Bullet Notes from CCD Session

Bullet M65/M66 Spiral Galaxies & Area Mosaic
Bullet NGC 3628 - Spiral Galaxy
Bullet NGC 4169 Galaxies (The Box)
Bullet M51 Spiral Galaxy (Whirlpool Galaaxy
Bullet M63 Spiral Galaxy (Sunflower Galaxy)
Bullet NGC 1893 Open Cluster - Mosaic

Notes (S00063)

Imaging session was with focal reducer bringing 8" f/10 LX200 to f/7. Images were recorded with ST7 CCD camera & CFW8 Colour Filter Wheel. Seeing was reasonable, however fast moving cloud patches hampered imaging forcing use of shorter exposures (30sec and 60 sec) and limited colour imaging. Despite this recorded some reasonable images of several galaxies - this was the first time I've imaged M51 and I was pretty happy with the result.  Two

Negative images of the galaxies imaged are shown below.

M51
(Whirlpool Galaxy)
NGC 4169 + Others
(The Box)
Image  Image
M63
(Sunflower Galaxy)
NGC 3628- colour
Image Image



Back to Top


M65/M66 Spiral Galaxies & Area Mosaic

Mosaic
(approximately 1 x 1 arc deg)
CCD  Mosaic [ 4 x 6 frames],  30 sec exposures, 30% resize
2004-03-21  22:28 to 22:45 h UT (#63081-104)
(View Mosaic at Full Size, 26 KB)

M65, M66 and NGC 3628 Spiral Galaxies
Mosaic as above with longer
exposure images embedded

M65 (left), M66 (right)
1/4 part of a large CCD  Mosaic [ 4 x 6],  30 sec exposures
2004-03-21  22:28 to 22:45 h UT (#63081-104)

M65 image taken one month previously (Session 58)
CCD Image,  4 x 2 minute exposure (average)
2004-02-20, 00:13 to 00:23 h UT (#58260-63)

Back to Top


NGC 3628 - Spiral Galaxy

NGC 3628 (Leo)
CCD Image,  5 x 1 min exposure (summed)
clear filter
2004-03-21  22:59 to 22:04 h UT (#63110-14)

CCD Colour Image,  LRGB
Clear 5x1 min, Red 2x2min, Green 2x2min, Blue 2x2min
rotated
2004-03-21 22:59 to 23:25 h UT (#63110-24)

Back to Top


NGC 4169 - Galaxies (The Box)

NGC 4169 et al  / Hickson 61  (Coma Berenices)
Annotated CCD Image (100% size)
3 x 1 min exposure (average), 2x2 binning, Clear filter
2004-03-21 23:30 to 23:34 h UT (#63127-29)
8" LX200 Classic + ST-7E

Negative CCD Image (100% size)
Image details as above

Back to Top


M51 - Spiral Galaxy (Whirlpool Galaxy)

M51 (Canes Venatici)
CCD Image, 15 x 1 min exposure (summed)
 clear filter
2004-03-21 23:44 h UT  to  2004-03-22 00:04 h UT
(#63137-55)

CCD Image as above
Mid range brighten

Back to Top


M63 - Spiral Galaxy (Sunflower Galaxy)

M63  (Canes Venatici)
CCD Image,  4 x 1 min exposure
2004-03-22  00:06 to 00:12 h UT (#63158-62)
CCD Image as above
Mid range Brightened

Back to Top


NGC 1893 - Open Cluster

NGC 1893 - left centre (Auriga)
Mosaic covering 59 x 48 arc min
Nebulosity associated with cluster (IC410) is not visible due to short exposure
CCD  Mosaic [ 4 x 5 frames],  30 sec exposures, 30% resize
2004-03-21  22:13 to 22:26 h UT (#63060-79)
