Notes (S00064)

Imaging session was with a focal reducer bringing 8" f/10 LX200 to f/7. Images were recorded with ST7 CCD camera. Seeing was reasonable and the opportunity was taken to acquire a sequence of 29 targets (5 x 60 sec sets) comprising mainly galaxies in Leo, Virgo and Coma Berenices, but also a couple of open clusters in Auriga and comet 123P West-Hartley.  The targets (including 15 Messier objects) were acquired via an automated scripting run of 3h 45m duration. Some highlights from the session are shown below :

M100
M64
(Black-eye Galaxy)
Image  Image
M88 M60
Image Image

Back to Top


M49 Elliptical Galaxy

M49  (Virgo) catalog mag +9.1
Other galaxies (catalog mags) VCC1199 (+15.5),
NGC4465 (+16.5), NGC4467 (+14.3), VCC1203 (+15.7)
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-29  01:20 h UT (#64183-87)

M49  (Virgo) catalog mag +9.1
Other galaxies (catalog mags) VCC1199 (+15.5),
NGC4465 (+16.5), NGC4467 (+14.3), VCC1203 (+15.7),
VCC1254 (+17.5), UGC7636 (+14.8)
CCD  Image, 5 x 60 sec exposure (summed)
2004-03-29  01:20 h UT (#64183-87)

Back to Top


M58 Spiral Galaxy

M58 (Virgo)
CCD  Image, 5 x 60 sec exposure (summed)
Mid range brightened
2004-03-28  23:55 h UT (#64145-49)

Back to Top


M59 Elliptical Galaxy

M59 (Virgo)
CCD  Image, 5 x 60 sec exposure (summed)
Mid range brightened
2004-03-28  23:47 h UT (#64138-42)

Back to Top


M60 Elliptical Galaxy

M60 (Virgo)
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-28  23:39 h UT (#64131-35)

Elliptical Galaxy M60 (+9.6),
Spiral Galaxy NGC4647 (+12.1)
Elliptical Galaxy CGCG71-18 (+15.8)
CCD  Image, 5 x 60 sec exposure (summed)
2004-03-28  23:39 h UT (#64131-35)

Back to Top


M64 Spiral Galaxy (Black-eye Galaxy)

M64 (Coma Berenices)
CCD  Image, 5 x 60 sec exposure (summed)
2004-03-29  01:20 h UT (#64225-29)

Back to Top


M84 Elliptical Galaxy

M84 (Virgo)
CCD  Image, 5 x 60 sec exposure (summed)
2004-03-29  00:29 h UT (#64177-81)

Back to Top


M86 Elliptical Galaxy

M86 (Virgo)
CCD  Image, 5 x 60 sec exposure (summed)
2004-03-29  00:23 h UT (#64171-74)

Back to Top


M87 - Elliptical Galaxy

M87 (Virgo)
(with NGC 4478 lower right)
CCD  Image, 5 x 60 sec exposure (summed)
2004-03-29  00:14 h UT (#64163-67)

M87 (false colour image)
 CCD Image (details as above)
Log Scale, False Colour

M87 - jet
CCD  Image (details as above)
Unsharp Masked, Log Scale, False Colour

M87 - jet
CCD  Image (details as above)
Unsharp Masked, Log Scale, False Colour

Back to Top


M88 Spiral Galaxy

M88 (Virgo)
CCD  Image, 10 x 60 sec exposure (summed)
2004-03-29  00:54 h UT (#64201-05 & 64213-17)

Back to Top


M89 Elliptical Galaxy

M89 (Virgo)
CCD  Image, 5 x 60 sec exposure (summed)
2004-03-29  00:07 h UT (#64157-61)

Back to Top


M90 Spiral Galaxy

M90 (Virgo)
CCD  Image, 5 x 60 sec exposure (summed)
2004-03-29  00:01 h UT (#64151-55)

Back to Top


M91 Spiral Galaxy

M91 (Coma Berenices)
CCD  Image, 4 x 60 sec exposure (summed)
2004-03-29  00:48 h UT (#64195-99)

M91 (catalog mag +11.1),
CGCG99-97 (catalog mag +15.6)
CCD  Image, 4 x 60 sec exposure (median combine)
2004-03-29  00:48 h UT (#64195-99)

Back to Top


M98 Spiral Galaxy

M98 (Coma Berenices)
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-29  01:14 h UT (#64219-23)

Back to Top


M100 Spiral Galaxy

M100 (Coma Berenices)
CCD  Image, 5 x 60 sec exposure (summed)
2004-03-29  01:01 h UT (#64207-11)

M100 (catalog mag +10.2),
NGC4328 (catalog mag +14.3)
VCC636 (catalog mag +16.4)
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-29  01:01 h UT (#64207-11)

Back to Top


M105 Elliptical Galaxy

M105 (Leo)
CCD  Image, 5 x 60 sec exposure (summed)
2004-03-28  23:13 h UT (#64107-11)

M105 elliptical galaxy (catalog mag +10.1),
NGC 3384 lenticular galaxy (catalog mag +10.7)
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-28  23:13 h UT (#64107-11)

Back to Top


NGC 1857 Open Cluster

NGC 1857 (Auriga)
CCD  Colour Image,
Red 60s, Green 60s, Blue 60s, Clear 60s  (LRGB combine)
2004-03-28  21:55 h UT (#64034-37)

Back to Top


NGC 1893 Open Cluster

NGC 1893 (Auriga)
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-28  22:14 h UT (#64052-56)

Location
CCD Mosaic Image of NGC 1893 taken on 2004-03-21
(with insert showing location of new image)

Back to Top


NGC 2339 Spiral Galaxy

NGC 2339 (Gemini)
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-28  22:21 h UT (#64058-62)

Back to Top


NGC 2872 Elliptical Galaxy

NGC 2872 (Leo)
Elliptical Galaxy NGC 2872 (catalog mag +12.6),
Spiral Galaxy NGC 2874 (catalog mag +13.4),
Spiral Galaxy NGC 2873 (catalog mag +16.8)
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-28  22:21 h UT (#64058-62)

Back to Top


NGC 3190 Spiral Galaxy

NGC 3190 (Leo)
Spiral Galaxy NGC 3190 (catalog mag +11.9),
Elliptical Galaxy NGC 3193 (catalog mag +12.0),
Spiral Galaxy NGC 3187 (catalog mag +13.2)
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-28  22:34 h UT (#64070-74)

Back to Top


NGC 3338 Spiral Galaxy

NGC 3338 (Leo)
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-28  23:07 h UT (#64101-04)

Back to Top


NGC 3346 Spiral Galaxy

NGC 3346 (Leo), catalog mag +12.3
CCD  Image, 5 x 60 sec exposure (summed)
2004-03-28  22:53 h UT (#64088-92)

Back to Top


NGC 3367 Spiral Galaxy

NGC 3367 (Leo), catalog mag +12.1
CCD  Image, 5 x 60 sec exposure (summed)
2004-03-28  22:59 h UT (#64094-98)

Back to Top


NGC 3433 Spiral Galaxy

NGC 3433 (Leo), catalog mag +12.3
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-28  23:20 h UT (#64113-17)

Back to Top


NGC 3507 Spiral Galaxy

NGC 3507 (Leo), catalog mag +12.7
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-28  22:47 h UT (#64082-86)

Back to Top


NGC 3686 Spiral Galaxy

NGC 3686 (Leo), catalog mag +11.8
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-28  23:33 h UT (#64125-29)

Back to Top


NGC 4526 Lenticular Galaxy (Lost Galaxy)

NGC 4526 (Virgo), catalog mag +10.4
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-29  00:41 h UT (#64189-93)

Back to Top


UGC 5829 Irregular Galaxy (Spider Galaxy)

UGC 5829 (Leo Minor)
catalog mag +14.0
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-28  22:27 h UT (#64064-68)

See Later Image of UGC 5829 (2021)

Back to Top


Comet 123P West-Hartley

123P West-Hartley
CCD  Image, 5 x 60 sec exposure (median combine)
2004-03-29  01:27 h UT (#64231-35)

Back to Top
