Notes (S00052)

This was my final opportunity to acquire images of Mars during 2003 opposition prior to dismantling my Dorset observatory.  Some good images were obtained.

Back to Top


M15 Globular Cluster

M15 (Pegasus)
CCD Image,  10s exposure
2003-08-22 22:13h UT (#52005)
11.4 x 7.6 arc sec

Back to Top


M27 (Dumbbell Nebula) - Planetary Nebula

M27 (Vulpecula)
CCD Image,  9 x 20s exposures (summed)
2003-08-22 22:30 to 22:34h UT (#52015-23)
11.4 x 7.6 arc sec

Back to Top


Mars

Mars - close to Opposition
(phase 99.6%, 25.0 arc min diameter)
Image Image
2003-08-22
23:52:37 h UT
0.30 sec exposure
(#52041)
2003-08-23
00:32:04 h UT
0.25 sec exposure
(#52117)
8" SCT operating at F/29 through eyepiece projection
Unfiltered. Images unsharp masked.
Image Scale 0.31 arc sec/pixel
(equivalent to surface scale of 85 km/pixel)



Mars features
2003-08-22  23:52:37 h UT (#52041)
Unsharp masked

Image  Image
Comparsion of 0.25 sec exposure
(image #52117, 2003-08-23 00:32 h UT)
with B/W view from Mars Previewer II




Mars through colour filters
 From left to right :
Green Filter,  5.00 sec exposure (00:58 h UT, #52147)
Yellow Filter , 0.25 sec exposure (01:32 h UT, #52163)
Blue Filter , 0.50 sec exposure (01:40 h UT, #52169)
Red Filter , 0.50 sec exposure (02:13 h UT, #52204)
8" SCT operating at F/29 through eyepiece projection
Taken on 2003-08-23. Images all unsharp masked
(Filters had to be manually inserted into the optical path, involving
 reconnecting the CCD camera to telescope and recentering/refocussing
on Mars each time - hence the large time gap between each image.
 Seeing quality had also deteriorated significantly by the time the
red filter image was taken)

Mars rotation over nearly 3 hours
 From left to right :
2003-08-22  23:45h UT (0.20 sec exposure, unfiltered, #52030)
2003-08-23  00:58h UT (0.25 sec exposure, unfiltered, #52127)
2003-08-23  01:47h UT (0.50 sec exposure, blue filter, #52177)
2003-08-23  02:35h UT (0.25 sec exposure, unfiltered, #52219)
Images all unsharp masked

Back to Top


NGC 7454 - Elliptical Galaxy

NGC 7454 (Pegasus)
(Catalog Mag +13.1)
CCD Image,  5 x 20s exposures (median)
2003-08-23 03:03h UT (#52231- 35)
9.8 x 6.3 arc sec

Back to Top


M31 (Andromeda Galaxy) - Nucleus/Dust Lane

M31 (Andromeda)
CCD Image,  6 x 1 20s exposures (summed)
Mid Range Brighten
2003-08-23  03:23 to 03:23h UT (#52253- 58)
11.4 x 7.6 arc sec

Back to Top


NGC 206 Emission Knot/Cluster in M31

NGC 206 Emission Knot in M31 arms (Andromeda)
CCD Image, 3 x 120 sec exposure
(2x2 binning, median combine, x0.5 resize)
2003-08-23  03:40 to 03:46h UT (#52259-61)
11.4 x 7.6 arc sec

Back to Top


Sky Brightness Survey
