CCD Session S00085
Bullet Notes from CCD Session
Bullet Jupiter
Bullet Jupiter Moons

Notes (S00085)

- 1.1/4 hour imaging session
- main observing target was Jupiter which was image at f/22 with a barlow
- seeing conditions were fairly poor with unsteady atmosphere (see sequence of images of Ganymede)
- attempts to record deep-sky images in Virgo were cut short due to dew formation on the front lens of telescope (I'd forgotten to attach the dew shield and hadn't started dew heater sufficiently early).

Back to Top


Jupiter

Jupiter
CCD Colour Image
Exposures : Red 0.6s, Green 0.6s, Blue 0.8s
Processing: Aligned & colour combined with Registax3
R x1.4, G x1.0, B x1.4,  Unsharp Masked
8" LX200 with x2 Barlow operating at f/22
ST7 camera, 1x1 binning
2005-05-10  22:25 h UT (#85024,27,30)

 CCD Colour Image, as above
Additional unsharp masking, and rotation.

Image Image
Similar Image as above (75% scale reduction)
Left : 2005-05-10  22:25 h UT (#85024,27,30)
Right : 2005-05-10  22:25 h UT (#85023,26,29)

Image Image
CCD Image Clear Filter, 9 x 0.6s
Aligned & stacked with Registax3,
75% scale reduction
2005-05-10  22:37 h UT (#85072-80)
CCD Image Red Filter, 9 x 0.6s
Aligned & stacked with Registax3,
75% scale reduction
2005-05-10  22:34 h UT (#85057-65)


Back to Top


Jupiter Moons

Jupiter + Europa
(Europa is about to be occulted - at 22:50h UT)
CCD Image, 0.2s exposure, clear filter
2005-05-10  22:38 h UT (#85082)

Europa just before point of occulation
CCD  Image,
2 sec exposure, clear filter
2005-05-10  22:47 h UT (#85114)

Jupiter + Io & Ganymede
Amalthea also lies within the field between Jupiter & Ganymede,
but at magnitude +14 it is is not visible in this short exposure
(an even in a long exposure it is likely to be lost in the glare from Jupiter, mag -2.3)
CCD Image
0.4 sec exposure, clear filter
2005-05-10  22:56 h UT (#85154)
Seeing  conditions as indicated by series of images of Ganymede
Image I
CCD Animation,  10 x 0.2s frames over a 38 sec period
Clear Filter,  frame width is 43 arc secs
2005-05-10  22:50 h UT (#85125-34)
