Objects Session Notes
Bullet AXP Monitoring (4U 0142+615 & 1E 2259+586)
Bullet M52 - Open Cluster
Bullet M103 - Open Cluster
Bullet M74 - Spiral Galaxy
Bullet IC 348 - Open Cluster with Nebulosity
Bullet Barnards B16 - Dark Nebula
Bullet NGC 1605 - Open Cluster
Bullet NGC 1514 - Planetary Nebula (Crystal Ball Nebula)
Bullet MPL 2003 UB313 (Attempt)
Bullet M31 - Spiral Galaxy (Andromeda Galaxy)
Bullet PGC 61173 - Spiral Galaxy
Bullet NGC 7242 - Elliptical Galaxy
Bullet NGC 7274 - Elliptical Galaxy
Bullet NGC 7274 - Elliptical Galaxy
Bullet NGC 6992 - Supernova Remnant (Veil Nebula, East)
Bullet NGC 6960 - Supernova Remnant (Veil Nebula)
Bullet NGC 6888 - Nebula (Crescent Nebula)
Bullet IC 5067 - Nebula (Pelican Nebula)
Bullet M1 - Supernova Remnant (Crab Nebula)
- 5.4 hour session (ambient temp +12.5 to +11.0 deg C)
- Aim of session was to record a variety of Deep Sky objects, and session was rewarded with a variety of objects, including clusters, galaxies, dark nebula, supernova remnants (including the Veil Nebula).
- 7 mosaics were recorded
- Opportunity was taken to acquire images of first time images of M52 and M103 objects and obtain improved images of M74
- An attempt was made to acquire images of Kuiper Belt Object 2003 UB313, but sky conditions did not allow this faint object to be seen
- More Notes

AXP Monitoring (4U 0142+615 & 1E 2259+586)

Two Anomalous X-ray pulsers (AXPs),  4U 0142+615 and  1E 2259+586 (both lying in Cassiopeia) were checked for brightening. No indication of activity was observed for either AXP.

Star field of 4U 0142+615 area
no sign of AXP (mag limit +17)
CCD Image
2 min exposure,  C Filter
2005-09-02 21:46h UT (#93017)

Star field of 1E 2259+586 area
no sign of AXP (mag limit +16.5)
CCD Image
2 min exposure,  C Filter
2005-09-02  21:55h UT (#93024)

[ Baseline Images and More Information ]

Back to Top


M52 - Open Cluster

M52 (Cassiopeia)
CCD Image Mosaic (2x2 frames)
20 sec exposure, R filter
2005-09-02  22:07 h UT (#93029-32)

Back to Top


M103 - Open Cluster

M103 (Cassiopeia)
CCD Image Mosaic (3x3 frames)
20 sec exposure, C filter
2005-09-02  22:32 h UT (#93039-49)

Back to Top


M74 - Spiral Galaxy

M74  (Pisces)
CCD Image
6x60s exposure (average combine), C Filter
2005-09-02  22:51 h UT (#93055-60)

 M74 (false colour)
CCD Image False Colour
3x60s exposure (average combine), C Filter
Logarithmic Scaling, False Colour
2005-09-03  00:40 h UT (#93152-54)

Back to Top


IC 348 - Open Cluster with Nebulosity

IC 348  (Perseus)
CCD Image
5 x 60s exposure (average combine), C Filter
2005-09-02  23:08 h UT (#93067-72)

 IC 348 (false colour)
Nebulosity is highlighted in this display
False Colour CCD Image
Logarithmic Scaling, Negative
details as above

Back to Top


Barnards B16 - Dark Nebula

B16 (Perseus) -  B16, B15, B17
  (identification of specific dark nebula is uncertain, as they somewhat merge together)
CCD  Image Mosaic (4 x 4 frames)
20s exposure, C Filter
2005-09-02  23:19 h UT (#93073-94)
(Full Size Image)

Back to Top


NGC 1605 - Open Cluster

NGC 1605 (Perseus)
CCD  Image
3 x 60s exposure (average combine), C Filter
2005-09-02  23:31 h UT (#93096-98)
(Full Size Image)

Back to Top


NGC 1514 - Planetary Nebula (Crystal Ball Nebula)

NGC 1514 (Taurus)
CCD  Image
3 x 60s exposure (average combine), C Filter
2005-09-02  23:36 h UT (#93100-02)
(cf. image from 2004-09-18

Back to Top


M31 - Spiral Galaxy (Andromeda Galaxy)

M31 - Transect (Andromeda)
It was not feasible to commit time to complete a Mosaic of entire M31, and in
any case the sky conditions were too variable to make a good job.
Instead an E-W Transect was made comprising 5 frames
CCD  Image Mosaic (5 x 1 frames)
120s exposure , C Filter, Logarithmic Scaling
2005-09-03  00:27 h UT (#93144-49)

Image Mosaic (central portion of above Transect)
120s exposure , C Filter,  Linear brightness scaling
2005-09-03  00:27 h UT (#93144-49)


False Colour CCD  Image Mosaic
Logarithmic Scaling, False Colour
image details as above

Back to Top


MPL 2003 UB313 Attempt - Kuiper Belt Object

2003 UB313 Attempt
Predicted Position of 2003 UB313 is midway between
the pair of mag +15.7 stars shown within red circle.
Due to low altitude / haze the deepest magnitude visible in image
is c. +17.7 and thus prevented being able to see this 19th magnitude
Kuiper Belt object, which has recently been proposed in the media as a Planet.
CCD  Image (negative)
20 x 1 min exposure (average combine), C Filter
2005-09-03  01:10 h UT (#93108-27)

Back to Top


PGC 61173 - Spiral Galaxy

PGC 61173 (Hercules)
(Alt Name UGC 11064 )
CCD Image
3x60s exposure (average combine), C Filter
2005-09-03  00:49 h UT (#93157-59)

Image was acquired in an attempt to image the discovered
Supernova 2005ds (discovered 2005-08-31)
however SN is reported to be +18.5 mag and was not visible
(mag limit of image is estimated at +17)

Back to Top


NGC 7242 - Elliptical Galaxy

NGC 7242 (Lacerta)
(NGC 7242 Catalog Mag +12.9)
CCD Image
5x60s exposure (average combine), C Filter
2005-09-03  00:49 h UT (#93161-65)

Image was acquired to compare image taken in 2001
which has shown SN 2001ib

Supernova 2001ib
Image Image
CCD Image (negative)
2001-12-14
with SN 2001ib (more)
CCD Image (negative)
2005-09-03
scaled & cropped to same area

Back to Top


NGC 7274 - Elliptical Galaxy

NGC 7274 (Lacerta)
CCD Image
3x60s exposure (average combine), C Filter
2005-09-03  01:01 h UT (#93167-69)

Back to Top


NGC 6992 - Supernova Remnant (Veil Nebula, East)

NGC 6992 (Cygnus)
 Image Image
CCD Image Mosaic (3x6 frames)
60s exposure, C Filter
2005-09-03  01:18 h UT (#93170-87)
(Full Size)
CCD Image Mosaic (3x6 frames)
Negative
(details as left)

Part of NGC 6992 (Cygnus)
CCD Image
3 x 60s exposure (average combine) C Filter
2005-09-03  01:31 h UT (#93188-90)

CCD Image (negative)
image details as above

Approximate Colour CCD Image (LRGB)
Luminance : 3 x 60s (C), Red 60s (R), Green 60s (V),  Blue 120s (B)
2005-09-03  01:33 h UT (#93188-94)

Back to Top


NGC 6960 - Supernova Remnant (Veil Nebula)

NGC 6960 (Cygnus)
bright star is 52 Cygni (SAO 70467, Mag +4.2)
 Image Image
CCD Image Mosaic (2x6 frames)
60s exposure, C Filter
2005-09-03  01:54 h UT (#93200-11)
(Full Size
CCD Image Mosaic (2x6 frames)
Negative
(details as left)

Part of NGC 6960 (Cygnus)
CCD Image
60s exposure, C Filter
2005-09-03  02:07 h UT (#93213-15)

CCD Image (negative)
image details as above

Faint Nebulosity between NGC 6960 and NGC 6992 (Cygnus)
 Image Image
CCD Image Mosaic (2x6 frames)
60s exposure, C Filter
2005-09-03  02:18 h UT (#93216-28)
(Full Size
CCD Image Mosaic (2x6 frames)
Negative
(details as left)

Back to Top


NGC 6888 - Nebula (Crescent Nebula)

NGC 6888 (Cygnus)
(Caldwell 27)
CCD Image Mosaic (54% size)
60s exposure, C Filter
2005-09-03  02:07 h UT (#93213-15)
8" LX200 Classic + ST-7E
(Full Size)

Negative CCD Image Mosaic (54% size)
image details as above
(Full Size)

Back to Top


IC 5067 - Nebula (Pelican Nebula)

Part of IC 5067 (Cygnus)
CCD Image
5 x 60s exposure (average combine), C Filter
2005-09-03  02:07 h UT (#93235-39)

Back to Top


M1 - Supernova Remnant (Crab Nebula)

M1 (Taurus)
CCD Image
3 x 60 sec exposure (average), C filter
2005-09-03  02:48 h UT (#93243-45)


CCD Image (Negative)
Details as above

Back to Top
