30 UT (#1176057) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2023wcw (in UGC 6265) on Supernova 2023 Page >> |
Back to Top
